All Purpose Steam Wand
STEAM100
User's
Guide
Important!
Read all instructions carefully, and keep for future reference.
STEAM-IT

Summary of Contents

  • Page 1

    All Purpose Steam Wand STEAM100 User’s Guide Important! Read all instructions carefully, and keep for future reference. STEAM-IT ™...

  • Page 2: Table Of Contents

    This state of the art steam wand will help you have a cleaner, healthier home. At Oreck, we understand that our customers are unique and expect superior service. To meet your needs, we offer different customer service options to work with your lifestyle and preferences.

  • Page 3

    General Warnings Safety IMPORTANT SAFETY INSTRUCTIONS! When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS STEAM CLEANER WARNING! To reduce the risk of fire, electric shock, or injury: • Do not leave the steam cleaner unattended when plugged in. Unplug it from the socket when not in use.

  • Page 4

    General Warnings Safety IMPORTANT SAFETY INSTRUCTIONS! • Do not touch any hot areas on the steam cleaner. It is normal for the steam cleaner to heat up during operation. • Do not use the steam cleaner to treat any item of clothing while being worn on the body.

  • Page 5: Parts, Product Components & Accessories

    Product Components & Accessories Parts Parts 1 Steam Regulator 2 Control Switches 3 Water Tank Cap 4 Water Tank 5 Lock Button 6 Powerhead 7 Towel Grips 8 Brush Slides 9 Cord Wrap 10 Lower Handle 11 Power Cord Accessories 12 Cord Dump 13 Squeegee 14 Utility Tool...

  • Page 6: Operation, Operating Instructions, Using The Steam-it

    Operating Instructions Operation 1. Place the steam cleaner in a 2. Insert the power plug into an 3. Press the ON/OFF switch located 4. Press the steam switch to the “ON” position. After approximately 5. Turn the steam regulator control to maximum and point the steam NOTE: Ensure the steam switch is turned off and the powerhead has cooled before connecting the powerhead or any of the other cleaning accessories.

  • Page 7: Cleaning Surface/steam Setting Reference, Carpet Cleaning, For Large Carpeted Areas

    Operation Cleaning Surface/Steam Setting Reference C C l l e e a a n n i i n n g g S S u u r r f f a a c c e e Carpet & Rugs Glass & Mirrors Grout on Hard Surfaces Tiled Surfaces,...

  • Page 8: Stubborn Stains, Carpet Pile Rejuvenation, Hard Floor Cleaning, Attaching An Accessory

    Operation Stubborn Stains For removing stubborn stains or embedded grime on hard surfaces, fold and attach the cloth leaving the brushes underneath the powerhead visible. Move the brush sliders so that the brushes appear underneath the power- head. Move the brushes backwards and forwards over the selected area.

  • Page 9

    Operation Squeegee For cleaning glass and mirror panels. Use the squeegee at a very low steam flow. Achieve this by adjusting the steam regulator. A cloth can be used to wipe the blade and remove excess water during usage when cool. For small window panels, remove the squeegee tool and spray the steam directly onto the surface.

  • Page 10: Maintenance, After Each Use, Cleaning The Steam Generator, Unblocking The Steam Outlet, Cleaning The Cloth

    4. Insert the steam nozzle back into the chamber and turn it clockwise to lock back into position. NOTE: Oreck recommends cleaning the chamber at least after every 12 - 15 uses to ensure optimum performance. Unblocking the Steam Outlet If steam flow appears reduced, the steam nozzle may be blocked.

  • Page 11: Troubleshooting

    If the following troubleshooting tips do not resolve the problem please contact Trouble- Oreck Customer Service. U.S.: 1-800-989-3535 Canada: 1-888-676-7325 shooting IMPORTANT! Always unplug and allow the steam cleaner to cool down before conducting any troubleshooting. See safety warnings. P P r r o o b b l l e e m m...

  • Page 12: Warranty

    “AS IS,” which means Oreck grants you no warranty, and that you, not Oreck, assume the entire risk of the quality and performance of this product, including the entire cost of any necessary servicing or repairs of any defects.
