Summary of Contents for Regency Excalibur P90
- Page 1 direct vent gas fireplaces...
- Page 2 I offer a Limited Lifetime Warranty. The Regency warranty is the best in the industry. I am absolutely sure that you will be as proud of your Regency Gas Fireplace as I am – I guarantee it. Robert Little Founder & CEO...
-
Page 3: Table Of Contents
Contemporary Collection Regency Horizon HZ54 Sunrise L676S, P33S Liberty Gas Fireplaces Liberty L900, L676 Excalibur Gas Fireplaces Excalibur P95, P90 Panorama Gas Fireplaces Panorama P131, P121 Panorama P48 Panorama P42, P40 Panorama P36, 36D Panorama P33 Design Choices Technical specs... -
Page 4: Regency Horizon Hz54
Inset reflective panels amplify the appearance of the stunning fire. The incredible styling is backed up by practical function; delivering consistent, controllable heat - even during power outages. Regency Horizon HZ54 shown with cobalt blue crystals, brushed stainless steel faceplate and reflective panels. - Page 5 Regency Horizon HZ54 shown with cobalt blue crystals, bright stainless steel faceplate and reflective panels. Specifications Natural Gas Input (BTU) 41,500 Turn down to (BTU) 29,000 EnerGuide Rating (Canada only) 55.08% Efficiency (steady state) Dimensions Faceplate width 54-3/4" Faceplate height 23-3/16"...
-
Page 6: Sunrise L676S, P33S
Sunrise L676S & P33S Contemporary Gas Fireplaces We have redefined the conventional firebox to include dramatic, contemporary elements that take it from timeless and traditional to modern and sensational! Reflective panels expand and amplify the beautiful Sunrise fire with cobalt blue crystals or ceramic spa stones. - Page 7 P33S Sunrise shown with cobalt blue crystals and stainless steel faceplate. L676S Sunrise shown with ceramic spa stones, stainless steel reflective panels and red faceplate. Specifications (NG)* L676S P33S Input (BTU) 29,000 17,000 Turn down to (BTU) 19,500 12,000 EnerGuide Rating (Canada only) 60.97% 65.08% Efficiency (steady state)
-
Page 8: Liberty L900, L676
Liberty L900 & L676 Gas Fireplaces The Liberty design creates an authentic masonry fireplace look that is sleek and simple in appearance with a beautiful flame and moderate heat. This Direct Vent fireplace looks so much like a real wood fire you just won’t believe it! No louvers and “disappearing” glass work together with the brick panels, extraordinary fire and log package to create a simply beautiful oasis. - Page 9 Liberty L676 shown with red brick panels. Andirons Specifications (NG)* L900 L676 Input (BTU) 41,500 33,000 Turn down to (BTU) 28,000 22,000 EnerGuide Rating (Canada only) 51.25% 45.75% Efficiency (steady state) Unit Dimensions Viewing area 900 sq.in. 676 sq.in. Width 47-1/2"...
-
Page 10: Excalibur P95 & P90
Excalibur P95 & P90 Gas Fireplaces Sit back and enjoy the irresistible comfort of an Excalibur fire. The Excalibur P95 direct vent gas fireplace is an incredible combination of timeless design and enduring quality. The fine finishing is what makes this one of the most sought after fireplaces anywhere today. - Page 11 P90 shown with antique nickel surround, double screen doors & herringbone brick panels. P95 shown with black surround & herringbone brick panels. Specifications (NG) Input (BTU) 45,000 35,000 Turn down to (BTU) 23,200 18,200 EnerGuide Rating (Canada only) 66.76% 67.75% Efficiency (steady state) Faceplate Dimensions Width...
-
Page 12: Panorama P131, P121
Panorama® P131 & P121 Three & Two Sided Gas Fireplaces Enjoy Regency fire and warmth in two rooms with one fireplace or select the corner fireplace option for your unique home design. For calming warmth and an exceptional fire view from all 3 sides of a spe- cial living space choose the Regency Pier fireplace. - Page 13 P131 shown with stainless steel louvers and trim. P131 shown with decorative patterned grills in black. Specifications Natural Gas Propane Input (BTU) 40,000 39,000 Turn down to (BTU) 20,500 20,600 EnerGuide Rating (Canada only) 60.66% 62.51% Efficiency (steady state) Unit Dimensions P131 P121 Viewing area...
-
Page 14: Panorama P48
Panorama® P48 Extra Large Gas Fireplace The largest gas fireplace in the Regency family, P48 presents a spectacular fire and extraordinary heat for your large living areas. Perfect for open living spaces, 51,000 BTU of comforting warmth is circulated to every corner. Backed by the most comprehensive warranty in the industry today, you'll enjoy your Regency worry free for years to come. - Page 15 Shown with gold louvers, brick panels and black finishing trim. Specifications Natural Gas Propane Input (BTU) 51,000 48,000 Turn down to (BTU) 29,000 26,000 EnerGuide Rating (Canada only) 62.30% 62.51% Efficiency (steady state) Unit Dimensions Width 48" Height 41" Depth 23-1/4"...
-
Page 16: Panorama® P40 & P42
Panorama® P40 & P42 Large Gas Fireplaces Continuing the standard set by the P48, the P42 delivers 35,000 BTU of consistent, controllable high efficiency heat for average sized living areas. The exceptional, full bodied flame can be enjoyed at 50% turn- down for maximum comfort choice. - Page 17 P40 shown with gold louvers and brick panels. Specifications (NG) Input (BTU) 45,000 35,000 Turn down to (BTU) 13,000 17,500 EnerGuide Rating (Canada only) 76.34% 63.2% Efficiency (steady state) Unit Dimensions Width 40" 40" Height 34" 34" Depth 20-1/16" 18-5/8" View area 699 sq.in.
-
Page 18: Panorama P36, 36D
Balmoral. Customize with warm finishes, screen doors and decorative accents - make it your Regency, right down to the last detail. Panorama P36 Gas Fireplace featuring Balmoral front in Smithy Black, 3-panel door, FireArt™ and brick panels. - Page 19 P36 shown with Tripoli front and brick panels. Specifications Natural Gas Propane Input (BTU) 30,000 30,000 Turn down to (BTU) 15,500 15,000 EnerGuide Rating (Canada only) 62.70% 62.70% Efficiency (steady state) Unit Dimensions Width 36" Height 30-1/2" Depth P36 12-3/4" Depth P36D 17-1/8"...
-
Page 20: Panorama P33
Panorama family in a compact size. This slim fireplace is fre- quently featured in bedrooms, kitchens and dens; quietly warming or dramatically focusing attention on the incredible Regency fire. Panorama P36 Gas Fireplace featuring brushed copper full screen doors and brick panels. - Page 21 P33 shown with black full screen doors and brick panels. Specifications Natural Gas Propane Input (BTU) 22,500 21,500 Turn down to (BTU) 10,500 10,500 EnerGuide Rating (Canada only) 62.49% 65.03% Efficiency (steady state) Unit Dimensions Width 33" Height 29" Depth 12-3/4"...
- Page 22 Programmable Wall Thermostat By setting a specific temperature with a Regency wall thermostat you can maintain a constant comfort level in your home for several hours or all day long.
-
Page 23: Design Choices
- contemporary collection Regency Horizon HZ54 Firebed options Cobalt blue crystals Ceramic spa stones Surround finishes Black Blue Black Brushed stainless steel Sunrise L676S Accent pebbles Log option Natural river pebbles Silver Accessories - Contemporary Collection Sunrise™ fire... -
Page 24: Full Screen Doors
design choices - traditional collection Fronts Liberty clean face style Flush front Louvers Gold* Brushed Steel Excalibur surround finishes Polished Gold* Antique Nickel** Full Screen Doors Black Brushed Copper** Brick Panels Herringbone - Rustic Brown Standard - Rustic Brown * 24 k gold plated ** Brushed &... - Page 25 Balmoral surround Kensington surround Accessories - at a glance Flush Front Glass Bay Front Glass Classic look Louvers Black Black/Brushed Steel Black/Gold Double Screen Doors Black Glass Trim Flush Brushed Steel Glass Trim Bay Gold Finishing Trim Black Excalibur Arch Surround Polished Gold Surrounds...
-
Page 26: Technical Specs
Regency Horizon™ HZ54 NOTE: All product specifications are subject to change without notice. Before installing refer to the relevant product manual for full and up to date information. Manuals can be downloaded from our web site www.regency-fire.com EnerGuide Rating Turn Down to (BTU) - Page 27 Dimensions P33S L676S Flue size 4" x 6-5/8" 5" x 8" 33-5/8” 42-1/2” 23” 33-1/8” 29” 37-3/8” 31-1/2” 45-5/8” 12-3/4” 24-1/2” 29” 40-3/8” 29-1/16” 31-5/8” 3” Framing P33S L676S 12” 3” 33-1/4” 43” Metal stud 31-3/4” 45-7/8” on edge (for L676S) vertical rise 19-1/2”...
- Page 28 Liberty direct vent fireplaces L900 / L676 Dimensions L676 Viewing area 676 sq.in. Flue size 5/8" 29-5/8" 28-1/16" 45-5/8" 8-1/4" 1" 1-1/2" 26" 42-1/2" 1/2" 24-1/2" Framing L676 80-13/16" 57-3/16" 45-7/8" 79" 25-3/4" 43" * Metal stud required. Non-combustibles L676 31-1/16"...
- Page 29 Excalibur direct vent fireplaces P95/P90 - Framing FRAMING - TOP VIEW CORNER INSTALL Minimum clearances to combustibles/framing 80-1/4" 56-3/4" 53-3/8" 70-1/2" 49-7/8" 46-1/2" Mantel clearances 12" 0-4" 22" 12" 0-8" 22-1/4" Panorama P131/121 P131 / P121 Front 12-1/2” 21-1/8” 12-1/2” Dimensions P131 44-1/2"...
- Page 30 Panorama direct vent fireplaces dimensions 48" 41" 40-1/16" 23-5/16" 40" 34" 32-7/8" 18-7/16" 40" 34" 32-1/2" 21-7/16" 33-7/16" 20-1/16" P36D 36" 30-1/2" 29-3/16" 15-1/2" 36" 30-1/2" 29-3/16" 15-1/2" 33" 29" 26" 16" framing FRAMING - TOP VIEW P36/P36D/P40/P42 MINIMUM TERMINATION CENTER LINE P36/P36D/P40/P42 P36/P36D/P42 Header...
-
Page 31: Mantel Clearances
mantel clearances Mantel Clearances 41" 15" 32-1/4" 14" 33" 21" 16-1/4" 15-1/2" P36 Flush 30-1/2" 14" P36 Bay 30-1/2" 13" P36 Deep Flush 30-1/2" 14" P36 Deep Bay 30-1/2" 13" P36 Barcelona 30-1/2" 17" P36 Barcelona Deep 30-1/2" 17" P36 Kensington/Balmoral 30-1/2"... - Page 32 We want you to enjoy your beautiful Regency fireplace for years to come. To help you figure out which product is just right for your home, fill in the following worksheet. Once complete, visit your nearest Regency dealer. Your professional Regency dealer will assess your needs - including local building codes - and install your Regency.
