Panasonic WJ-HD716 Brochure

Panasonic digital disk recorder product brochure.
WJ-HD716
H.264 High Picture Quality encoding with 16ch Real-time recording,
HDMI Full HD display and SD5Link
Key Features
• H.264 (High profile) codec with "UniPhier
System LSI platform provides high quality and high compression
encoding simultaneously.
• 16 analog video inputs including 16 (WJ-HD716) / 8 (WJ-HD616)
Panasonic coax. camera control inputs and 4 audio inputs
• Real-time recording (WJ-HD716 only):
480/400 ips (Field), 240/200 ips (Frame) (NTSC/PAL)
* WJ-HD616 features Field 240/200 ips and Frame 120/100 ips (NTSC/PAL)
• Live/Playback monitor out (HDMI, BNC) and Live monitor out (HDMI, BNC)
• 2x HDMI interfaces supporting dual 1080i (1,920 x 1,080) display
• Up to 960/800 ips at 16ch 2x monitors real-time live (NTSC/PAL)
• Various Display Modes: 4 / 7 / 8 / 9 / 12 / 16 split screen display
• SD5Link (Super Dynamic 5 Link) capability with i-VMD (intelligent-
Video Motion Detection) alarm provides disk saving and easy search.
• Up to 5 recorders can be integrated in cascade connection mode for
up to 80 cameras.
• Equipped with 4 HDD slots accessible from front panel
• DVD drive (optional) and SD/SDHC memory card slot for easy copy
of recorded image data
• HDD capacity is expandable up to 31 HDDs (4 HDD slots in the
main unit and 3 optional WJ-HDE400 Hard Disk Extension Units
each with 9 HDD slots).
• RAID5/6 redundant recording with optional WJ-HDB601 RAID Board
• Up to 4 optional WV-CU650 system controllers can be connected by PS
• Easy operation with GUI and USB mouse
16ch Real-time H.264 Digital Disk Recorder
®
" Panasonic's proprietary
Data.
WJ-HD716
16ch H.264 Digital Disk Recorder
WJ-HD616
WJ-HD716
(120 V AC)
WJ-HD616
(120 V AC)
• Remote monitoring available from Internet Explorer
• H.264 image transfer at QVGA resolution for narrow network bandwidth
• Setup data of WJ-HD716/WJ-HD616 can be downloaded and
uploaded with SD/SDHC memory card.
• User/Host authentication (Up to 32 user registrations)
• Up to 8 users can operate via network simultaneously.
• Excellent maintenance capability: Front HDD exchangeability, Front
maintenance network port
Standard Accessories
• CD-ROM* ...................................... 1 pc.
• Installation Guide .......................... 1 pc.
• Quick Reference Guide................. 1 pc.
* The CD-ROM contains the operating instructions (PDFs)
and other manuals.
The following are for installation:
• Power Cord (NTSC model) ........... 1 pc.
• Power Cord (PAL model) ............ 2 pcs.
Optional Accessories
HDD Canister
Hard Disk Extension Unit
WJ-HDU40K
WJ-HDE400
RAID Board
WJ-HDB601
Built-in DVD Drive
WJ-HDB611
WJ-HD716
(220 ~ 240 V AC)
WJ-HD616
(220 ~ 240 V AC)
TM
®
and WV-ASM100
• Rack Mount Bracket ................... 2 pcs.
• Screw for Rack Mount Bracket ... 6 pcs.
• Rack Handle ............................... 2 pcs.
• Screw for Rack Handle ............... 4 pcs.
• Washer ....................................... 4 pcs.
• HDD Canister................................ 1 pc.
• HDD Fixing Screw for HDD Canister... 6 pcs.
i-Pro Management Software
WV-ASM100
