This new drill has been engineered and manufactured to our high standard for dependability, ease of operation and operator
safety. When properly cared for, the drill will give you years of rugged, trouble-free performance.
WARNING
To reduce the risk of injury, the user must read and understand the operator's manual before using this product.
Thank you for buying a RIDGID product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
1/2 in. SPADE HANDLE DRILL
SINGLE SPEED/REVERSIBLE
DOUBLE INSULATED
R7121
1

Advertisement

Table of Contents
loading

Summary of Contents for RIDGID R7121

  • Page 1 This new drill has been engineered and manufactured to our high standard for dependability, ease of operation and operator safety. When properly cared for, the drill will give you years of rugged, trouble-free performance. WARNING To reduce the risk of injury, the user must read and understand the operator’s manual before using this product.
  • Page 2: Table Of Contents

    INTRODUCTION The spade handle drill has many features for making the use of this product more pleasant and enjoyable. Safety, performance, and dependability have been given top priority in the design of this product making it easy to maintain and operate.
  • Page 3: General Safety Rules

    GENERAL SAFETY RULES WARNING: Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “power tool” in all of the warnings listed below refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 4: Specific Safety Rules

    GENERAL SAFETY RULES SERVICE  Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. WARNING! To reduce the risk of injury, user must read instruction manual.
  • Page 5: Symbols

    SYMBOLS Important: Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME Volts Amperes Hertz Watt Minutes Alternating Current...
  • Page 6: Electrical

    Always use original factory replace- ment parts when servicing. ELECTRICAL CONNECTION The drill has a precision-built electric motor. It should be connected to a power supply that is 120 volts, 60 Hz, AC only (normal household current). Do not operate this tool on direct current (DC).
  • Page 7: Features

    This new drill is equipped with the following features. See Figure 1. SINGLE SPEED REVERSIBLE SWITCH This drill has a single speed rocker-type switch. The switch is reversible for changing the direction of rotation. LOCK-ON BUTTON This tool is equipped with a lock-on feature for continuous drilling.
  • Page 8: Unpacking

     Do not discard the packing material until you have care- fully inspected and satisfactorily operated the tool.  If any parts are damaged or missing, please call 1-866-539-1710 for assistance. PACKING LIST 1/2 in. (13 mm) Single Speed Reversible Drill Spade Handle Auxiliary Handle Chuck Key Key strap Operator’s Manual...
  • Page 9: Assembly

    INSTALLING AUXILIARY HANDLE See Figure 2. An auxiliary handle is packed with the drill for ease of op- eration and to help prevent loss of control. The auxiliary handle may be installed at three different positions on the drill body.
  • Page 10: Assembly

     Unplug the drill.  Insert the chuck key and twist counterclockwise as shown in figure 4.  Insert the drill bit into the chuck the full length of the jaws. WARNING: Do not insert drill bit into chuck jaws and tighten as shown in figure 5.
  • Page 11: Operation

    Exercise caution when using this tool. Careless actions, for even a fraction of a second, can result in serious personal injury. APPLICATIONS You may use the spade handle drill for the purposes listed below:  Drilling in wood  Drilling in both hard and soft metals ...
  • Page 12  Plug the drill into power supply source.  Hold the drill firmly and place the bit at the point to be drilled.  Depress the switch trigger to start the drill. Do not lock the switch ON for jobs where the drill may need to be stopped suddenly.
  • Page 13: Maintenance

     Open chuck jaws using the provided chuck key.  Insert a 3/8 inch (10 mm) or larger hex key wrench into the chuck of the drill and tighten the chuck jaws securely.  Tap the hex key wrench sharply with a mallet in a clock- wise direction.
  • Page 14: Brush Replacement

    BRUSH REPLACEMENT See Figure 13. The drill has externally accessible brush assemblies that should be periodically checked for wear. Follow these steps to replace the brushes:  Unplug the drill.  Remove the brush cap with a flat blade screwdriver. The brush assembly is spring loaded and will pop out when you remove the brush cap.
  • Page 15: Accessories

    MAINTENANCE WARNING: When servicing use only identical RIDGID replacement parts. Use of any other parts may create a hazard or cause product damage. GENERAL Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of commercial solvents and may be damaged by their use.
  • Page 16 NOTES...
  • Page 17: Warranty

    2/1/04 and after. This product is manufactured by One World Technologies, Inc. The trademark is licensed from RIDGID, Inc. All warranty communications should be directed to One World Technologies, Inc., attn: RIDGID Hand Held and Stationary Power Tool Technical Service at (toll free) 1-866-539-1710.
  • Page 18: Customer Service Information

    R7121 Customer Service Information: For parts or service, contact your nearest RIDGID authorized service center. Be sure to provide all relevant information when you call or visit. For the location of the authorized service center nearest you, please call 1-866-539-1710 or visit us online at www.ridgid.com.
