Pioneer PDP-501MX Technical Manual

Plasma display / table-top stand / speaker system
Hide thumbs Also See for PDP-501MX:
Table of Contents

Advertisement

Quick Links

See also: Field Service Manual , Service Manual
TECHNICAL MANUAL
PLASMA DISPLAY : PDP-501MX/PDP-V501X
TABLE-TOP STAND: PDK-5001
SPEAKER SYSTEM: PDP-S02-LR
This manual provides precautions and information for installation, preparation, and handling of the plasma display and
its dedicated mounting hardware.
Before installation and preparation work, choose a safe and appropriate site after thorough consideration of construction,
materials used, strength, and surroundings. If the adequate safeguards are not in place, immediately halt the installation
process and discontinue marketing activities.
CAUTION
Exclamation marks placed within triangles are
intended to alert users to the presence of important
safety information. Be sure to read instructions
indicated by this symbol.
About Mounting/Installation
• The product is sold under the assumption that in-
stallation will be performed by experienced, quali-
fied experts. Refer all mounting and installation work
to qualified personnel, or consult the nearest
PIONEER dealer for assistance.
• We accept no responsibility for accident or loss re-
sulting from failure to select an appropriate installa-
tion site, or for those occurring during assembly, in-
stallation, mounting, or operation of this product, or
resulting from modifications made to the product,
or from natural calamities.
PRECAUTIONS
• We accept no responsibility for losses resulting from
the use of parts other than those supplied by us.
• We guarantee the performance of our products only
when they are assembled and adjusted as described in
this manual.
• The specifications and external designs shown in this
manual are subject to change without notice.
(Ver.1.1A)
