Page 2
CONGRATULATIONS ON YOUR PURCHASE OF THIS FINE PIONEER PRODUCT. Pioneer is on the leading edge of DVD research for consumer products and this unit incorporates the latest technological developments. We are sure you will be fully satisfied with this system.
Wood screw Protrusion: 5-7mm • If you are unsure of the qualities and strength of the walls, consult a professional for advice. • Pioneer is not responsible for any accidents or damage that result from improper installation. 5 mm 10 mm...
These labels can be found on the DVD/CD tuner rear panel and bottom panel and on the powered subwoofer rear panel. Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading the instructions, put them away in a safe place for future reference.
Thank you for buying this Pioneer product. Please read through these operating instructions so that you will know how to operate your model properly. After you have finished reading the instructions, put them in a safe place for future reference.
Before you start Chapter 1 Before you start Features DVD-Audio and SACD compatible Experience the super high-quality audio performance of DVD-Audio and Super Audio CD (SACD). The on-board 24-bit/192kHz DAC means that this player is fully compatible with high sampling-rate discs, capable of delivering exceptional sound quality in terms of dynamic range, low-level resolution and high- frequency detail.
The surround sound you get from a home theater system depends not only on the speakers you have set up in your room, but also on the source and the sound settings of the system.
Before you start DVD-R/RW and CD-R/RW discs (Audio CDs and Video CDs) recorded using a DVD recorder, CD recorder or personal computer may not be playable on this system. This may be caused by a number of possibilities, including but not limited to: the type of disc used;...
Before you start • When naming MP3 files, add the corresponding file name extension (.mp3). Files are played according to the file extension. To prevent noise and malfunctions, do not use these extensions for other kinds of files. • This player can recognize up to 999 files (MP3/JPEG) and up to 499 folders.
Controls and displays Chapter 2 Controls and displays Front panel VOLUME buttons Use to adjust the volume. Press to stop playback. Press to switch to the DVD/CD function. Also press to start/pause/resume playback. Timer indicator Lights when the wake-up timer is set (page 54). Display unit Remote sensor TIMER...
Controls and displays Display MIDNIGHT QUIET Tuner indicators Lights when a broadcast is being received. Lights when a stereo FM broadcast is being received in auto stereo mode. Lights when FM mono reception is selected. Lights when a disc is playing. MIDNIGHT Lights when the Midnight mode is selected (page 34).
Page 14
Controls and displays 14 Speaker indicators These show which speakers are being used to output the current source. The illustrations below show some example displays. 5.1 channel surround sound Stereo (2.1 channel) sound 3.1 channel sound with Dialogue enhancement on the center channel 5.1 channel surround sound with Virtual Surround Back mode active...
Controls and displays Remote control STANDBY/ON FM/AM L1/L2 TUNER LINE DISPLAY OPEN/CLOSE DVD MENU RETURN TUNE+ ST– ENTER TUNE– MUTE SOUND MASTER VOLUME TV CONTROL INPUT BASS MODE DIALOGUE VIRTUAL SB AUTO SURROUND ADVANCED PROGRAM REPEAT RANDOM AUDIO SUBTITLE ANGLE HOME ZOOM TOP MENU...
Page 16
Controls and displays MUTE Press to mute all sound from the speakers and headphones (press again to cancel) (page 36). MASTER VOLUME Use to adjust the volume. 10 TV CONTROL (page 20) Press to switch the TV on or into standby. INPUT Press to switch the TV input.
Page 17
Controls and displays HOME MENU Press to display (or exit) the on-screen menu for Initial Settings, Play Mode functions, etc. 18 (In SUB) SYSTEM SETUP Use to make various system and surround sound settings (page 57). TEST TONE Use to output the test tone (for speaker setup) (page 59).
87 if you’re not sure which one to choose. Welcome to Pioneer DVD! Thank you for purchasing this Pioneer DVD player. Before using, please take a little time to setup your DVD player Put the batteries into the remote control...
Getting started Press ENTER again to finish setting up. Let's Get Started Menu Setup complete If you're finished setting up, choose [Complete], to start again choose [Back] Complete Back • Use the (cursor right) button to select Back then press ENTER if you want to go back and change the setting you just made.
Switches the TV’s input between the built in TV tuner and an external video source. • The default setting is for a Pioneer TV. Using the Room Setup Before using your system to enjoy surround sound playback, we recommend you spend a few minutes using the Room Setup.
Getting started If the system isn’t already on, press STANDBY/ON to switch it on. Press ROOM SETUP. • If you have previously set up the room type and seating position, the display will show the current room settings. Press ENTER. Use the (cursor up/down) buttons to select a room type then press...
Getting started DISPLAY DVD MENU ENTER MUTE MASTER VOLUME TV CONTROL INPUT BASS MODE DIALOGUE AUTO SURROUND PROGRAM REPEAT AUDIO SUBTITLE ZOOM TOP MENU SYSTEM SETUP TEST TONE QUIET/ DIMMER MIDNIGHT FOLDER– MAIN Button What it does HOME Displays/exits the on-screen MENU display Changes the highlighted menu...
Getting started Press (play) to start playback. If you’re playing a DVD or Video CD/Super VCD, a menu may appear. See DVD disc menus on page 25 and Video CD/Super VCD PBC menus on page 26 for how to navigate these.
Getting started Button What it does Pauses a disc that’s playing, or restarts a paused disc. Stops playback. DVD and Video CD: The display shows Resume. Press you want to cancel the resume function. (See also Resume and Last Memory below.) Press to start fast reverse scanning.
Getting started • Resume and Last Memory are not avail- able with DVD-Audio discs. • The Last Memory function doesn’t work with VR format DVD-RW discs. • With MP3 format discs, playback does not resume. Instead, playback begins of the first track of the folder containing the file that was playing when playback was stopped.
Getting started DVD MENU ENTER MUTE MASTER VOLUME TV CONTROL INPUT BASS MODE DIALOGUE AUTO SURROUND PROGRAM REPEAT AUDIO SUBTITLE ZOOM TOP MENU SYSTEM SETUP TEST TONE QUIET/ DIMMER MIDNIGHT FOLDER– MAIN Button What it does TOP MENU Displays the ‘top menu’ of a DVD disc—this varies with the disc.
Getting started Button What it does RETURN Displays the PBC menu. Numbers Selects a numbered menu option. Displays the previous menu page (if there is one). Displays the next menu page (if there is one). ENTER Press to select highlighted menu option.
Getting started • Manual tuning: Press TUNE +/– repeatedly to change the displayed frequency. • Auto tuning: Press and hold TUNE +/– until the frequency display starts to move, then release. The tuner will stop on the next station it finds. Repeat to search for other stations.
Getting started Press SYSTEM SETUP. Use the (cursor left/right) buttons to choose ‘St. Memory?’ then press ENTER. Use the (cursor up/down) buttons to select the station preset you want. There are 30 preset locations; each can store one station preset. Press ENTER to save the station preset.
Home theater sound Chapter 4 Home theater sound Using this system you can enjoy listening to sources, analog or digital, in either stereo or surround sound. Auto listening mode The Auto listening mode is the simplest way to listen to any source as it was mastered: the output from the speakers mirrors the channels in the source material.
Home theater sound • PL II Music – Pro Logic II 5.1 channel surround sound, especially suited to music sources, for use with any two- channel source (see also Dolby Pro Logic II Music settings below) • Stereo – See Listening in stereo below •...
Home theater sound • See also Using the Advanced Surround effects below, for further stereo and surround playback options. Listening with headphones When headphones are connected, only the Stereo (default) and Phones Surround (virtual surround sound for headphones) modes are available. •...
Home theater sound • Sports – Designed for sports and other programs based on commentary • Game – Creates surround sound from video game sources • ExPwrSurr. (Extra Power Surround) – Gives additional energy and width to stereo sources • Virtual – Creates the impression of surround sound from just the front speakers •...
Home theater sound Listening with a virtual surround back speaker • Default setting: Vir. SB Off The Virtual Surround Back feature can be used when listening in surround sound to simulate an added surround back channel. In a real theater the surround back speaker would be directly behind you, creating more cohesive and realistic surround sound.
Home theater sound Adjusting the bass and treble • Default setting: Treble: 0, Bass: 0 Use the bass and treble controls to adjust the overall tone. Bass and treble adjustment is not possible when the Quiet or Midnight modes are active. DISPLAY OPEN CLOSE DVD MENU...
Home theater sound Muting the sound Use the MUTE button if you need to momentarily turn off all sound from the speakers. DVD MENU TUNE+ ST– ENTER TUNE– MUTE MUTE MASTER VOLUME • Press MUTE to mute the volume. To cancel, adjust the volume or press MUTE again.
Playing discs Chapter 5 Playing discs Introduction Most of the features described in this chapter make use of on-screen displays. For an expla- nation of how to navigate these, see Using the on-screen displays on page 21. Many of the functions covered in this chapter apply to DVD and SACD discs, Video CD/ Super VCDs, CDs and MP3/JPEG discs, although the exact operation of some varies...
Playing discs For SACD, select a track within the current playback area. Disc Navigator Track 1-14 2ch Area Track 001 Track 002 Track 003 Track 004 Track 005 Track 006 Track 007 Track 008 For a VR (Video Recording) mode DVD-RW disc select beween the Playlist and Original areas of the disc, or a title.
Playing discs To resume normal playback, press (play). • Sound can be heard while scanning audio CDs, SACD and MP3 discs. • When scanning a Video CD/Super VCD or MP3 track, playback automatically resumes at the end or beginning of the track.
Playing discs Looping a section of a disc The A-B Repeat function allows you to specify two points (A and B) within a track (CD and Video CD) or title (DVD-Video and DVD-RW) that form a loop which is played over and over. •...
Playing discs Using the OSD During playback, press HOME MENU and select ‘Play Mode’. Select ‘Repeat’ from the list of functions on the left. Play Mode A-B Repeat Title Repeat Repeat Chapter Repeat Random Repeat Off Program Search Mode Select a repeat play option. If program play is active, select Program Repeat to repeat the program list, or Repeat Off to cancel.
Playing discs Using random play Use the random play function to play titles or chapters (DVD-Video), groups or tracks (DVD- Audio), or tracks (SACD, CD, Video CD/Super VCD and MP3 discs) in a random order. You can set the random play option when a disc is playing or stopped.
Playing discs • To cancel random playback without stop- ping playback, press CLR. The disc will play to the end, then stop. • During random play, the buttons function a little differently to normal: returns to the beginning of the current track/chapter. You can't go back further than this.
Page 44
Playing discs • To add a chapter, first highlight the title, then press (cursor right) and select a chapter from the list. Program Program Step Title 1-38 01. 01-003 Title 01 Title 02 Title 03 Title 04 Title 05 Title 06 Title 07 Title 08 For a DVD-Audio disc, you can add a whole...
Page 45
Playing discs To play the program list, press (play). Program play remains active until you turn off program play (see below), erase the program list (see below), eject the disc or switch off the player or switched to a function other than DVD (CD).
Playing discs • Program Memory (DVD-Video only) – Select On to save the program list for the disc loaded. (Select Off to cancel the program memory for the disc loaded) • Program lists are saved for the DVD disc loaded. When you load a disc with a saved program list, program play is automati- cally turned on.
Playing discs Select a search mode. Use the number buttons to enter a title, group, chapter, folder or track number, or a time or a page. Play Mode A-B Repeat Title Search Repeat Chapter Search Random Time Search Program Search Mode •...
Playing discs • Press AUDIO repeatedly to select an audio language option. Current /Total Audio 1 /2 French • Some discs only allow you to change audio language from the disc menu. Press TOP MENU to access. • To set audio language preferences, see Audio Language on page 65.
Playing discs • If the navigation square at the top of the screen disappears, press ZOOM again to display it. • We do not recommend using DVD disc menus when the screen is zoomed as menu options will not be highlighted. •...
Page 50
Playing discs • CD and Video CD displays Play Current / Total Elapsed Track 2/16 1.07 Play Elapsed Disc 28.00 • (During PBC playback only.) Play • Super VCD displays Play Current / Total Elapsed Track 2/16 1.07 • MP3 disc displays Play Current / Total Elapsed...
Playing discs Display unit information Limited disc information also appears in the display unit. Press DISPLAY to change the displayed information. • DVD-Video / DVD-RW displays Title no. 8 4 9 Chapter no. Elapsed title time Title no. 2 TTL 1 0 7 0 0 Remaining title time Title no.
Viewing JPEG discs Chapter 6 Viewing JPEG discs Playing a JPEG slideshow After loading a CD/CD-R/RW containing JPEG pictures, press from the first folder/picture on the disc. The player displays the pictures in each folder in alphabetical order. Pictures are automatically adjusted so that they fill as much of the screen as possible (if the aspect ratio of the picture is different to your TV screen you may notice black bars at...
Viewing JPEG discs • When a folder is highlighted you can press ENTER to open the Photo Browser screen for that folder. See below for more on using the Photo Browser. To resume the slideshow from the highlighted file, press ENTER. Using the Photo Browser The Photo Browser displays nine thumbnail images at a time from the current folder.
Using the timer Chapter 7 Using the timer Setting the wake-up timer Use the wake-up timer to set the system to switch on at any time and start playing whatever source you want. • The clock must be set to the correct time for the wake-up timer to work properly (see Setting the clock on page 19).
Using the timer • You can check the timer settings in standby by pressing TIMER/CLOCK twice. (Press TIMER/CLOCK once to display the current time.) Turning the wake-up timer on/off If the wake-up timer is on, it will switch on the system everyday at the time you have set.
Using the timer Setting the sleep timer The sleep timer switches off the system after a specified time so you can fall asleep without worrying about it. • If you set the sleep timer while either the wake-up timer is active, the earlier switch off time takes priority.
Surround sound setup Chapter 8 Surround sound setup Setting up surround sound The Room Setup feature (page 20) is designed to give you a basic surround sound setup, however you can make the more detailed settings that may improve the surround sound in your listening room.
Page 58
Surround sound setup Front speakers distance setting Specifies the distance from your listening position to the front speakers: • Front 0.3 m ~ Front 9 m – Distance can be set in increments of 0.3 m. The default is 3 m. Center speaker distance setting Specifies the distance from your listening position to the center speaker:...
Surround sound setup Setting the channel levels You can set the relative channel levels from your main listening position for each listening mode, including all the Surround and Advanced Surround modes. If you used the Room Setup feature (page 20), the channel levels for each listening mode will already be set.
Video Adjust menu Chapter 9 Video Adjust menu Video Adjust • Default setting: Standard From the Video Adjust screen you can select the standard video presentation or define presets of your own. Press HOME MENU and select ‘Video Adjust’ from the on-screen display. HOME MENU Play Mode Initial Settings...
Page 61
Video Adjust menu You can adjust any or all of the following picture quality settings: • Contrast – Adjusts the contrast between light and dark. • Brightness – Adjusts the overall bright- ness. • Chroma Level – Adjusts how saturated colors appear.
Initial Settings menu Chapter 10 Initial Settings menu Using the Initial Settings menu The Initial Settings menu gives you complete control in setting up your DVD system, including video output settings and parental lock settings, among others. If an option is grayed out it means that it cannot be changed at the current time.
Initial Settings menu • If you set to DTS with non-DTS compatible equipment, noise will be output when you play a DTS disc. • DTS-CDs are always output as DTS digital audio regardless of this setting. Linear PCM Out • Default setting: Down Sample Off Initial Settings Digital Audio Mode Dolby Digital Out...
COMPATIBILITY WITH THIS MODEL 525p DVD PLAYER, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER. This system is compatible with the following Pioneer displays and monitors: PDP-503HDG, PDP-433HDG progressive scan-compatible TVs. STANDBY/ON to put the system (stop) button for about 8 seconds...
Initial Settings menu S-Video Out You only need to make this setting if you connected this system to your TV using an S-video cable. • Default setting: S2 Initial Settings Digital Audio Mode TV Screen Video Output Component Out Language S-Video Out Display Options...
Initial Settings menu • You can usually change or switch off the subtitles on a DVD-Video disc during playback using the SUBTITLE button. (This does not affect this setting.) See Switching subtitles on page 47. • Some DVD-Video discs set the subtitle language automatically when loaded, overriding the Subtitle Language setting.
Initial Settings menu This sets whether operation displays are shown on-screen (Play, Resume, Scan and so on). Angle Indicator • Default setting: On Initial Settings Digital Audio Mode OSD Language Video Output On Screen Display Language Angle Indicator Display Options If you prefer not to see the camera icon on- screen during multi-angle scenes on DVD discs, change this setting to Off.
Initial Settings menu Press ENTER to register the password and return to the Options menu screen. If you forget your password, you can reset the system then register a new one. See Resetting the system on page 77 for how to reset the system.
Initial Settings menu Setting/changing the Country code You may also want to refer to the Country code list on page 88. Select ‘Country Code’. Initial Settings Digital Audio Mode Parental Lock Password Change Video Output Bonus Group Level Change Language Auto Disc Menu Country Code Display...
Initial Settings menu When you play a DVD-Audio disc that has a bonus group, the key number input screen appears automatically. You can also access the same screen here. • If you eject the disc, switch the power off, or unplug the player, you will need to re- enter the key number.
Initial Settings menu • This setting reverts to DVD-Audio when the function is changed, the disc tray is opened, or the power is switched into standby. SACD Playback • Default setting: Multi-ch Area Initial Settings Digital Audio Mode Parental Lock 2ch Area Video Output Bonus Group...
Other connections Chapter 12 Other connections Connecting external antennas External AM antenna Use 5–6 meters of vinyl-insulated wire and set up either indoors or outdoors. Leave the AM loop antenna connected. Outdoor antenna Indoor antenna (vinyl-coated wire) 5–6 m External FM antenna Use a 75Ω...
Other connections • Connect the LINE 1 (IN) jacks to the analog outputs of an external playback component. These include components such as a VCR or cassette deck. Connect using RCA pin-plug stereo cables. See also Reducing the TV and line signal levels below.
Other connections Recording mode The Recording mode allows you to make analog recordings from the LINE 1 (OUT) jacks. When Recording mode is on, most sound- related functions (including SURROUND, ADVANCED, AUTO, SYSTEM SETUP) become inactive. The display will briefly blink RecMode On if you try and use a prohibited function while Recording mode is on.
Other connections Connecting using the component video output If your TV has component video inputs, you can use these instead of the standard video output to connect this system to your TV. This should give you the best quality picture from the three types of video output available.
Additional information Chapter 12 Additional information Switching off the demo • Default setting: Demo On This system has an automatic demo feature that starts when the system is plugged in for the first time. Switch the system into standby. Press SYSTEM SETUP. Use the (cursor left/right) buttons to select ‘Demo Mode?’, then...
8 seconds until the display shows ‘Mem.Clr.?’. Press the top panel The system’s settings are now reset, and you should see the ‘Welcome to Pioneer DVD !’ screen. NTSC or Dimming the display • Default setting: 3 The display has three brightness levels (1–3).
Additional information Using and taking care of discs Titles, groups, chapters and tracks DVD discs are generally divided into one or more titles. Titles may be further subdivided into chapters. Title 1 Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 1 Chapter 2 DVD-Audio discs are divided into one or more groups that can each contain a number of tracks.
This unit is designed for use with conventional, fully circular discs only. Use of shaped discs is not recommended for this product. Pioneer disclaims all liability arising in connection with the use of shaped discs.
The DVD player’s lens should not become dirty in normal use, but if for some reason it should malfunction due to dust or dirt, consult your nearest Pioneer authorized service center. Although lens cleaners are commercially available, we do not recommend using them since some may damage the lens.
A damaged power cord can cause a fire or give you an electrical shock. Check the power cord once in a while. When you find it damaged, ask your nearest Pioneer authorized service center or your dealer for a replacement.
If the trouble cannot be rectified even after exercising the checks listed below, ask your nearest Pioneer authorized service center or your dealer to carry out repair work. • If the system does not operate normally due to external effects such as static electricity disconnect the power plug from the outlet and insert again to return to normal operating conditions.
• Make sure the fan at the AMP section of the unit is not being blocked. system will not switch • Check that the speakers are connected correctly. • If the problem persists, take it to your nearest Pioneer authorized service center or your dealer for servicing. DVD/CD/Video CD player...
Additional information Problem Picture disturbance during playback or dark. Noticeable difference in DVD and CD volume. Incomplete sound from headphones when listening to a DVD- Audio disc. MP3/JPEG discs Problem CD-ROM disc is not recognized by the system. Files don’t show up in the Disc Navigator/ Photo Browser.
Additional information Tuner Problem Remedy Considerable noise in • Connect the antenna (refer to the Setup Guide). radio broadcasts. • Fully extend the FM wire antenna, position for best reception, and secure to a wall. • Connect an outdoor FM antenna (see Connecting external antennas on page 72).
Page 86
Additional information Message DVD-AUDIO SACD Desciption • Blinks rapidly when one of the below buttons is pressed while a DVD- Audio disc is loaded. ·AUTO ·SURROUND ·ADVANCED ·DIALOGUE ·VIRTUAL SB ·BASS MODE • Blinks rapidly when one of the below buttons is pressed while a SACD disc is loaded.
Additional information Screen sizes options; see the instructions that and disc came with your TV for formats details. DVD-Video discs Please note that come in several some movie aspect different screen ratios are wider than aspects, ranging from 16:9, so even though TV programs, which you have a are generally 4:3, to...
Additional information Language code list Language (Language code letter), Language code Japanese (ja), 1001 Basque (eu), 0521 English (en), 0514 Persian (fa), 0601 French (fr), 0618 Finnish (fi), 0609 German (de), 0405 Fiji (fj), 0610 Italian (it), 0920 Faroese (fo), 0615 Spanish (es), 0519 Frisian (fy), 0625 Dutch (nl), 1412...
Additional information Preset code list Please note that there are cases where only certain functions may be controllable after assigning the proper preset code, or the codes for the manufacturer in the list will not work for the model that you are using. MANUFACTURER Code(s) ACURA 644 ERRES 607...
Additional information Glossary Analog audio An electrical signal that directly represents sound. Compare this to digital audio which can be an electrical signal, but is an indirect representation of sound. See also Digital audio. Aspect ratio The width of a TV screen relative to its height. Conventional TVs are 4:3 (in other words, the screen is almost square);...
Page 92
Additional information EXIF (Exchangeable Image File) A file format developed by Fuji Photo Film for digital still cameras. Digital cameras from various manuafcturers use this compressed file format which carries date, time and thumbnail information, as well as the picture data.
Page 93
Additional information Sampling frequency The rate at which sound is measured to be turned into digital audio data. The higher the rate, the better the sound quality, but the more digital information is generated. Stan- dard CD audio has a sampling frequency of 44.1kHz, which means 44,100 samples (measurements) per second.
控制按鈕和顯示 遙控器 STANDBY/ON FM/AM L1/L2 TUNER LINE DISPLAY OPEN/CLOSE DVD MENU RETURN TUNE+ ST– ENTER TUNE– MUTE SOUND MASTER VOLUME TV CONTROL INPUT BASS MODE DIALOGUE VIRTUAL SB AUTO SURROUND ADVANCED PROGRAM REPEAT RANDOM AUDIO SUBTITLE ANGLE HOME ZOOM TOP MENU MENU SYSTEM CH LEVEL...
Page 111
控制按鈕和顯示 (副功能) ZOOM 按該按鈕改變畫面縮放比率 ( 第 48 頁 )。 TOP MENU 用於顯示播放位置處的 DVD 碟片的頂層選 單 (這可能和按下 DVD MENU 同) 。 HOME MENU 按該按鈕顯示 (或退出)初始設置,播放 模式功能等項目的螢幕顯示選單。 (副功能) SYSTEM SETUP 用於進行多種系統和環繞聲設置(第57頁) 。 TEST TONE 用於輸出測試音(設定揚聲器用)( 第 59 頁 )。 CH LEVEL 用於調節揚聲器等級 ( 第 59 頁 )。 (副功能)...
如果無法確定如何選擇,請同時參見第 87 頁 “ 屏幕尺寸和碟片格式” 。 (在遙控器或前面板 Welcome to Pioneer DVD! Thank you for purchasing this Pioneer DVD player. Before using, please take a little time to setup your DVD player Put the batteries into the remote control Next, press the [ENTER] button on the remote control...
開始使用 再次按 結束設置。 ENTER Let's Get Started Menu Setup complete If you're finished setting up, choose [Complete], to start again choose [Back] Complete Back 如果您要返回並改變先前進行的設置,請 • 使用 (右光標)按鈕選擇 。 ENTER 您 還 可 以 使 用 功 能 按 鈕 ( •...
開始使用 DISPLAY DVD MENU ENTER MUTE MASTER VOLUME TV CONTROL INPUT BASS MODE DIALOGUE AUTO SURROUND PROGRAM REPEAT AUDIO SUBTITLE ZOOM TOP MENU SYSTEM SETUP TEST TONE QUIET/ DIMMER MIDNIGHT FOLDER– MAIN 按鈕 功能 HOME 顯示 退出螢幕顯示 MENU 改變高亮選單項目 ENTER 選定高亮顯示的選單項目...
開始使用 DVD MENU ENTER MUTE MASTER VOLUME TV CONTROL INPUT BASS MODE DIALOGUE AUTO SURROUND PROGRAM REPEAT AUDIO SUBTITLE ZOOM TOP MENU SYSTEM SETUP TEST TONE QUIET/ DIMMER MIDNIGHT FOLDER– MAIN 按鈕 功能 TOP MENU 顯示 DVD 碟片的 “頂層選單” -隨碟片而異。 顯示...
開始使用 按鈕 功能 RETURN 顯示 PBC 選單。 數字按鈕 選擇數字選單項目。 顯示前一選單頁(如果有的話) 。 顯示後一選單頁(如果有的話) 。 ENTER 按下選定高亮顯示的選單項目。 收聽收音機 調諧器可以接收 FM 和 AM 廣播,並記憶您最喜 歡的電臺,從而無需每次在想要收聽時進行手 動調諧。 STANDBY/ON FM/AM L1/L2 TUNER LINE DISPLAY OPEN CLOSE DVD MENU RETURN TUNE+ ST– ENTER TUNE– MUTE SOUND MASTER VOLUME TV CONTROL...
家庭影院的聲效 第 章 家庭影院的聲效 使用該系統,您能以立體聲或環繞聲模式盡情 收聽各種模擬或數位播放源。 自動聽音模式 自動聽音模式是按操作收聽一切播放源的最 簡單方法 ,揚聲器的輸出反映了播放源資料的 各聲道狀態。 BASS MODE DIALOGUE BASS MODE AUTO AUTO SURROUND PROGRAM REPEAT AUDIO SUBTITLE ZOOM TOP MENU SYSTEM TEST TONE SETUP QUIET/ DIMMER MIDNIGHT FOLDER– MAIN 按 選擇 “ AUTO Auto •...
家庭影院的聲效 用虛擬後置環繞聲揚聲器收聽 預設狀態: Vir. SB Off • 當以環繞聲模式收聽時 ,可使用虛擬後置環繞 聲功能來模擬附加的後置環繞聲聲道 。在真正 的影院裡 ,後置環繞聲揚聲器應該位於您的正 後方,以創造更多連續而逼真的環繞聲。 BASS MODE DIALOGUE AUTO SURROUND PROGRAM REPEAT AUDIO SUBTITLE ZOOM TOP MENU SYSTEM TEST TONE SETUP QUIET/ DIMMER MIDNIGHT FOLDER– MAIN 反覆按 • VIRTUAL SB “ ”之間進行切換。...
播放碟片 使用 在碟片播放時,按 HOME MENU “ Play Mode” (播放模式) 。 從左邊的功能列表中選擇“ 複播放) 。 Play Mode A-B Repeat Title Repeat Repeat Chapter Repeat Random Repeat Off Program Search Mode 選擇重複播放選項。 如果編序播放已激活,請選擇 Repeat (編序重複)以重複播放編序列表, 或選擇 Repeat Off (重複播放關閉)以取消 重複播放。 對於DVD影碟或DVD-RW碟片 , 選擇 Chapter Repeat (標...
播放碟片 對於 MP3 碟片,請選擇 Random All 放全部) (所有文件夾)或 Random Track 機 播 放 曲 目) (僅 限 於 當 前 文 件 夾) 〔或 (隨機播放關閉) 〕。 Random Off Play Mode A-B Repeat Random All Repeat Random Track Random Random Off Program Search Mode 您也可以使用遙控器上的...
Page 138
播放碟片 在編序列表中為當前步驟選擇一個標題、 章、分組、文件夾或曲目。 對於 DVD 影碟 ,您可以將整個標題或標題內的 章添加至編序列表。 要添加標題,請選擇該標題。 • Program Program Step Title 1~38 01. 01 Title 01 Title 02 Title 03 Title 04 Title 05 Title 06 Title 07 Title 08 要添加章,先高亮顯示其所在標題,然後 • 按 (右光標)並從列表中選擇一個章。 Program Program Step Title 1-38 01.
Page 144
播放碟片 CD 和 VCD 顯示 • Play Current / Total Elapsed Track 2/16 1.07 Play Elapsed Disc 28.00 (僅在 PBC 播放過程中) • Play 超級 VCD 顯示 • Play Current / Total Elapsed Track 2/16 1.07 MP3 碟片顯示 • Play Current / Total Elapsed Track 1/17...
使用定時器 設置睡眠定時器 在規定時間後,睡眠定時器將關閉系統,這樣 您就無需擔心系統而安心入睡。 如果您在喚醒定時器開啟狀態下設置睡眠 • 定時器,則較早的關閉時刻優先進行。 STANDBY/ON FM/AM TUNER DISPLAY DVD MENU TUNE+ ST– ENTER ENTER TUNE– MUTE MASTER VOLUME TV CONTROL INPUT BASS MODE DIALOGUE AUTO SURROUND PROGRAM REPEAT AUDIO SUBTITLE ZOOM TOP MENU SYSTEM SETUP TEST TONE QUIET/ DIMMER MIDNIGHT...
環繞聲設定 第 章 環繞聲設定 設定環繞聲 房間設定功能 (第 20 頁)設計用於帶給您一 個基本的環繞聲設定,但是您仍可以進行更詳 細的設置,以改善您收聽房間內的環繞聲。 STANDBY/ON FM/AM L1/L2 TUNER LINE DISPLAY OPEN CLOSE DVD MENU RETURN TUNE+ ST– ENTER ENTER TUNE– MUTE SOUND MASTER VOLUME TV CONTROL INPUT BASS MODE DIALOGUE VIRTUAL SB AUTO SURROUND ADVANCED PROGRAM...
Page 152
環繞聲設定 前置揚聲器距離設置 指定從您的收聽位置到前置揚聲器的距離: • Front 0.3 m ∼ Front 9 m 增量進行距離設置。預設狀態為 3 m。 中置揚聲器距離設置 指定從您的收聽位置到中置揚聲器的距離: • Center 0.3 m Center 9 m ∼ 為增量進行距離設置。預設狀態為 3 m。 環繞聲揚聲器距離設置 指定從您的收聽位置到前置揚聲器的距離: • Surr. 0.3 m ∼ Surr. 9 m 增量進行距離設置。預設狀態為 3 m。 動態範圍控制...
環繞聲設定 設置聲道等級 您可以為各收聽模式設置與您的主要收聽位 置相關的聲道等級 ,其中包括所有的環繞聲以 及高級環繞聲模式。 如果您使用房間設定功能 (第 20 頁) ,則各 收聽模式的聲道等級將隨即被設置。但是, 您 仍可以按需要對各等級進行微調。 STANDBY/ON FM/AM L1/L2 TUNER LINE DISPLAY OPEN CLOSE DVD MENU RETURN ENTER MUTE SOUND MASTER VOLUME TV CONTROL INPUT BASS MODE DIALOGUE VIRTUAL SB AUTO SURROUND SURROUND ADVANCED PROGRAM...
初始設置 (Initial Settings) 如果所連接的設備具有內置式 DTS 解碼器,請 將本設定設為 DTS,否則設為 DTS>PCM。如 果您不確定該設備是否為 DTS 兼容,請查看隨 該設備附帶的手冊。 如果對於非DTS兼容設備 , 您將本設定設為 • 了 ,則當您播放 DTS 碟片時將輸出噪 音。 無論本設定為何 ,DTS-CD始終輸出DTS數位 • 音頻。 Linear PCM Out (線性 Down Sample Off • 預設狀態︰ Initial Settings Digital Audio Mode Dolby Digital Out Down Sample On Video Output...
初始設置 (Initial Settings) ( 視頻輸出) S-Video Out 僅當本系統用 S 視頻電纜與您的電視機連接 時,才需要進行這項設置。 預設狀態︰ • Initial Settings Digital Audio Mode TV Screen Video Output Component Out Language S-Video Out Display Options 如果您發現在預設狀態 • 或扭曲,請嘗試將設置改為 (語言設 Language settings 置) Audio Language (伴音語言) 預設狀態︰ English •...
初始設置 (Initial Settings) 您可以在播放過程中用 • 變或關閉 DVD 影碟上的字幕。 (這不影響 本設置。)請參見第 47 頁 “ 切換字幕” 。 一些 DVD 影碟在裝入時會忽略 • (字幕語言)設置,自動設定 Language 字幕語言。 帶有兩種以上字幕語言的碟片一般可從碟 • 片選單選擇字幕語言。要進入碟片選單, 請按 DVD MENU 按鈕。 DVD Menu Language 言) 預設狀態︰ • w/Subtitle Lang. Initial Settings Digital Audio Mode Audio Language Video Output Subtitle Language...
初始設置 (Initial Settings) 設置 改變國家代碼 您可能需要參見第 88 頁 “ 國家 ( 地區 ) 代 碼列表” 。 選定 “ Country Code”(國家代碼) 。 Initial Settings Digital Audio Mode Parental Lock Password Change Video Output Bonus Group Level Change Language Auto Disc Menu Country Code Display Group Playback...
初始設置 (Initial Settings) 當您播放具有附送類的 DVD 唱碟時,密碼輸入 畫面將自動顯示。您也可以在此處進入該畫 面。 如果您退出碟片、關閉電源或拔下播放機 • 的電源線,則需要重新輸入密碼。 Auto Disc Menu (自動碟片選單) 預設狀態︰ • Initial Settings Digital Audio Mode Parental Lock Video Output Bonus Group Language Auto Disc Menu Display Group Playback Options DVD Playback Mode SACD Playback Photo Viewer 該設定指定碟片裝入後選單...
