01
DVD Player
DV-686A-s
Operating Instructions
1
En

Advertisement

Table of Contents
loading

Summary of Contents for Pioneer DV-686A-s

  • Page 1 DVD Player DV-686A-s Operating Instructions...
  • Page 2: Operating Environment

    IMPORTANT The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 3 POWER-CORD CAUTION Handle the power cord by the plug. Do not pull out the plug by tugging the cord and never touch the power cord when your hands are wet as this could cause a short circuit or electric shock. Do not place the unit, a piece of furniture, etc., on the power cord, or pinch the cord.
  • Page 4: Table Of Contents

    Contents Contents 01 Before you start Features ......5 What’s in the box ....6 Hints on installation .
  • Page 5: Before You Start

    Before you start Chapter 1 Before you start Features • DVD-Audio and SACD compatible Experience the super high-quality audio perfor- mance of DVD-Audio and Super Audio CD (SACD). • Super VCD compatible This player supports the IEC’s Super VCD stan- dard.
  • Page 6: What's In The Box

    Before you start What’s in the box Please confirm that the following accessories are in the box when you open it. • Remote control • AA/R6P dry cell batteries x2 • Audio/video cable (red/white/yellow plugs) • Power cable (Singapore and Taiwan model •...
  • Page 7: Disc / Content Format Playback Compatibility

    Before you start • Place on an unstable surface, or one that is not large enough to support all four of the unit’s feet. Disc / content format playback compatibility This player is compatible with a wide range of disc types (media) and formats. Playable discs will generally feature one of the following logos on the disc and/or disc packaging.
  • Page 8: Compressed Audio Compatibility

    Before you start Compressed audio compatibility • Compatible formats: MPEG-1 Audio Layer 3 (MP3), Windows Media Audio (WMA) • Sampling rates: 32, 44.1 or 48kHz • Bit-rates: Any (128Kbps or higher recommended) • VBR (variable bit rate) MP3 playback: No •...
  • Page 9: Divx Video Compatibility

    Before you start • The number of external subtitle files which can be switched for the same movie file is limited to a maximum of 10. DivX video compatibility ® • Official DivX Certified product. ® ® • Plays DivX 5, DivX 4, DivX VOD video content (in compliance with...
  • Page 10: Connecting Up

    Connecting up Chapter 2 Connecting up Easy connections The setup described here is a basic setup that allows you to play discs using just the cables supplied with the player. In this setup, stereo audio is played through the speakers in your TV. A/V IN White AUDIO OUT...
  • Page 11: Connecting Using The S-Video Output

    Connecting up Connect the VIDEO OUT and AUDIO OUT (2ch) jacks to a set of A/V inputs on your TV. Use the supplied audio/video cable, connecting the red and white plugs to the audio outputs and the yellow plug to the video output.
  • Page 12 Connecting up Watching progressive scan video from the component video outputs This player can output progressive scan video from the component video output. Compared to interlace video, progressive scan video effectively doubles the scanning rate of the picture, resulting in a very stable, flicker-free image.
  • Page 13: Connecting To An Av Receiver

    S-Video or component video connections if they’re avail- able. • You usually have to connect the same kind of video cable between your DVD player and AV receiver, and between your AV receiver and TV. Connecting the multichannel analog outputs If your AV receiver has 5.1 channel analog...
  • Page 14: Connecting The Digital Output

    Connecting up Connecting the digital output This player has both optical and coaxial-type digital audio outputs for connection to an AV receiver. Connect whichever is convenient. Depending on the capabilities of your AV receiver, you might have to set up this player to output only digital audio in a compatible format.
  • Page 15: Controls And Displays

    Controls and displays Chapter 3 Controls and displays Front panel STANDBY/ON (page 17) (page 20, 22) (page 20) (page 20) (page 20) RW Compatible (page 7) HOME MENU (page 17) RETURN (page 21) MENU (page 21) 10 ENTER & cursor buttons (page 17) 11 TOP MENU (page 21) 12 Display OPEN/CLOSE (page 19)
  • Page 16: Remote Control

    Controls and displays Remote control STANDBY/ON AUDIO SUBTITLE TOP MENU ENTER HOME MENU PLAY MODE SURROUND ZOOM STANDBY/ON (page 17) AUDIO (page 30) SUBTITLE (page 30) Number buttons (page 20) TOP MENU (page 21) ENTER & cursor buttons (page 17) HOME MENU (page 17) (page 20, 23) (page 20)
  • Page 17: Getting Started

    STANDBY/ON on the front panel or remote control to switch the player on. Also, switch on your TV and make sure that it is set to the input you connected the DVD player STANDBY/ON • My DVD player switches on but there is nothing displayed on my TV.
  • Page 18: Setting Up The Player For Your Tv

    Getting started Note • From here on in this manual, the word ‘select’ generally means use the cursor buttons to highlight an item on-screen, then press ENTER. Setting up the player for your If you have a widescreen (16:9) TV, you should setup the player so that the picture will be presented correctly.
  • Page 19: Playing Discs

    Getting started Playing discs The basic playback controls for playing DVD, CD, SACD, Video CD/Super VCD, DivX video and MP3/WMA discs are covered here. Further functions are detailed in the next chapter. For details on playing JPEG picture discs, see Viewing a JPEG slideshow on page 24.
  • Page 20: Basic Playback Controls

    Getting started Basic playback controls The table below shows the basic controls on the remote for playing discs. The following chapter covers other playback features in more detail. Button What it does Starts playback. If the display shows RESUME or LAST MEM playback starts from the resume or last memory point (see also Resume and Last Memory...
  • Page 21 Getting started • If you don’t need the Last Memory function when you stop a disc, you can press OPEN/CLOSE to stop playback and open the disc tray. DVD disc menus Many DVD-Video and DVD-Audio discs feature menus from which you can select what you want to watch.
  • Page 22 Getting started Button What it does Displays the previous menu page (if there is one). Displays the next menu page (if there is one). • After I load a DVD disc, it ejects automatically after a few seconds! Most likely, the disc is the wrong region for your player.
  • Page 23: Playing Discs

    Playing discs Chapter 5 Playing discs Note • Many of the functions covered in this chapter apply to DVD and SACD discs, Video CDs/Super VCDs, CDs, DivX video and WMA/MP3 JPEG discs, although the exact operation of some varies slightly with the kind of disc loaded.
  • Page 24: Frame Advance/Frame Reverse

    Playing discs Frame advance/frame reverse You can advance or back up DVD-Video and DVD-R/RW discs frame-by-frame. With Video CD/Super VCDs and DivX video file you can only use frame advance. During playback, press Press advance a frame at a time. To resume normal playback, press (play).
  • Page 25: Browsing Wma, Mp3, Divx Video And Jpeg Files With The Disc Navigator

    Playing discs Select a view option. Disc Navigator Title Chapter The options available depend on the kind of disc loaded and whether the disc is playing or not, but include: • Title – Titles from a DVD-Video disc. • Chapter – Chapters from the current title of a DVD-Video disc.
  • Page 26: Looping A Section Of A Disc

    Playing discs • When a JPEG file is highlighted, a thumbnail image is displayed on the right. 00:00/ 00:00 0kbps Folder 2 File1 File2 File3 File4 File5 To play the highlighted track or DivX video file or display the highlighted JPEG file, press ENTER.
  • Page 27: Using Repeat Play

    Playing discs Using repeat play There are various repeat play options, depending on the kind of disc loaded. It’s also possible to use repeat play together with program play to repeat the tracks/chapters in the program list (see Creating a program list on page 28).
  • Page 28: Creating A Program List

    Playing discs Select a random play option. The random play options available depend on the kind of disc loaded. For example, for DVD- Video discs, you can select Random Title or Random Chapter (or Random Off). Play Mode A-B Repeat Random Title Repeat Random Chapter...
  • Page 29: Searching A Disc

    Playing discs After pressing ENTER to select the title/ chapter/group/track, the step number automatically moves down one. Repeat step 3 to build up a program list. A program list can contain up to 24 titles/ chapters/tracks. • You can insert steps into the middle of a program list by just highlighting the position where you want the new step to appear and entering a title/chapter/group/...
  • Page 30: Switching Subtitles

    Playing discs • Some DVD-Audio discs feature pages of browsable pictures. Enter the page number you want. Press ENTER to start playback. Switching subtitles Some DVD-Video and DivX video discs have subtitles in one or more languages; the disc box will usually tell you which subtitle languages are available.
  • Page 31: Zooming The Screen

    Playing discs Zooming the screen Using the zoom feature you can magnify a part of the screen by a factor of 2 or 4, while watching a DVD, DivX video title or Video CD/ Super VCD or playing a JPEG disc. During playback, use the ZOOM button to select the zoom factor (Normal, 2x or 4x).
  • Page 32: Audio Settings And Video Adjust Menus

    Audio Settings and Video Adjust menus Chapter 6 Audio Settings and Video Adjust menus Audio Settings menu The Audio Settings menu offers features for adjusting the way discs sound. Press HOME MENU and select ‘Audio Settings’ from the on-screen display. Audio Settings Select and change settings using the (cursor) buttons, and ENTER.
  • Page 33: Video Adjust Menu

    Audio Settings and Video Adjust menus • If the player is outputting Dolby Digital, DTS or MPEG bitstream audio (in other words, no conversion to PCM), Virtual Surround has no effect on the audio from the digital output. See Digital Audio Out settings on page 34 for how to set up the digital output formats.
  • Page 34: Initial Settings Menu

    Initial Settings menu Chapter 7 Initial Settings menu Using the Initial Settings menu The Initial Settings menu provides audio and video output settings, parental lock settings, and display settings, among others. If an option is grayed out it means that it cannot be changed at the current time.
  • Page 35: Video Output Settings

    Initial Settings menu Setting Option Linear PCM Out Down Sample On Down Sample Off MPEG Out MPEG > PCM MPEG Video Output settings Setting Option TV Screen 4:3 (Letter Box) (See also Screen sizes and disc formats on 4:3 (Pan & Scan) page 45.) 16:9 (Wide) Component Out...
  • Page 36: Display Settings

    Initial Settings menu Setting Option Subtitle Language English (See also Displaying DivX subtitle files on Languages as displayed page 8.) Other Language DVD Menu w/Subtitle Lang. Language Languages as displayed Other Language Subtitle Display Display settings Setting Option OSD Language English Languages as displayed Angle Indicator...
  • Page 37: Parental Lock

    Default Country/Area code: us (2119) To give you some control over what your children watch on your DVD player, some DVD- Video discs feature a Parental Lock level. If your player is set to a lower level than the disc, the disc won’t play.
  • Page 38: Dts Downmix

    Initial Settings menu Setting/changing the Parental Lock Select ‘Level Change’. Use number buttons to enter your password, then press ENTER. Select a new level and press ENTER. • Press (cursor left) repeatedly to lock more levels (more discs will require the password);...
  • Page 39: Playing Divx Vod Content

    Initial Settings menu • Resetting the player (as described in Resetting the player in the main Operating Instructions) will not cause you to lose your registration code. Displaying your DivX VOD registration code Press HOME MENU and select ‘Initial Settings’. Select ‘Options’, then ‘DivX VOD’.
  • Page 40: Speakers Settings

    Initial Settings menu Speakers settings Setting Option Audio Output 2 Channel Mode 5.1 Channel Speaker – Installation Speaker Distance – Audio Output Mode • Default setting: 2 Channel Initial Settings Digital Audio Out Audio Output Mode Video Output Speaker Distance Language Speaker Installation Display...
  • Page 41: About The Audio Output Settings

    Initial Settings menu About the audio output settings The table below shows how the audio settings you make in the Initial Settings menu (see page 34) affect the output from the 2 channel and the 5.1 channel analog outputs, and from the digital outputs with various types of disc.
  • Page 42: Speaker Distance

    Initial Settings menu Speaker Distance • Default settings: all speakers 3.0 m You only need to make this setting if you connected this player to your amplifier using the 5.1 channel analog outputs. These settings do not affect any digital audio output.
  • Page 43: Speaker Installation

    Initial Settings menu Speaker Installation • Default settings: L/R: Large | C: Large | SL/ SR: Large| SW: On You only need to make this setting if you connected this player to your amplifier using the 5.1 channel analog outputs. This setting does not affect digital audio output.
  • Page 44: Additional Information

    Additional information Chapter 8 Additional information Taking care of your player and discs General Hold discs by the edge or by the center hole and edge. When you're not using a disc, return it to its case and store upright. Avoid leaving discs in excessively cold, humid, or hot environments (including under direct sunlight).
  • Page 45: Screen Sizes And Disc Formats

    Cleaning the pickup lens The DVD player’s lens should not become dirty in normal use, but if for some reason it should malfunction due to dust or dirt, consult your nearest Pioneer-authorized service center.
  • Page 46: Setting The Tv System

    All DVD-Video discs carry a region mark on the case somewhere that indicates which region(s) of the world the disc is compatible with. Your DVD player also has a region mark, which you can find on the rear panel. Discs from incompatible regions will not play in this player.
  • Page 47: Selecting Languages Using The Language

    Additional information Selecting languages using the language code list Some of the language options (such as ‘DVD Language’ in the Setup Navigator) allow you to set your preferred language from any of the 136 languages listed in the language code list on page 48.
  • Page 48: Language Code List

    Additional information Language code list Language (Language code letter), Language code Japanese (ja), 1001 English (en), 0514 French (fr), 0618 German (de), 0405 Italian (it), 0920 Spanish (es), 0519 Chinese (zh), 2608 Dutch (nl), 1412 Portuguese (pt), 1620 Swedish (sv), 1922 Russian (ru), 1821 Korean (ko), 1115 Greek (el), 0512...
  • Page 49: Troubleshooting

    Additional information Troubleshooting Incorrect operation is often mistaken for trouble or malfunction. If you think that there is something wrong with this component, check the points below. Sometimes the trouble may lie in another component. Inspect the other components and electrical appliances being used. If the trouble cannot be rectified after checking the items below, ask your nearest Pioneer authorized service center or your dealer to carry out repair work.
  • Page 50 Additional information Problem No picture/No color. Screen is stretched or aspect does not change. Picture disturbance during playback or the picture is dark. No audio, or audio is distorted. The analog audio is OK, but there appears to be no digital audio signal. Noticeable difference in DVD and CD volume.
  • Page 51 Additional information Problem Remedy Cannot play multi- • Make sure that Audio Output Mode is set to 5.1 Channel channel audio (page 40). • Check that the Dolby Digital, DTS and MPEG Out settings (pages 34–35) are suitable for your amplifier/receiver—check the instruction manual that came with your amplifier/receiver.
  • Page 52: Glossary

    Additional information Note • Static electricity or other external influences may cause malfunctioning of this unit. In this case, unplug the power cord and then plug back in. This will usually reset the unit for proper operation. If this does not correct the problem, please consult your nearest Pioneer service center.
  • Page 53 Additional information Progressive All the lines that make up a video scan video picture are updated in one pass (compared to interlace which takes two passes to update the whole picture). Regions These associate DVD-Video discs and (DVD-Video players with particular areas of the only) world.
  • Page 54: Specifications

    Specifications General System ......DVD player Power requirements Australia model..AC 220–240 V, 50/60 Hz Other models .
  • Page 55 J2G60901A SH 05/05 PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O. BOX 1540, Long Beach, California 90810-1540, U.S.A. TEL: (800) 421-1404 PIONEER ELECTRONICS OF CANADA, INC. 300 Allstate Parkway, Markham, Ontario L3R OP2, Canada TEL: 1-877-283-5901 PIONEER EUROPE NV Haven 1087, Keetberglaan 1, B-9120 Melsele, Belgium TEL: 03/570.05.11 PIONEER ELECTRONICS ASIACENTRE PTE.
