FURY
Residential Electric Water Heaters
Available in 30, 38.5 and 60 Imperial Gallon Electric Models
6 Year Limited Tank Warranty*
1 Year Limited Parts Warranty*
•
R-Foam Insulation for greater heat
retention – cuts energy costs
•
Proven Rheemglas
corrosive attacks of hot water chemicals
Get
2 MORE YEARS
– ensures longer tank life
with ProtectionPlus
™
•
Direct Immersion Elements efficiently
transmits heat directly to water and
creates more hot water at less cost
•
Magnesium Anode Rod for greater
protection of inner tank – reduces
corrosion and extends water heater life
•
Temperature and Pressure Relief
Valve included
DESCRIPTION
STORAGE
CAPACITY
ELEM.
IMP.
MODEL NUMBER
GALS.
LITERS
QTY.
TOP INLET, TOP EXIT
RR317T
30
135
RR415TM
37.5
170
RR615TM
60
270
SIDE INLET, TOP EXIT
RR415SI
38.5
175
RR615SI
60
270
RR620SI
60
270
• 3⁄4" N.P.T. outlet, inlet, anode rod, T&P valve connections.
• 140°F thermostat setting.
• Not available with 3 phase wiring.
6
Y E A R
TA N K W A R R A N T Y
B E C O M E S
In keeping with its policy of continuous progress and product improvement, Rheem reserves the right to make changes without notice.
Rheem Manufacturing Company • Water Heater Division
Rheem Canada Ltd./Ltée,128 Barton Street West, Hamilton, Ontario L8N 3P3
0 3 / 0 6 W P
™
Lining resists
FEATURES
HEATING ELEMENTS
120 VOLT
208 VOLT
WATTAGE
AMPS
WATTAGE
2
1500
12.5
2250
2
1500
12.5
2250
2
N/A
N/A
3380
2
N/A
N/A
2250
2
N/A
N/A
3380
2
N/A
N/A
3380
8
L I M I T E D
•
Factory Installed Plumbing Nipples
•
Electrical Junction Box is located
ontop of water heater – reduces wiring
costs and more attractive appearance
•
Automatic Temperature Control
Thermostats keeps water stored at a
desired temperature – convenient,
dependable hot water
•
Certified to the CAN/CSA C191.1-M90
efficiency standard
*See Residential Warranty Information
Brochure for complete warranty information.
ROUGHING IN DIMENSIONS
HEIGHT
240 VOLT
(IN.)
AMPS
WATTAGE
AMPS
A
10.8
3000
12.5
46-1/2
10.8
3000
12.5
46
16.3
4500
18.8
59
10.8
3000
12.5
47
16.3
4500
18.8
58
16.3
4500
18.8
58
OUTSIDE
HT. TO
ESTIMATED
DIAMETER
DRAIN
SHIPPING WEIGHT
(IN.)
VALVE (IN.)
B
C
19-3/4
3-1/2
105
21-3/4
3-1/2
117
23
3-1/2
177
21
3-1/2
124
23
3-1/2
174
24-5/16
3-1/2
188
F O R M N O. 1 0 1 - 5 C A N R e v. 6
LBS.
KG
48
53
80
56
79
85
