Aube Technologies TH110A-SP-P Installation Manual

Aube technologies thermostat installation guide.


MODEL TH110A-SP-P (120 V)
SUMMARY
u
OPTIONS SELECTION
At the back of the thermostat, there are three selection switches to set at
your preferences.
Temperature in °C or °F, time in 12 or 24 hours and Early Start function.
u
TO SET TIME AND DAY
Press on DAY, HOUR and MIN buttons to adjust time and day.
u
TO RECORD THE
(COMFORT) SETPOINT TEMPERATURE
Select chosen setpoint temperature by using
button (2 to 3 seconds) until icon appears on display.
u
TO RECORD THE
(ECONOMY) SETPOINT TEMPERATURE
Select chosen setpoint temperature by using
Press on
button (2 to 3 seconds) until icon appears on display .
u
TO RECORD THE
(VACATION) SETPOINT TEMPERATURE
To program the Vacation temperature, select the desired degree using the
buttons and press on the
until the
icon is displayed (app. 3 seconds).
u
OPERATING MODES
To select an operating mode, use MODE button.
AUTO:
Runs the program.
and can override temporarily your programming up to the
next program.
MAN:
Maintains the selected temperature.
the temperature setting.
or
button. Press on
or
button.
and
buttons simultaneously
or
shows temperature setting
or
changes
INSTALLATION
NOTE : The "Problems and Solutions" section at the end of this user's guide will
help you to correct your problems during the installation.
This thermostat has been designed to operate with any installation
which has a RESISTIVE load not exceeding 2400 W (20 A) @ 120 VAC
such as electric baseboards, radiant ceilings and floors, electric con-
vectors, etc. It is not compatible with a low voltage controller used by
a central heating system.
Electricians or experienced technicians should install the thermostat.
This thermostat is designed to be used with a self-protected heating
system equipped with thermal cut off and circuit breaker.
PARTS INCLUDED
- One (1) TH110A-SP-P (120 VAC) thermostat
- Two (2) 6-32 screws
- Four (4) solderless connectors (for copper wire)
TURN OFF POWER OF THE HEATING SYSTEM AT THE MAIN POWER
PANEL TO AVOID ELECTRICAL SHOCK. Keep air vents of the thermostat
clean and free from obstructions.
1) Connecting wires and mounting thermostat
Connect the rear thermostat wires to the 120 V LINE and to the load using
solderless connectors for copper wires. See schematic diagram.
Push the excess wire back into the electrical box to prevent interference with the
thermostat. Secure the thermostat using two (2) 6-32 screws. Once the
thermostat is properly installed, return power to heating system.
SUPPLY
BEFORE
OLD
THERMOSTAT
BLACK
BLACK
WHITE
BLACK
BLACK
LOAD
NOTE : All cables and connections must conform to the local electrical code.
WARNING: Special CO/ALR solderless connectors must be used when
connecting with aluminum conductors.
Power-up
Set the On/Stand by switch to On.
When power is applied for the first time, the
2400 W (NI) @ 120 Vca
display must show the time 00:00, the room
temperature and the Manual mode icon (
Other information might show up on the display if
installation is defective or does not comply with the
instructions.
NOTE : The On/Stand by switch set to Stand by
AFTER
120 V LINE
B
W
120 VAC
B
B
W
W
60 HZ
W
B
LOAD
will place the thermostat in sleep mode.
Ideal for summertime.
920-110-001-00-1-B
).
1/3
