PM0496504.17 Insert Additif Adición Honda – ELECTRIC GENERATOR Honda – GROUPE ELECTROGENE Honda – GENERADOR ELECTRICO IMPORTANT – Please make certain that persons who are to use this equipment thoroughly read and understand these instructions and any additional instructions provided prior to operation.
MAJOR GENERATOR FEATURES 13 HP Honda OHV engine Cast-iron cylinder sleeve Low oil sensor Receptacles on control panel Voltmeter and hour meter on panel Idle control Automatic voltage regulator (AVR) Battery charger CordKeeper™ 5.6 gallon metal fuel tank Spark arrester Portability Kit CONTROL PANEL A.
Use cables approved for battery charging. Connect a red clip to the positive terminal of the battery. Connect a black clip to the negative terminal of the battery. Connect the other end of the clip wire to the corresponding black(-) and red (+)binding posts on the generator panel.
LIMITED WARRANTY (NOT VALID IN MEXICO) This product is warranted by Coleman Powermate, Inc. to the original retail consumer against defects in material and workmanship for a period of two years from the date of retail purchase and is not transferable. This two year warranty applies only to products used in consumer applications.
CARACTÉRISTIQUES PRINCIPALES DU GROUPE ELECTROGENE Moteur 13 HP Honda OHV Chemise de cylindres en fonte Détecteur de bas niveau d'huile Prises sur tableau de commande Voltage métre et competeur horaire sur tableau Commande du ralenti La tension automatique régulatrice Chargeur de batterie CordKeeper™...
DANGER : Les accumulateurs en train de recharger dégagent du gaz hydrogène DETONANT. Il doit être formellement interdit de fumer ou de produire des flammes ou des étincelles à proximité lorsque vous rechargez des accus. Servez-vous de câbles approuvés aux fins de chargement de la pile.
GARANTIE : Pièces de remplacement et service sont disponibles dans les Centres de Service de Coleman Powermate, Inc. Pour trouver votre centre de service le plus proche, composer le NUMERO GRATUIT 1-800-445-1805. Dans le cas fort improbable qu'un Centre de Service ne puisse être localisé, contacter Coleman Powermate, Inc.
CARACTERISTICAS PRINCIPALES DEL GENERADOR Motor 13 HP Honda OHV Manga de hierro fundido del cilindro El sensor del nivel bajo de aceite Receptáculos sobre el panel de control Voltaje metro y contador de horas sobre el panel Control en vacío El regulador automático del voltaje Cargador de batería CordKeeper™...
Utilice cables aprobados para cargar baterías. Conecte la grapa roja a la terminal positiva de la batería. Conecte la grapa negra a la terminal negativa de la batería. Relacionar el otro final de la gancho hilo hasta el correspondiente negro y bermeja encuadernación poste.
LO QUE ESTA CUBIERTO: Repuestos y mano de obra. LO QUE NO ESTA CUBIERTO: Los gastos de transporte a Coleman Powermate, Inc. en el caso de productos defectuosos. Los gastos de transporte al consumidor por de los productos reparados. Las escobillas, los fusibles, los pies de caucho y los receptáculos;...
PARTS LIST / LISTE DES PIÈCES / LISTA DE PIEZAS REF. PART DESCRIPTION NO. NO. Note A Engine, 13 hp Honda OHV 0050236.01 Adapter, engine 0000919.01 Bolt, wz 3/8-16 x 3/4 0049623 Rotor, 6.5 kW Note B Washer, lock 5/16 0055938 Bolt, hex 5/16-24 x 8.5 0058939...
Page 13
115 percent of the nameplate rating of the generator. Remarque A: Coleman Powermate ne fournit pas de moteurs dans ses pièces détachées. Les moteurs sont couverts par la garantie du fabricant de moteurs. Consulter le manuel du moteur inclus ou contacter notre département de service après-vente pour toute assistance.
