Specifications - Samsung SCL810 Owner's Instruction Book

ENGLISH

Specifications

These technical specifications and design may be changed without notice.
System
Recording system
Video signal
Usable cassette
Tape speed
Speed mode
Recording time
FF or REW time
Image device
Optical zoom ratio
Focal length: f
F
Filter diameter
Focus system
Macro
Min. Illumination
LCD monitor
Size/Pic. cell
Method
Connectors
Video out
Audio out
External mic
General
Power requirements
Power consumption
*Recording, LCD ON
Built-in mic
Built-in speaker
Operating temperature
Dimension (WxHxD)
Weight
72
SCL810/L860/L870
Video: 2 rotary heads Helical scanning FM
Audio: FM monaural system
NTSC color, EIA standard
Hi8 or 8mm
SP: 14.345 mm/sec
Record: SP only Playback: SP only
P6-120: 120 min.
P6-120: approx. 6.5 min.
CCD (Charge Coupled Device)
22x
3.6~79.2 mm
1.6
46 mm
Inner
Auto wide macro
0.3 lux (visible)
2.5 inch/112k
TFT
Mini jack, 1 Vp-p, 75 ohms, Unbalanced
Mini jack, 7.7 dBs, imp.: less than 820 ohms
Monaural ø3.5 (SCL860/L870)
DC 8.4 V (1.5 A)
SCL810 : 5.4 W, SCL860/L870: 5.9 W
Condenser mic, omni-directional
Dynamic, 0.5 W standard
0°C to 40°C (32°F to 104°F)
101x104x174 mm (3.98x4.09x6.85 inches)
780 g (1.716 lbs)
