ProForm CROSSWALK CALIBER ELITE PFTL71505.2 User's Manual

Proform user manual treadmill pftl71505.2.
Model No. PFTL71505.2
Serial No.
Write the serial number in the
space above for future reference.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or if parts are missing,
PLEASE DO NOT CONTACT
THE STORE; please contact
Customer Care.
IMPORTANT: You must note the
product model number and
serial number (see the drawing
above) before contacting us:
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.proformservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!

   Related Manuals for ProForm CROSSWALK CALIBER ELITE PFTL71505.2

   Summary of Contents for ProForm CROSSWALK CALIBER ELITE PFTL71505.2

  • Page 1

    Sat. 8 a.m.–4 p.m. MST ON THE WEB: www.proformservice.com CAUTION Read all precautions and instruc- tions in this manual before using this equipment. Save this manual for future reference. USER'S MANUAL Visit our website at www.proform.com new products, prizes, fitness tips, and much more!

  • Page 2: Table Of Contents

    HOW TO FOLD AND MOVE THE TREADMILL ........

  • Page 3: Important Precautions

    To reduce the risk of serious injury, read all important precautions and in- structions in this manual and all warnings on your treadmill before using your treadmill. ICON as- sumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4

    (See the drawing on page 5 for the location of the circuit breaker.) 21. Do not attempt to raise, lower, or move the treadmill until it is properly assembled.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new PROFORM WALK CALIBER ELITE treadmill. The CROSSWALK CALIBER ELITE treadmill offers an impressive array of features designed to make your workouts at home more enjoyable and effective. And when you’re not ex-...

  • Page 6: Assembly

    To hire an authorized service technician to assemble the treadmill, call 1-800-445-2480. Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials; do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-perfor- 3/4”...

  • Page 7

    2. Attach a Wheel (66) to the base of the Uprights (69) with a Wheel Bolt (64) and a Nut (13) as shown. Do not overtighten the Wheel Bolt; the Wheel should turn freely. With the help of a second person, carefully tip the tread- mill onto its other side.

  • Page 8

    5. If there is a board between the Uprights (69), remove the two bolts attaching the board. Discard the board and the bolts. Identify the Right Handrail (72), which has a large hole in the left side. Remove the wire tie securing the Upright Wire (42) inside of the right Upright (69).

  • Page 9

    Upright (not shown) in the same way. 11. Make sure that all parts are properly tightened be- fore you use the treadmill. Note: Extra hardware may be included. Keep the included hex key in a secure place; the hex key is used to adjust the walking belt (see page 26).

  • Page 10: Operation And Adjustment

    (see drawing 1 at the right). To purchase a surge suppressor, see your local PROFORM dealer or call the telephone number on the front cover of this manual and order part number 146148, or see your local electronics store.

  • Page 11

    When the manual mode of the console is selected, the speed and incline of the treadmill can be changed with the touch of a button. As you exercise, the console will display continuous exercise feedback. You can even measure your heart rate using the built-in handgrip pulse sensor.

  • Page 12

    THE INFORMATION MODE on page 22 to turn off the demo mode. Next, stand on the foot rails of the treadmill. Find the clip attached to the key (see the drawing on page 11) and slide the clip onto the waistband of your clothes.

  • Page 13

    The lower left corner of the display will also show the incline level of the treadmill for a few seconds each time the incline setting changes. Note: When a speed & incline program or the calorie goal pro-...

  • Page 14

    Speed increase button. The walking belt will begin to move at 1 mph. When the next seg- ment of the workout begins, the treadmill will auto- matically adjust to the speed and incline settings for the next segment.

  • Page 15

    6.5 mph. Note: To change the speed of the walking belt or the incline of the treadmill at any time during the program, press the Speed or Incline buttons. The upper left corner of the display will show the number of meters still to be run.

  • Page 16

    To change the speed of the walking belt or the in- cline of the treadmill at any time during the pro- gram, press the Speed or Incline buttons. Note: Each time you change the speed of the walking belt, the time remaining in the program will auto- matically be recalculated.

  • Page 17

    HOW TO CONNECT THE TREADMILL TO USE IFIT.COM PROGRAMS To use iFIT.com MP3 or CD programs, the treadmill must be connected to your MP3 player, CD player, portable stereo, home stereo, or computer. See pages 17 and 18 for connecting instructions. To use iFIT.com programs directly from our Web site, the treadmill must be connected to your computer.

  • Page 18

    HOW TO CONNECT YOUR HOME STEREO Note: If your stereo has an unused LINE OUT jack, see instruction A below. If the LINE OUT jack is being used, see instruction B. A. Plug one end of a long 1/8" to RCA stereo audio cable (available at electronics stores) into the input jack on the console.

  • Page 19

    Start button on the console. The VIDEO AUDIO RF OUT treadmill will not respond to an MP3, CD, or video program while the time is flashing in the display. During the program, an electronic “chirping” sound Y-adapter will alert you when the speed and/or incline of the treadmill is about to change.

  • Page 20

    Stop button or remove the key and go to step 1 on page 19. Note: If the speed and/or incline of the treadmill does not change when a “chirp” is heard: • Make sure that the Personal Training indicator is lit and that the time is not flashing in the dis- play.

  • Page 21

    Additional options are soon to be available. See www.iFIT.com for details. To use programs from our Web site, the treadmill must be connected to your home computer. See HOW TO CONNECT YOUR COMPUTER on page 18. In addition, you must have an internet connection and an internet service provider.

  • Page 22

    The console features a display demo mode, designed to be used if the treadmill is displayed in a store. While the demo mode is turned on, the console will function normally when you plug in the power cord, switch the reset/off circuit breaker to the reset posi- tion, and insert the key into the console.

  • Page 23: How To Fold And Move The Treadmill

    2. Move your right hand to the position shown and hold the treadmill firmly. Using your left hand, pull the latch knob to the left and hold it. Raise the frame until the hole in the frame is aligned with the latch pin. Slowly release the latch knob;...

  • Page 24: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual.

  • Page 25

    PROBLEM: The console displays remain lit when you remove the key from the console SOLUTION: a. The console features a display demo mode, designed to be used if the treadmill is displayed in a store. If the displays remain lit when you remove the key, the demo mode is turned on. To turn off the demo mode, see THE INFORMATION MODE on page 22.

  • Page 26

    Be careful to keep the walking belt centered. Then, plug in the power cord, insert the key, and run the treadmill for a few minutes. Repeat until the walking belt is properly tightened. c. If the walking belt still slows when walked on, please see the front cover of this manual.

  • Page 27: Exercise Guidelines

    EXERCISE GUIDELINES WARNING: Before beginning any exercise program, consult your physician. This is especially important for persons over the age of 35 or persons with pre-existing health problems. The pulse sensor is not a medical device. Various factors may affect the accuracy of heart rate readings.

  • Page 28

    PART LIST—Model No. PFTL71505.2 No. Qty. Description Hood 3/4" Screw Motor Belt Motor Tension Bolt Right Grip Plate Motor Star Washer Left Grip Plate Drive Motor Foot Rail Decal Reed Switch Latch Warning Decal Frame Spacer Frame Pivot Bolt Platform Screw, Front Handrail Cap Front Roller/Pulley Magnet...

  • Page 29

    EXPLODED DRAWING—Model No. PFTL71505.2 R0108A...

  • Page 30

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
