HIROSHIMA, JAPAN Important Notes About This Manual Keep this manual in the glove box as a handy reference for the safe and enjoyable use of your Mazda. Should you resell the vehicle, leave this manual with it for the next owner.
Table of Contents Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Essential Safety Equipment Use of safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Knowing Your Mazda Explanation of basic operations and controls; opening/closing and adjustment of various parts.
Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Interior Overview ................1-2 Interior Equipment (View A) ............ 1-2 Interior Equipment (View B) ............ 1-3 Interior Equipment (View C) ............ 1-4 Exterior Overview ................. 1-5 Front ..................
Your Vehicle at a Glance Interior Overview Interior Equipment (View B) Audio control switches ..................page 6-63 SRS air bags ...................... page 2-51 Cruise control switches ..................page 5-19 Information display ..................page 6-184 Climate control system ..................page 6-2 Hazard warning flasher switch ................
Your Vehicle at a Glance Interior Overview Interior Equipment (View C) Overhead lights ....................page 6-182 SRS air bags ...................... page 2-51 Seat belt ......................page 2-19 Rear entertainment system ................. page 6-70 Center console ....................page 6-192 Remote fuel-filler lid release ................page 3-48 Cup holders ......................
Your Vehicle at a Glance Exterior Overview Front Hood ........................page 3-49 Windshield wiper blades ..................page 8-27 Moonroof ......................page 3-50 Door lock ......................page 3-30 Fuel-filler lid ...................... page 3-47 Tires ........................page 8-33 Light bulbs ......................page 8-37 The equipment and installation position varies by vehicle...
Essential Safety Equipment Use of safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Seats ....................2-2 Front Seats (Manually Operated Seats) ........2-2 Front Seats (Electrically Operated Seats) ........2-4 Second-Row Seats ..............2-9 Third-Row Seat ............... 2-13 Head Restraints ...............
Page 12
Adjust the driver's seat only when the result in serious injury. Consult an vehicle is stopped: Authorized Mazda Dealer if there is Adjusting the driver's seat while the any need to remove or reinstall the vehicle is moving is dangerous. The front seats.
Page 13
Essential Safety Equipment Seats qSeat Recline Do not drive with the seatback unlocked: WARNING All of the seatbacks play an important role in your protection in a Do not drive with either front seat vehicle. Leaving the seatback reclined: unlocked is dangerous as it can allow Sitting in a reclined position while the passengers to be ejected or thrown vehicle is moving is dangerous...
Page 14
Consult an Authorized Mazda Dealer if there is any need to remove or reinstall the front seats. Down Do not drive with damaged front seats: Driving with damaged front seats is dangerous.
Page 15
Essential Safety Equipment Seats qSeat Recline CAUTION WARNING Ø The seat-bottom power adjustment is operated by motors. Do not drive with either front seat Avoid extended operation because reclined: excessive use can damage the Sitting in a reclined position while the motors.
Page 16
Essential Safety Equipment Seats í qSeat Position Memory To change the seatback angle, press the front or rear side of the reclining switch. The driver's seat position memory Release the switch at the desired position. function allows you to program a desired seat position.
Page 17
Essential Safety Equipment Seats 2. Press the set switch followed by one of Activating the seat position when the programming buttons (1 3) within unlocking with an advanced key/ about 5 seconds. A beep sound is heard retractable type key after the programming is completed.
Page 18
Essential Safety Equipment Seats qLumbar Support Adjustment NOTE If the seat is already adjusted to the (Driver's Seat) position you are activating, the seat does Manually operated not move (a beep sound is not heard). The advanced key/retractable key cannot be To increase the seat firmness, pull the programmed while the key is inserted in the lever forward.
Page 19
Essential Safety Equipment Seats Do not drive with the seatback Second-Row Seats unlocked: All of the seatbacks play an WARNING important role in your protection in a Do not stack cargo higher than the vehicle. Leaving the seatback seatbacks: unlocked is dangerous as it can allow Stacking luggage or other cargo passengers to be ejected or thrown higher than the seatbacks is...
Page 20
Essential Safety Equipment Seats qSeat Slide qSeat Recline WARNING To move the seat forward or backward, raise the bar and slide the seat to the Do not drive with the seats reclined: desired position and release the bar. Sitting in a reclined position while the vehicle is moving is dangerous because you do not get the full protection from the seat belts.
Page 21
Essential Safety Equipment Seats qThird-Row Seat Access CAUTION After folding the second-row seat When returning a rear-reclined seatback and sliding the seat forward, you seatback to its upright position, can access the third-row seat easily. make sure you hold onto the seatback with your other hand while Entering/exiting the third-row seat area operating the lever.
Page 22
Essential Safety Equipment Seats 4. Pull the lever and fold the seatback CAUTION forward. Ø When folding a seatback, always hold onto the seatback with your other hand while operating the lever. If the seatback is not supported, it will flip forward suddenly and could cause injury.
Page 23
Essential Safety Equipment Seats Returning seatbacks to their original Third-Row Seat positions WARNING 1. Lift the seatback to its original position. Do not stack cargo higher than the Make sure the seatback is secured by seatbacks: attempting to lightly move it forward Stacking luggage or other cargo and back.
Page 24
Essential Safety Equipment Seats Never allow a passenger to sit or stand 3. Fasten the strap to its original position. on the folded seatback while the NOTE vehicle is moving: To create a flat luggage compartment space Driving with a passenger on the from the rear of the vehicle to the back of the folded seatback is dangerous.
Page 25
Essential Safety Equipment Seats Second-Row outboard seat/Third-Row Head Restraints seat Head restraints are intended to help protect you and the passengers from neck injury. WARNING Always drive with the head restraints installed when seats are being used and make sure they are properly adjusted: Driving with the head restraints adjusted too low or removed is...
Page 26
Essential Safety Equipment Seats qActive Head Restraints NOTE The active head restraints operate in a The front seats are equipped with active rear-end collision. The head restraints head restraints. return to their original position after the In a rear-end collision, the active head collision.
Page 27
Essential Safety Equipment Seats í WARNING Seat Warmer Ø Be careful when using the seat The front seats are electrically heated. The warmer. The heat from the seat ignition switch must be in the ON warmer may be too hot for some position.
Page 28
Essential Safety Equipment Seats NOTE If the ignition switch is turned off while the seat warmer is operating (High or Low) and then turned to the ON position again, the seat warmer will automatically operate at the temperature set before the ignition switch was turned off.
Page 29
Seat Belt Precautions Seat belts help to decrease the possibility of severe injury during accidents and sudden stops. Mazda recommends that the driver and all passengers always wear seat belts. Your vehicle has the following types of seat belts. Seating Position...
Page 30
Using a damaged seat belt is dangerous. An accident could damage the belt webbing of the seat belt in use. A damaged seat belt cannot provide adequate protection in a collision. Have an Authorized Mazda Dealer inspect all seat belt systems in use during an accident before they are used again.
Page 31
Essential Safety Equipment Seat Belt Systems CAUTION Belt retraction may become difficult if the belts and rings are soiled, so try to keep them clean. For more details about cleaning the seat belts, refer to “Cleaning the Lap/Shoulder Belt Webbing” (page 8-59). qPregnant Women and Persons with Serious Medical Conditions Pregnant women should always wear seat belts.
Page 32
Essential Safety Equipment Seat Belt Systems qAutomatic Locking Mode Always use the automatic locking mode to keep the child-restraint system from shifting to an unsafe position in the event of an accident. To enable seat belt automatic locking mode, pull it all the way out and connect it as instructed on the child-restraint system. It will retract down to the child-restraint system and stay locked on it.
Page 33
Essential Safety Equipment Seat Belt Systems WARNING 3-Point Type Seat Belt Positioning the Shoulder Portion of the qFastening the Seat Belt Seat Belt: Improper positioning of the shoulder 1. Grasp the seat belt tongue. portion of the seat belt is dangerous. 2.
Page 34
If it is still not retracting Seat Belt: properly, have it inspected at an Authorized Improper positioning of the shoulder Mazda Dealer. portion of the seat belt is dangerous. Always make sure the shoulder To secure the outboard-third row seat...
Page 35
Even if the pretensioners have not fired, front seat belts inspected. Always the load limiting function must be have an Authorized Mazda Dealer checked by an Authorized Mazda Dealer. inspect the front seat belt pretensioners and air bags after any collision.
Page 36
Ask an Authorized Mazda possible. Dealer how to safely dispose of the qAir Bag/Front Seat Belt pretensioner system or how to scrap a pretensioner-equipped vehicle.
Page 37
ON position. If any of Driving the vehicle with the air bag/ these occur, consult an Authorized Mazda front seat belt pretensioner system Dealer as soon as possible. The system warning beep sounding is dangerous.
Page 38
Essential Safety Equipment Seat Belt Systems WARNING Center-Rear Position Seat Belt (Second-Row Seats) Using the Seat Belt Guide: Not using the seat belt guide is Before using the center-rear lap/shoulder dangerous. If the seat belt guide is belt make sure tongue (A) and anchor not used, the shoulder portion of the buckle (B) are fastened.
Page 39
Always make sure the shoulder properly, have it inspected at an Authorized portion of the seat belt is positioned Mazda Dealer. across your shoulder and near your neck, but never under your arm, on your neck, or on your upper arm.
Page 40
Essential Safety Equipment Seat Belt Systems qRetracting the Center Seat Belt To stow the seat belt, retract the belt, put the seat belt tongues (A) and (C) together (Middle Row) to Lower the and insert each tongue into the respective Seatbacks for Carrying Cargo ceiling recess.
Page 41
When ordering an extender, only order one that provides the necessary additional qRe-attaching the Seat Belt after the length to fasten the seat belt properly. Please contact your Authorized Mazda Middle Row Seatbacks are Dealer for more information. Returned to their Upright Positions...
Page 42
NEVER use the extender in a different vehicle or seat. If you sell your Mazda, do not leave your seat belt extender in the vehicle. It could be used accidentally by the new owner of the vehicle.
Page 43
Minder NOTE The belt minder can be deactivated. Consult an Authorized Mazda Dealer to deactivate or restore the seat belt minder. 2-33...
Page 44
Essential Safety Equipment Seat Belt Systems Driver seated/Front passenger seated The seat belt warning function reminds the front passenger to fasten the seat belt according to the chart below. Vehicle speed Between 0 20 km/h Condition km/h (12 mph) or 12 mph) more Seat belt...
Page 45
Even if the front passenger air bag is shut off, Mazda strongly recommends that children be properly restrained and child-restraint systems of all kinds are properly secured on the rear seats which are the best place for children.
Page 46
Essential Safety Equipment Child Restraint WARNING Use the correct size child-restraint system: For effective protection in vehicle accidents and sudden stops, a child must be properly restrained using a seat belt or child-restraint system depending on age and size. If not, the child could be seriously injured or even killed in an accident. Follow the manufacturer's instructions and always keep the child-restraint system buckled down: An unsecured child-restraint system is dangerous.
Page 47
Essential Safety Equipment Child Restraint Do not install a front-facing child-restraint system on the front passenger seat unless it is unavoidable: In a collision, the force of a deploying air bag could cause serious injury or death to the child. If installing a front-facing child-restraint system on the front passenger seat is unavoidable, move the front passenger seat as far back as possible.
Page 48
NOTE Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seats. When using these anchors to secure a child-restraint system, refer to LATCH Child-Restraint Systems (page 2-46).
Page 49
Follow these instructions when using a installed on the seats that take tethers to child-restraint system, unless you are be effective. In your Mazda, tethered attaching a LATCH-equipped child- child-restraint systems can only be restraint system to the rear LATCH lower accommodated in the three positions on anchors.
Page 50
Essential Safety Equipment Child Restraint 2. If the seat in which you install a child- 7. Push the child-restraint system firmly restraint system has a seat slide into the vehicle seat. Be sure the belt function, slide the seat as far back as retracts as snugly as possible.
Page 51
Essential Safety Equipment Child Restraint Anchor bracket location WARNING Use the tether and tether anchor only for a child-restraint system: Using the tether or tether anchor to secure anything but a child-restraint system is dangerous. This could weaken or damage the tether or tether anchor and result in injury.
Page 52
Essential Safety Equipment Child Restraint qThird-Row Seats Child-Restraint 3. To get the retractor into the automatic locking mode, pull the shoulder belt System Installation portion of the seat belt until the entire The third-row seats cannot accommodate length of the belt is out of the retractor. LATCH-type child-restraint systems or tethers, therefore these systems must be installed on the other seat positions such...
You should not be able bags: to pull the shoulder belt out of the retractor Mazda vehicles equipped with side air bag while the system is in the automatic locking will have a SRS AIRBAG tag on the mode.
Page 54
Essential Safety Equipment Child Restraint qFront Passenger's Seat Child- Never use a rear-facing child-restraint system in the front seat with an air bag Restraint System Installation that could deploy: 1. Slide the seat as far back as possible. Rear-facing child-restraint systems on the front seat are particularly dangerous.
Page 55
If the indicator light does not illuminate after seating a child in a child-restraint system on the front passenger seat, seat a child in a child-restraint system on the rear seat and consult an Authorized Mazda Dealer as soon as possible. 2-45...
Page 56
Child Restraint LATCH Child-Restraint Systems Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems the second-row seats. Both anchors must be used, otherwise the seat will bounce around and put the child in danger. Most LATCH child- restraint systems must also be used in conjunction with a tether to be effective.
Page 57
Essential Safety Equipment Child Restraint qLATCH Child-Restraint System 6. If your child-restraint system came equipped with a tether, that means it is Installation Procedure (Second- very important to properly secure the Row Outboard Seats) tether for child safety. Please carefully 1.
Page 58
Essential Safety Equipment Child Restraint qLATCH Child-Restraint System WARNING Installation Procedure (Second- Use the tether and tether anchor only Row Center Seat) for a child-restraint system: The LATCH lower anchors at the center Using the tether or tether anchor to of the rear seat are much further apart than secure anything but a child-restraint the sets of LATCH lower anchors for...
Page 59
Essential Safety Equipment Child Restraint 3. Expand the area between the seat WARNING bottom and the seatback slightly to Use the tether and tether anchor only verify the locations of the LATCH for a child-restraint system: lower anchors. Using the tether or tether anchor to secure anything but a child-restraint system is dangerous.
Page 60
Essential Safety Equipment Child Restraint Anchor bracket position Tether strap position Tether strap Forward 2-50...
Page 61
Essential Safety Equipment SRS Air Bags Supplemental Restraint System (SRS) Precautions The front and side supplemental restraint systems (SRS) include 6 air bags. Please verify the air bags equipped on your vehicle by locating the SRS AIRBAG location indicators. These indicators are visible in the area where the air bags are installed. The air bags are installed in the following locations: The steering wheel hub (driver air bag) The front passenger dashboard (front passenger air bag)
Page 62
Essential Safety Equipment SRS Air Bags If your vehicle is also equipped with a driver and front passenger occupant classification system, refer to the Driver and Front Passenger Occupant Classification System (page 2-64) for details. If your vehicle is equipped with a driver and front passenger occupant classification system, the front passenger air bag deactivation indicator light illuminates for a specified time after the ignition is switched ON.
Page 63
Essential Safety Equipment SRS Air Bags Never use a rear-facing child-restraint system in the front seat with an air bag that could deploy: Rear-facing child-restraint systems on the front seat are particularly dangerous even though you may feel assured that a front passenger air bag will not deploy based on the fact that the front passenger air bag deactivation indicator light illuminates.
Essential Safety Equipment SRS Air Bags Do not attach objects on or around the area where a side air bag deploys: Attaching things to the front seat in such a way as to cover the outboard side of the seat in any way is dangerous. In an accident the object could interfere with the side air bag, which inflates from the outboard side of the front seats, impeding the added protection of the side air bag system or redirecting the air bag in a way that is dangerous.
Page 65
Should you sell your Mazda, we urge you to tell the new owner of its air bag systems and that familiarization with all instructions about them, from the Owner's Manual, is important.
Essential Safety Equipment SRS Air Bags Supplemental Restraint System Components Driver/Front passenger inflators and air bags Crash and roll-over sensor, and diagnostic module (SAS unit) Front seat belt pretensioner and load limiting systems (page 2-25) Front air bag sensor Side crash sensors Air bag/front seat belt pretensioner system warning light (page 2-60) Side and curtain inflators and air bags Front passenger air bag deactivation indicator light (page 2-64)
SRS Air Bags How the SRS Air Bags Work Your Mazda is equipped with the following types of SRS air bags. SRS air bags are designed to work together with the seat belts to help to reduce injuries during an accident.
Page 68
Essential Safety Equipment SRS Air Bags qFront Passenger Air Bag The front passenger air bag is mounted in the front passenger dashboard. The inflation mechanism for the front passenger air bag is the same as the driver's air bag, as mentioned above.
Page 69
Essential Safety Equipment SRS Air Bags qCurtain Air Bags The curtain air bags are mounted in the front and rear window pillars, and the roof edge along both sides. When the air bag crash sensors detect a side impact of greater than moderate force, the curtain air bag inflates quickly and helps to reduce injury mainly to the rear outboard passenger's head caused by directly hitting interior parts such as a door or window.
Page 70
A system malfunction is indicated if the warning light constantly flashes, constantly illuminates or does not illuminate at all when the ignition switch is turned to the ON position. If any of these occur, consult an Authorized Mazda Dealer as soon as possible. The system may not work in an accident.
Essential Safety Equipment SRS Air Bags SRS Air Bag Deployment Criteria This chart indicates the applicable SRS equipment that will deploy depending on the type of collision. (The illustrations are the representative cases of collisions.) Types of collision A severe frontal/near frontal A severe side A roll-over/near A rear collision...
Essential Safety Equipment SRS Air Bags Limitations to SRS Air Bag In severe collisions or roll-overs such as those described previously in SRS Air Bag Deployment Criteria , the applicable SRS air bag equipment will deploy. However, in some accidents, the equipment may not deploy depending on the type of collision and its severity.
Page 73
Essential Safety Equipment SRS Air Bags Limitations to roll-over detection: The following illustration is an example of an accident that may not be detected as a roll- over accident. Therefore, the front seat belt pretensioners and curtain air bags may not deploy.
Essential Safety Equipment SRS Air Bags í Driver and Front Passenger Occupant Classification System First, please read Supplemental Restraint System (SRS) Precautions (page 2-51) carefully. NOTE This system is equipped on models for the U.S., Canadian and Puerto Rican markets. qDriver Seat Slide Position Sensor Your vehicle is equipped with a driver seat slide position sensor as a part of the supplemental restraint system.
Page 75
ON position and does not illuminate as indicated in the above chart, do not allow a child to sit in the front passenger seat and consult an Authorized Mazda Dealer as soon as possible. The system may not work properly in an accident.
Page 76
Essential Safety Equipment SRS Air Bags WARNING Do not decrease the total seated weight on the front passenger seat: When an adult or large child sits on the front passenger seat, decreasing the total seated weight on the front passenger seat from the total seated weight of approximately 42 kg (93 lbs) required for air bag deployment is dangerous.
Page 77
Essential Safety Equipment SRS Air Bags Do not increase the total seated weight on the front passenger seat: When an infant or small child sits on the front passenger seat, increasing the total seated weight on the front passenger seat from the total seated weight of approximately 30 kg (66 lbs) is dangerous.
Page 78
If the front passenger air bag deactivation indicator light does not illuminate after installing a child-restraint system on the front passenger seat, install the child-restraint system on the rear seat and consult an Authorized Mazda Dealer as soon as possible. qDriver and Front Passenger Buckle Switches The buckle switches on the front seat belts detect whether or not the front seat belts are securely fastened and further control the deployment of the air bags.
The air bag systems do not require regular maintenance. But if any of the following occurs, take your vehicle to an Authorized Mazda Dealer as soon as possible: The air bag system warning light flashes. The air bag system warning light remains illuminated.
Page 80
Improper disposal of an air bag or a vehicle with live air bags in it can be extremely dangerous. Unless all safety procedures are followed, injury can result. Ask an Authorized Mazda Dealer how to safely dispose of an air bag or how to scrap an air bag equipped vehicle.
Knowing Your Mazda Explanation of basic operations and controls; opening/closing and adjustment of various parts. Advanced Keyless Entry and Start System ........ 3-2 í Advanced Keys ..............3-2 Operation Using Advanced Keyless Functions ......3-7 Operation Using Advanced Key Functions ......3-14 Advanced Key Suspend Function ...........
Knowing Your Mazda Advanced Keyless Entry and Start System í Advanced Keys The advanced keyless functions (advanced keyless entry and start system) enables the following operations while the advanced key is being carried (page 3-7). Locking/unlocking the doors and the liftgate without operating the key.
Page 83
(not in the vehicle) for use if you need to make a replacement key. Also write down the code number and keep it in another safe and handy place, but not in the vehicle. If your key is lost, consult your Authorized Mazda Dealer with the code number ready.
Page 84
Refer to Advanced Key Battery Dead Warning on page 3-20. Additional advanced keys can be obtained at an Authorized Mazda Dealer. Up to 6 advanced keys can be used with the advanced keyless functions per vehicle.
Page 85
Knowing Your Mazda Advanced Keyless Entry and Start System qAdvanced Key Maintenance Replacing the battery at an Authorized Mazda Dealer is recommended to prevent CAUTION damage to the advanced key. If replacing the battery by yourself, follow the Ø Make sure the battery is installed instruction below.
Page 86
Knowing Your Mazda Advanced Keyless Entry and Start System 3. Insert the flathead screwdriver into the 5. Insert a new battery with the positive gap between the cover and the pole facing up, and then cover the transmitter, and then rotate the battery with the battery cap.
Mazda Dealer. liftgate. If your advanced key is lost or stolen, Exterior transmitter bring all remaining advanced keys to an Authorized Mazda Dealer as soon as possible for a replacement and to make the lost or stolen advanced key inoperative. CAUTION Radio equipment like this is governed by laws in the United States.
Page 88
Knowing Your Mazda Advanced Keyless Entry and Start System qLocking, Unlocking with Request Starting the engine Switch The operational range for starting the engine includes nearly the entire cabin All doors and the liftgate can be locked/ area except for the luggage compartment.
Page 89
Knowing Your Mazda Advanced Keyless Entry and Start System NOTE NOTE The request switch on the driver's door can (Without theft-deterrent system) The hazard warning lights will flash once to be used to close the power windows and the indicate that the doors and the liftgate are moonroof.
Page 90
Knowing Your Mazda Advanced Keyless Entry and Start System (Auto re-lock function) LOCK (Depressed) After unlocking doors and the liftgate by The ignition switch can be turned to the pressing the request switch, all doors and ACC position when the KEY indicator...
Page 91
Knowing Your Mazda Advanced Keyless Entry and Start System ACC (Accessory) Starting the engine The steering wheel unlocks and some NOTE electrical accessories will operate. Engine-starting is controlled by the spark ignition system. NOTE This system meets all Canadian The Advanced Keyless Entry System does not...
Page 92
Knowing Your Mazda Advanced Keyless Entry and Start System NOTE NOTE The starter will not operate if the shift lever is In the following cases, the KEY warning light not in P or N. (red) illuminates and the engine will not start.
Page 93
Knowing Your Mazda Advanced Keyless Entry and Start System NOTE NOTE In extremely cold weather or after the When turning the ignition switch to the vehicle has not been driven in several days, LOCK position, the ignition switch has to...
Knowing Your Mazda Advanced Keyless Entry and Start System Transmitter Operation Using Advanced with power liftgate Key Functions Operation indicator Lock button qKeyless Entry System light This system uses the more traditional Unlock button keyless entry buttons to remotely lock and...
Page 95
Power liftgate button when any door or the liftgate is open. Confirm that all doors and the liftgate are If your Mazda has a power liftgate (page locked visually or audibly by use of the 3-35), the transmitter can open/close the double click.
Page 96
Knowing Your Mazda Advanced Keyless Entry and Start System (Turning on the alarm) Pressing the panic button for 1 second or more will trigger the alarm for about 2 minutes and 30 seconds, and the following will occur: The horn sounds intermittently.
Page 97
Knowing Your Mazda Advanced Keyless Entry and Start System Declaration of Conformity Keyless entry system 3-17...
Knowing Your Mazda Advanced Keyless Entry and Start System qAuxiliary Key Function Advanced Key Suspend Use the auxiliary key stored in the Function advanced key in the event of a dead transmitter battery or malfunction. If one advanced key is left in the vehicle...
However the beep sound will be heard vehicle inspected at an Authorized continuously when the start knob is in Mazda Dealer as soon as possible. the ACC position and the door is open Refer to Ignition Switch (page 5-2). due to the activation of the warning...
Page 100
Knowing Your Mazda Advanced Keyless Entry and Start System qRequest Switch Inoperable The advanced key is not within operational range. Warning Beep The advanced key is placed in areas If the request switch for a front door or the where it is difficult for the system to liftgate is pressed under the following detect the signal (page 3-7).
Knowing Your Mazda Advanced Keyless Entry and Start System Setting Change (Function Customization) The following function settings are possible. These settings can only be changed by an Authorized Mazda Dealer. After Setting Setting Function At Initial Setting Change Advanced key battery...
The advanced key is malfunctioning. Park the vehicle in When the KEY warning light (red) remains illuminated a safe place, and use the auxiliary key to continue in the instrument cluster. driving the vehicle. Have the vehicle inspected at an Authorized Mazda Dealer as soon as possible. 3-22...
This could result in If your key is lost, consult your Authorized someone being badly injured or even Mazda Dealer and have your code number killed. Children may find these new ready. kinds of keys to be an interesting toy...
Knowing Your Mazda Doors and Locks Key extend/retract method (Retractable í Keyless Entry System type key) This system remotely locks and unlocks To extend the key, press the release the doors and the liftgate, and opens the button. power windows and the moonroof.
Page 105
Additional transmitters can be obtained at windows and the moonroof. an Authorized Mazda Dealer. Up to 3 Refer to the following pages: transmitters can be used with the keyless Opening/Closing the Power Windows (page entry system per vehicle.
Page 106
Knowing Your Mazda Doors and Locks NOTE NOTE Pressing the transmitter lock button to lock (Without theft-deterrent system) the doors while any door is open does not The hazard warning lights will flash twice to sound the horn. indicate that all doors and the liftgate are unlocked.
Page 107
Knowing Your Mazda Doors and Locks qTransmitter Maintenance 2. Insert a screwdriver into the slot and push the tab to remove the key from If the buttons on the transmitter are the transmitter. inoperable and the operation indicator light does not flash, the battery may be dead.
Page 108
Authorized Mazda Dealer. If your transmitter is lost or stolen, bring all remaining transmitters to an Authorized Mazda Dealer as soon as possible for a replacement and to make the lost or stolen transmitter inoperative. CAUTION Radio equipment like this is governed by laws in the United States.
Page 109
Knowing Your Mazda Doors and Locks qDeclaration of Conformity Keyless entry system 3-29...
Knowing Your Mazda Doors and Locks qLocking, Unlocking with Key Door Locks The driver's door can be locked/unlocked WARNING with the key. Turn the key toward the front to unlock, Always take all children and pets with toward the back to lock.
Page 111
Knowing Your Mazda Doors and Locks qLocking, Unlocking with Door- NOTE (With advanced key) Lock Knob The driver's door cannot be locked using To lock any door from the inside, push the the door-lock knob from the outside. door-lock knob.
Page 112
Knowing Your Mazda Doors and Locks Locking, unlocking with key Locking, unlocking with door-lock switch All doors and the liftgate lock automatically when the driver's door is All doors and the liftgate lock locked with the key. All doors and the automatically when lock side is pressed.
Knowing Your Mazda Doors and Locks qRear Door Child Safety Locks Liftgate These locks are intended to help prevent WARNING children from accidentally opening the rear doors. Use them both whenever a Never allow a person to ride in the child rides in the vehicle.
Page 114
Knowing Your Mazda Doors and Locks qLocking, Unlocking with Transmitter NOTE If the vehicle battery is dead or there is a (with Retractable Type Key) malfunction in the electrical system and the The liftgate can be locked/unlocked by liftgate cannot be unlocked, perform the...
Page 115
Authorized button on the keyless entry system is Mazda Dealer as soon as possible. dangerous. A person could become Manually closing the liftgate caught between the liftgate and an...
Page 116
Knowing Your Mazda Doors and Locks Never allow children to operate the NOTE power liftgate system: Do not apply unnecessary force to the Allowing children to operate the power liftgate when it is opening/closing power liftgate switch and the keyless electrically.
Page 117
Knowing Your Mazda Doors and Locks Opening/Closing the power liftgate Operation from the driver's seat (To open/close) If the vehicle has satisfied all the following operation conditions, the power Press the power liftgate switch for about liftgate can be opened using the power one second or more while the liftgate is in function.
Page 118
Knowing Your Mazda Doors and Locks NOTE CAUTION If the power liftgate switch/power liftgate close Sensors are installed on both ends of switch/power liftgate button on the transmitter the power liftgate. Be careful not to is pressed or the outside handle is operated...
Page 119
Knowing Your Mazda Doors and Locks NOTE Power liftgate drop prevention mechanism If the liftgate handle is pulled while the easy closure function is operating, the The power liftgate drop prevention liftgate can be opened. mechanism activates if the system detects...
Knowing Your Mazda Doors and Locks qOperating the Front Power Windows Power Windows NOTE The ignition switch must be in the ON Each passenger power window can be position for the power windows to operated with each door switch when the operate.
Page 121
Knowing Your Mazda Doors and Locks NOTE Manual opening/closing (POWER WINDOW RESET PROCEDURE) To open a power window to the desired If the battery was disconnected during vehicle position, lightly hold down the switch. maintenance, or for other reasons such as a...
Page 122
If you are unable to cancel the function the front power windows, carry out the despite carrying out the cancellation following procedure using the master procedure, consult an Authorized Mazda control switches. Dealer. 1. Turn the ignition switch to the ON...
Page 123
Knowing Your Mazda Doors and Locks qOperating the Rear Power Windows NOTE Depending on driving conditions, a closing The power windows may be operated power window could stop and start opening when the power window lock switch on when the window feels a shock that is the driver's door is in the unlocked similar to something blocking it.
Page 124
Knowing Your Mazda Doors and Locks NOTE Engine-off power window operation When the power window lock switch is in the The power windows can be operated for locked position, the light on each power about 40 seconds after the ignition switch...
Page 125
Opening Power liftgate button Because nobody likes getting into a very hot car, Mazda has introduced a way to open the two front windows and the Panic button moonroof as you approach the vehicle to get the air moving before you get in.
Page 126
Knowing Your Mazda Doors and Locks NOTE NOTE The unlock button does not operate unless (With advanced key) it is pressed twice sequentially. If the auto-lock function (page 3-8) has been The lock button cannot be used to close the activated, the doors and the liftgate power windows and the moonroof.
CAUTION Always use only a genuine Mazda fuel-filler cap or an approved equivalent, available at an Authorized Mazda Dealer. The wrong cap can result in a serious malfunction of the fuel and emission control systems.
Page 128
Knowing Your Mazda Doors and Locks qFuel-Filler Lid CAUTION To open, pull the remote fuel-filler lid If the check fuel cap warning light release. illuminates, the fuel-filler cap may not be properly installed. If the warning light illuminates, park your...
Knowing Your Mazda Doors and Locks 3. Grasp the support rod in the padded Hood area and secure it in the stay hole indicated by the arrow to hold the hood WARNING open. Always check that the hood is closed...
The moonroof can be opened or closed does not get inside the cabin area. After electrically only when the ignition switch washing your Mazda or after it rains, wipe the is in the ON position. water off the moonroof before operating it to...
Page 131
Knowing Your Mazda Doors and Locks qEngine-off Moonroof Operation To stop sliding partway, press any part of the tilt or slide switch. The moonroof can be operated for about 40 seconds after the ignition switch is turned from the ON position to the ACC or LOCK position with all doors closed.
Page 132
Knowing Your Mazda Doors and Locks qSunshade The sunshade can be opened and closed by hand. The sunshade opens automatically when the moonroof is opened, but must be closed by hand. Sunshade CAUTION Ø The sunshade does not tilt. To avoid damaging the sunshade, do not push up on it.
Knowing Your Mazda Security System CAUTION Immobilizer System (with Advanced Key) Do not allow the following when starting the engine with the auxiliary The immobilizer system allows the engine key due to an advanced key dead to start only with an advanced key the battery or other malfunction.
Page 134
Authorized Mazda Dealer. Always keep a spare advanced key in case one is lost. If an advanced key is lost, consult an Authorized Mazda Dealer as soon as possible. If you lose an advanced key (including auxiliary key), an Authorized Mazda Dealer...
Page 135
Knowing Your Mazda Security System Declaration of Conformity Immobilizer system 3-55...
Page 136
Go to an Authorized If the engine does not start with the Mazda Dealer and have it checked. If the correct advanced key, and the security engine is shut off while the indicator light is indicator light keeps illuminating or flashing, you will not be able to restart it.
Add-On Immobilizer System Equipment (without Advanced Key) Mazda cannot guarantee the immobilizer system's operation if the system has been The immobilizer system allows the engine modified or if any add-on equipment has to start only with a key the system been installed.
Page 138
Ø A key ring rests on the key grip. If a key is lost, contact an Authorized Mazda Dealer as soon as possible. If you lose a key, an Authorized Mazda Dealer will reset the electronic codes of your remaining keys and immobilizer system.
Page 139
Knowing Your Mazda Security System Declaration of Conformity Immobilizer system 3-59...
Page 140
Disarming shut off the engine. Go to an Authorized The system is disarmed when the ignition Mazda Dealer and have it checked. If you switch is turned to the ON position with shut off the engine while the light is the correct ignition key.
Knowing Your Mazda Security System NOTE í Theft-Deterrent System If the battery goes dead while the theft- deterrent system is armed, the horn will If the theft deterrent system detects an activate and the hazard warning lights will inappropriate entry into the vehicle, which flash when the battery is charged or replaced.
Page 142
Insert the key into the ignition switch Mazda recommends that you affix it to the and turn it to the ON position. lower rear corner of a front door window. (With advanced key) Press a request switch or the unlock button on the transmitter.
Knowing Your Mazda Steering Wheel and Mirrors Steering Wheel Mirrors WARNING qOutside Mirrors Never adjust the steering wheel while Check the mirror angles before driving. the vehicle is moving: Mirror type Adjusting the steering wheel while the vehicle is moving is dangerous.
Page 144
Knowing Your Mazda Steering Wheel and Mirrors qRearview Mirror 2. Depress the mirror switch in the appropriate direction. WARNING Selector switch Outside mirror Do not stack cargo or objects higher than the seatbacks: Cargo stacked higher than the seatbacks is dangerous. It can block...
Page 145
Knowing Your Mazda Steering Wheel and Mirrors NOTE Press the OFF button ( ) to cancel the automatic dimming function. The For the manual day/night mirror, perform the indicator light will turn off. adjustment with the day/night lever in the day To reactivate the automatic dimming position.
Page 146
Knowing Your Mazda Steering Wheel and Mirrors NOTE Do not use glass cleaner or suspend objects on or around the light sensor. Otherwise, light sensor sensitivity will be affected and may not operate normally. Light sensor Light sensor For information regarding the 3 buttons...
Page 147
Before Driving Your Mazda Important information about driving your Mazda. Fuel and Engine Exhaust Precautions ........4-2 Fuel Requirements ..............4-2 Emission Control System ............4-3 Engine Exhaust (Carbon Monoxide) ......... 4-4 Before Starting the Engine ............4-5 Before Getting In ..............4-5 After Getting In .................
Ø Never add fuel system additives. Never add cleaning agents other than those specified by Mazda. Other cleaning agents and additives may damage the system. Consult an Authorized Mazda Dealer. Gasoline blended with oxygenates such as alcohol or ether compounds are generally referred to as oxygenated fuels.
Ø USE ONLY UNLEADED FUEL. Ø Do not drive your Mazda with any sign of engine malfunction. Ø Do not coast with the ignition switch turned off. Ø Do not descend steep grades in gear with the ignition switch turned off.
When inhaled, it can cause loss of consciousness and death. If you smell exhaust gas inside your vehicle, keep all windows fully open and contact an Authorized Mazda Dealer immediately. Do not run the engine when inside an enclosed area: Running the engine inside an enclosed area, such as a garage, is dangerous.
Before Driving Your Mazda Before Starting the Engine Before Getting In After Getting In Be sure the windows, outside mirrors, Are all doors closed and locked? and outside lights are clean. Is the seat adjusted properly? Inspect inflation pressures and Are the inside and outside mirrors condition of tires.
Break-In Period Money-Saving Suggestions No special break-in is necessary, but a few How you operate your Mazda determines precautions in the first 1,000 km (600 how far it will travel on a tank of fuel. Use miles) may add to the performance, these suggestions to help save money on economy, and life of your Mazda.
Before Driving Your Mazda Driving Tips For more traction in starting on Hazardous Driving slippery surfaces such as ice or packed snow, use sand, rock salt, chains, qDriving on Slippery Surface carpeting, or other nonslip material WARNING under the front wheels.
Page 154
Before Driving Your Mazda Driving Tips qRoll-over qEmergency Maneuvering WARNING WARNING Avoid sharp turns, excessive speed and Do not perform abrupt maneuvers abrupt maneuvers when driving this when driving the vehicle in an vehicle: emergency situation: Sharp turns, excessive speed and...
Before Driving Your Mazda Driving Tips Floor Mat Rocking the Vehicle WARNING WARNING Make sure the floor mats are hooked Do not spin the wheels at more than 56 on the retention pins to prevent them km/h (35 mph), and do not allow...
Ask an Authorized Mazda Dealer to to further improve traction on snow and perform the following precautions: ice covered roads.
Page 157
Install the chains on the front tires. Do not use chains on the rear tires. Use only genuine Mazda tire chains. Please consult an Authorized Mazda Dealer. 4-11...
Before Driving Your Mazda Driving Tips Driving In Flooded Area Overloading WARNING WARNING Dry wet brakes by driving very slowly Be careful not to overload your vehicle: and applying the brakes lightly until The gross axle weight rating (GAWR) brake performance returns to normal:...
Before Driving Your Mazda Driving Tips Driving on Uneven Road Your vehicle's suspension and underbody can be damaged if driven on rough/uneven roads or over speed bumps at excessive speeds. Use care and reduce speed when traveling on rough/uneven roads or over speed bumps.
Never overload vehicle or trailer. Consult an Authorized Mazda Dealer if you need further details. CAUTION Do not tow a trailer during the first 1,000 km (600 miles) of your new Mazda. If you do, you may damage the engine, transaxle, differential, wheel bearings, and other power train components.
Page 161
Before Driving Your Mazda Towing High-altitude operation In a high-altitude operating environment, a gasoline engine loses power at a rate of 3 % to 4 % per 304 m (1,000 ft) of elevation. In these conditions, a reduction in gross vehicle weight and gross combination weight is recommended.
Page 162
Before Driving Your Mazda Towing Model Item Without Towing With Towing Package Package Front 60 % DISTRIBUTION OF TRAILER Rear 40 % LOAD GCWR: Gross Combination Weight Rating (sum of TTW, vehicle weights and 2 passengers) GAWR: Gross Axle Weight Rating GVWR: Gross Vehicle Weight Rating *1 i.e.
Page 163
Before Driving Your Mazda Towing WARNING Always make sure the trailer hitch is securely attached before departure: An unsecured trailer hitch is dangerous as it causes greater trailer sway from crosswinds, rough roads or other causes, resulting in loss of control and a serious accident.
Page 164
Towing Tips Verify that your Mazda maintains a near-normal attitude when a loaded or unloaded trailer is connected. Do not drive if it has an abnormal front-up or front-down position.
Page 165
Stop and re-inspect all lights and connections after driving a short distance. Driving Your Mazda will handle differently with a trailer in tow, so practice turning, backing, and stopping in a traffic-free area. Take time to get accustomed to the extra weight and length.
Page 166
Before Driving Your Mazda Towing Ascending a hill Shift into a lower gear to reduce the possibility of overloading or overheating the engine, or both. Descending a hill Shift into a lower gear and use engine compression as a braking effect.
Page 167
Before Driving Your Mazda Towing 3. Release the parking brake (also the foot brake) and pull away from the wheel blocks. Stop; apply the parking brake and shift into P. 4. Have a helper retrieve the wheel blocks. Fuel consumption Trailer towing causes higher fuel consumption.
Driving Your Mazda Explanation of instruments and controls. Starting and Driving ..............5-2 Ignition Switch ................5-2 Starting the Engine ..............5-4 Brake System ................5-5 Automatic Transaxle Controls ..........5-10 Power Steering ................ 5-16 í All-Wheel Drive (AWD) Operation ........
Driving Your Mazda Starting and Driving qIgnition Switch Positions Ignition Switch With advanced Auxiliary key (with advanced key) NOTE When starting the engine using the advanced key, refer to Starting the Engine (page 3-10). Without advanced When starting the engine with the auxiliary key, perform the following procedure.
Page 171
Driving Your Mazda Starting and Driving WARNING This is the normal running position after Remove the key only when the vehicle the engine is started. Some indicator is parked: lights/warning lights should be inspected Removing the key from the ignition before the engine is started (page 5-43).
Driving Your Mazda Starting and Driving NOTE Starting the Engine In extremely cold weather or after the vehicle has not been driven in several days, NOTE let the engine warm up without operating Engine-starting is controlled by the spark the accelerator.
Do not coast with the engine stalled or qFoot Brake turned off, find a safe place to stop: Coasting with the engine stalled or Your Mazda has power-assisted brakes turned off is dangerous. Braking will that adjust automatically through normal require more effort, and the brake's use.
Page 174
Driving Your Mazda Starting and Driving qParking Brake Setting the parking brake Depress the brake pedal, then depress the WARNING parking brake pedal fully. Before leaving the driver's seat, always put the key or start knob to LOCK position, set the parking brake and...
Page 175
System Warning Light NOTE Having to add brake fluid is sometimes an indicator of leakage. Consult an Authorized Mazda Dealer as soon as possible even if the brake light is no longer illuminated. WARNING Do not drive with the brake system warning light illuminated.
Page 176
ABS. for unsafe and reckless driving, Should this happen, consult an Authorized excessive speed, tailgating (following Mazda Dealer as soon as possible. another vehicle too closely), driving NOTE on ice and snow, and hydroplaning...
Page 177
This causes a loud screeching illuminated. Have the vehicle towed to noise to warn that the pads should be an Authorized Mazda Dealer to have replaced. the brakes inspected as soon as possible:...
Driving Your Mazda Starting and Driving Automatic Transaxle Controls Various Lockouts: Indicates that you must depress the brake pedal to shift (The ignition switch must be in the ACC or ON position). Indicates the shift lever can be shifted freely into any position.
Page 179
Driving Your Mazda Starting and Driving qTransaxle Ranges WARNING The shift lever must be in P or N to If the engine is running faster than idle, operate the starter. do not shift from N or P into a driving...
Page 180
Driving Your Mazda Starting and Driving qActive Adaptive Shift (AAS) NOTE When the ignition switch is in the LOCK Active Adaptive Shift (AAS) position, the shift lever cannot be shifted automatically controls the transaxle shift from P. points to best suit the road conditions and To be sure the vehicle is in park, the driver input.
Page 181
Driving Your Mazda Starting and Driving NOTE Shifting If you change to manual shift mode when Manually Shifting up the vehicle is stopped, the gear will shift to (M1 → M2 → M3 → M4 → M5 → M6) To shift up to a higher gear, tap the shift...
Page 182
Driving Your Mazda Starting and Driving Manually Shifting down Second gear fixed mode ( M6 → M5 → M4 → M3 → M2 → When the shift lever is tapped back ( while the vehicle is stopped, the transaxle To shift down to a lower gear, tap the shift is set in the second gear fixed mode.
Page 183
Driving Your Mazda Starting and Driving During deceleration, the gears shift down On a steep downgrade, downshifting automatically when speed is reduced to helps maintain safe speed and prolongs the following: brake life. Gear Vehicle speed qDriving Tips M6 → M5 47 km/h (29 mph) M5 →...
Driving Your Mazda Starting and Driving Power Steering All-Wheel Drive (AWD) í Operation Power steering is only operable when the engine is running. If the engine is off or if AWD provides excellent driveability on the power steering system is inoperable,...
Page 185
RSC might help if you get into If the AWD warning light illuminates, trouble, but then it might not be able contact an Authorized Mazda Dealer. to allow you to fully recover, always If the AWD warning light flashes: drive carefully with the vehicle's height in mind.
Page 186
Driving Your Mazda Starting and Driving Tire chains WARNING Install tire chains to the front tires. Never spin a wheel that is off the Do not use tire chains on the rear ground: wheels. Spinning a wheel that is off the...
Driving Your Mazda Starting and Driving qActivation/Deactivation Cruise Control To activate the system, press the ON With cruise control, you can set and switch. automatically maintain any speed of more The cruise main indicator light than about 30 km/h (19 mph).
Page 188
Driving Your Mazda Starting and Driving qTo Increase Cruising Speed 3. Set the cruise control by pressing the cruise control SET /SET - switch up Follow either of these procedures. or down at the desired speed. The cruise control is set at the moment the...
Page 189
Driving Your Mazda Starting and Driving Your vehicle has a tap-down feature that To increase speed using accelerator allows you to decrease your current speed pedal in decrements of 1.6 km/h (1 mph) by a Depress the accelerator pedal to accelerate momentary tap of the cruise control SET - to the desired speed.
Driving Your Mazda Starting and Driving Press the CANCEL switch. Traction Control System (TCS) The Traction Control System (TCS) enhances traction and safety by controlling engine torque and braking. When the TCS detects driving wheel slippage, it lowers engine torque and operates the brakes to prevent loss of traction.
Page 191
Indicator Light Refer to TCS OFF Switch on page 5-24. If the light remains illuminated and the TCS is not switched off, take your vehicle to an Authorized Mazda Dealer. The dynamic stability control may have a malfunction. NOTE...
Page 192
Driving Your Mazda Starting and Driving qTCS OFF Switch NOTE When TCS is on and you attempt to free the If the vehicle speed is less than 15 km/h vehicle when it is stuck, or drive it out of (9 mph), press the TCS OFF switch to freshly fallen snow, the TCS will activate.
Driving Your Mazda Starting and Driving WARNING Dynamic Stability Control (DSC)/Roll Stability Do not rely on the dynamic stability control as a substitute for safe driving: Control (RSC) The dynamic stability control (DSC)/ Roll Stability Control (RSC) cannot The Dynamic Stability Control (DSC)
Page 194
TCS/DSC/RSC indicator light is correctly unless the following are illuminated. observed: Ø Use tires of the correct size specified for your Mazda on all four wheels. Ø Use tires of the same manufacturer, brand and tread pattern on all four wheels.
Driving Your Mazda Starting and Driving í Tire Pressure Monitoring System The tire pressure monitoring system (TPMS) monitors the pressure for each tire. If tire pressure is too low in one or more tires, the system will inform the driver via the warning light in the instrument panel and by the warning beep sound.
Page 196
Driving Your Mazda Starting and Driving CAUTION Ø Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a...
Page 197
Authorized Mazda Dealer or a tire repair station. Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated.
Page 198
Leaks need to be addressed by more than simply refilling the trouble tire as leaks are dangerous - take it to an Authorized Mazda Dealer which has all the equipment to fix tires, TPMS systems and order the best replacement tire for your vehicle.
Page 199
The easiest way to do it is to have an Consult an Authorized Mazda Dealer. Authorized Mazda Dealer change your tire and A system error activation may occur in complete ID signal code registration.
Page 200
Replacing tires and wheels CAUTION Ø When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. Ø The wheels equipped on your Mazda are specially designed for installation of the tire pressure sensors.
Driving Your Mazda Starting and Driving í Blind Spot Monitoring (BSM) System The Blind Spot Monitoring (BSM) system is designed to assist the driver by monitoring blind spots on both sides of the vehicle to the rear in certain situations such as when changing lanes on roads and freeways.
Page 202
Vehicles with lower body height such as sports cars. Have the radar sensors inspected at an Authorized Mazda Dealer if any shock is applied to the rear bumper, even in a minor accident. If the vehicle is driven with a damaged radar sensor, the system may not operate properly resulting in an accident.
Page 203
Driving Your Mazda Starting and Driving The following conditions may affect the visibility of the BSM warning lights on the outside mirror, making it difficult to confirm the illumination of the lights: Ice or snow adheres to the surface of the outside mirrors.
Page 204
If the ignition switch is turned to the LOCK consult an Authorized Mazda Dealer. position with the BSM system turned off, the For repairs or paintwork around the radar system becomes operable automatically...
Page 205
Driving Your Mazda Starting and Driving qSafety Certification (CANADA) ICDCE2008075 (temporary permission Radiation Hazard until RSS·220 is in force) This BSM (blind spot monitoring) device This vehicle is equipped with a 24 GHz emits intentional electromagnetic blind spot monitoring (BSM) radar...
Driving Your Mazda Instrument Cluster and Indicators Meters and Gauges When the ignition switch is in the ON position, the dashboard gauges illuminate. Speedometer ...................... page 5-39 Odometer, Trip Meter and Trip Meter Selector ..........page 5-39 Tachometer ......................page 5-40 Engine Coolant Temperature Gauge ..............
Page 207
Driving Your Mazda Instrument Cluster and Indicators qSpeedometer The speedometer indicates the speed of the vehicle. qOdometer, Trip Meter and Trip Odometer Meter Selector The display mode can be changed between trip meter A and trip meter B by Trip meter A...
Page 208
Driving Your Mazda Instrument Cluster and Indicators qEngine Coolant Temperature Gauge The trip meter records the total distance the vehicle is driven until the meter is The engine coolant temperature gauge again reset. Return it to 0.0 by holding shows the temperature of the engine the selector depressed for 1 second or coolant.
Page 209
Driving Your Mazda Instrument Cluster and Indicators qFuel Gauge qDashboard Illumination The fuel gauge shows approximately how Rotate the knob to adjust the brightness of much fuel is remaining in the tank when the instrument cluster and other the ignition switch is in the ON position.
Page 210
Driving Your Mazda Instrument Cluster and Indicators To cancel the illumination dimmer, press the dashboard illumination knob. NOTE This symbol ( ) indicates the knob to adjust the brightness of the dashboard illumination. If the illumination dimmer is cancelled, the...
Driving Your Mazda Warning/Indicator Lights and Beep Sounds Warning/Indicator Lights Warning/Indicator lights will appear in any of the highlighted areas Signal Warning/Indicator Lights Page Brake System Warning Light 5-45 Charging System Warning Light 5-47 Engine Oil Pressure Warning Light 5-47...
Page 212
Driving Your Mazda Warning/Indicator Lights and Beep Sounds Signal Warning/Indicator Lights Page Low Fuel Warning Light 5-49 Check Fuel Cap Warning Light 5-49 Seat Belt Warning Light/Beep 5-49 Door-Ajar Warning Light 5-51 Low Washer Fluid Level Warning Light 5-51 Automatic Transaxle Warning Light...
Page 213
Parking brake warning indicator of leakage. Consult an Authorized The light illuminates when the parking Mazda Dealer as soon as possible even if the brake is applied with the ignition switch brake light is no longer illuminated. in the START or ON position. It turns off WARNING when the parking brake is fully released.
Page 214
ABS. brake force distribution system. Should this happen, consult an Authorized WARNING Mazda Dealer as soon as possible. Do not drive with both the ABS warning NOTE light and brake warning light When the engine is jump-started to charge the illuminated.
Page 215
Driving Your Mazda Warning/Indicator Lights and Beep Sounds qCharging System Warning Light If the light illuminates while driving: 1. Drive to the side of the road and park off the right-of-way on level ground. 2. Turn off the engine and wait 5 minutes for the oil to drain back into the oil pan.
Page 216
The fuel tank level being very low or drive at high speeds and consult an approaching empty. Authorized Mazda Dealer as soon as The engine's electrical system has a possible. problem. qAir Bag/Front Seat Belt The emission control system has a problem.
Page 217
Driving Your Mazda Warning/Indicator Lights and Beep Sounds qLow Fuel Warning Light qSeat Belt Warning Light/Beep Low fuel warning light This warning light in the fuel gauge The seat belt warning light illuminates signals that the fuel tank will soon be and a beep sound will be heard if the empty.
Page 218
Driving Your Mazda Warning/Indicator Lights and Beep Sounds Belt minder Driver seated/Front passenger seated The seat belt warning function reminds Driver seated/Front passenger not the front passenger to fasten the seat belt seated according to the chart below. The belt minder is a supplemental warning to the seat belt warning function.
Page 219
CAUTION If the automatic transaxle warning light illuminates, the transaxle has an electrical problem. Continuing to drive your Mazda in this condition could cause damage to your transaxle. Consult an Authorized Mazda Dealer as soon as possible. This warning light illuminates when any door or liftgate is not securely closed.
Page 220
í (TPMS) Warning Light place where air may be added and the system monitored again by an Authorized Mazda Dealer or a tire repair station. Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated.
Page 221
Leaks need to be addressed by more than simply refilling the trouble tire as leaks are dangerous - take it to an Authorized Mazda Dealer which has all the equipment to fix tires, TPMS systems and order the best replacement tire for your vehicle.
Page 222
Have the vehicle tire is being used. inspected at an Authorized Mazda Dealer as soon as possible. Warning light flashes When the warning light flashes, there may When flashing be a system malfunction.
Page 223
Driving Your Mazda Warning/Indicator Lights and Beep Sounds Under the following conditions, the NOTE KEY warning light (red) will flash The advanced key can be set so that the KEY continuously when the start knob has indicator light (green) does not flash even if not been returned to the LOCK the battery power is low.
Page 224
Driving Your Mazda Warning/Indicator Lights and Beep Sounds qHeadlight High-Beam Indicator Gear position indicator Light When the shift lever is in the D or M position, the numeral for the selected gear displays. qTCS/DSC Indicator Light This light indicates one of two things: The high-beam headlights are on.
Page 225
Refer to TCS OFF Switch on page 5-24. If the light remains illuminated and the TCS is not switched off, take your vehicle to an Authorized Mazda Dealer. The dynamic stability control may have a This indicator light illuminates for a few malfunction.
Warning to be heard for approximately 35 minutes. Indicator Lights Have your vehicle inspected at an Authorized Mazda Dealer as soon as possible. WARNING Do not drive the vehicle with the air bag/front seat belt pretensioner system...
Page 227
Driving Your Mazda Warning/Indicator Lights and Beep Sounds qSeat Belt Warning Beep qTire Inflation Pressure Warning í Beep If the driver's seat belt is not fastened when the ignition switch is turned to the The warning beep sound will be heard for...
Driving Your Mazda Switches and Controls Type B (With AUTO position) Lighting Control qHeadlights Type A (Without AUTO position) Turn the headlight switch to turn the headlights, other exterior lights and dashboard illumination on or off. Switch Position Turn the headlight switch to turn the...
Page 229
Authorized Mazda Dealer regarding sensor adjustment. The sensitivity of the AUTO lights may be Ø The light sensor also works as a changed by an Authorized Mazda Dealer. rain sensor for the auto-wiper í control. Keep hands and scrapers Xenon fusion headlight bulbs...
Page 230
Driving Your Mazda Switches and Controls í qLights-On Reminder qFlashing the Headlights If lights are on and the key is removed To flash the headlights, pull the lever fully from the ignition switch, a continuous toward you. The headlight switch does...
Driving Your Mazda Switches and Controls Select the proper setting from the following chart. Turn and Lane-Change Front seat Rear seat Signals Switch Load Second- Third- Position Driver Passenger qTurn Signal × × × Move the signal lever down (for a left ×...
Driving Your Mazda Switches and Controls í Fog Lights Windshield Wipers and Washer Use this switch to turn on the fog lights. They help you to see as well as to be seen. The ignition switch must be in the ON position.
Page 233
If they do not resume functioning, consult an Authorized INT ring Mazda Dealer as soon as possible. Drive to the side of the road and park off the right-of- way. Wait until the weather clears before trying Type B (With AUTO position) to drive with the wipers inoperative.
Page 234
Driving Your Mazda Switches and Controls AUTO (Auto-wiper control) CAUTION When the wiper lever is in the AUTO Ø Do not shade the rain sensor by position, the rain sensor senses the adhering a sticker or a label on amount of rainfall on the windshield and the windshield.
Page 235
Driving Your Mazda Switches and Controls Ø When the wiper lever is in the NOTE AUTO position and the ignition Switching the auto-wiper lever from the switch is in the ON position, the OFF to the AUTO position while driving at...
If the washer does not work, inspect the Normal fluid level (page 8-26). If it's normal, Intermittent consult an Authorized Mazda Dealer. qRear Window Washer To spray washer fluid, turn the rear wiper/ washer switch to the position. After the switch is released, the washer will stop.
Driving Your Mazda Switches and Controls NOTE Rear Window Defroster This defroster is not designed for melting snow. If there is an accumulation of snow on the rear The rear window defroster clears frost, window, remove it before using the defroster.
Driving Your Mazda Switches and Controls Horn Hazard Warning Flasher To sound the horn, press the mark on The hazard warning lights should always the steering wheel. be used when you stop on or near a roadway in an emergency.
Driving Your Mazda Switches and Controls WARNING HomeLink Wireless í Control System Do not use the HomeLink system with any garage door opener that lacks the NOTE safety stop and reverse feature: Using the HomeLink system with any HomeLink and HomeLink house are registered garage door opener that lacks the trademarks of Johnson Controls.
Page 240
Driving Your Mazda Switches and Controls NOTE The HomeLink system provides 3 buttons which can be individually selected and FCC ID: NZLOBIHL3 programmed using the transmitters for CANADA:4112A-OBIHL3 current, on-market devices as follows: This device complies with FCC rules part 15.
Page 241
Driving Your Mazda Switches and Controls 5. Press and hold the just-trained HomeLink should now activate your HomeLink button and observe the rolling code equipped device. indicator light. NOTE If the indicator light stays on constantly, To program the remaining two HomeLink buttons, begin with Programming ―...
Page 242
Driving Your Mazda Switches and Controls Continue to press and hold the HomeLink button while you press and release every two seconds ( cycle ) your hand- held transmitter until the frequency signal has successfully been accepted by HomeLink. (The indicator light will flash slowly and then rapidly.)
Audio System ......... 6-17 Used ..........6-157 Antenna ..........6-17 Safety Certification ......6-157 Operating Tips for Audio System ..6-17 Mazda Bluetooth Hands-Free Customer Service ..........6-158 Audio Set (Type A) ......6-27 Audio Set (Type B) ......6-37 í...
Lack of refrigerant snow and ice from the hood and the air may make the air conditioner less inlet in the cowl grille to improve the efficient. Consult an Authorized Mazda system efficiency. Dealer for refrigerant inspection. qFoggy Windows...
Page 245
Interior Comfort Climate Control System qSunlight/Temperature Sensor The fully automatic air conditioner function measures inside and outside temperatures, and the intensity of direct sunlight. It then sets temperatures inside the passenger compartment accordingly. CAUTION Do not obstruct either sensor, otherwise the automatic air conditioner will not operate properly.
Interior Comfort Climate Control System Vent Operation (Front) Open Close qAdjusting the Vents Directing airflow You can direct air flow by moving the adjustment knob. Opening/closing vents The two outside vents can be opened and closed with wheel. NOTE When using the air conditioner, mist may come out from the vents. This is not a sign of trouble but a result of humid air being suddenly cooled.
Page 247
Interior Comfort Climate Control System qSelecting the Airflow Mode Dashboard Vents Defroster and Floor Vents Defroster Vents Dashboard and Floor Vents Floor Vents...
Interior Comfort Climate Control System Fully Automatic Type Climate control information is displayed on the information display. Information display Air intake display AUTO DUAL Airflow display Mode selector display Ambient temperature /Temperature setting display (front passenger) Temperature setting display (driver) Windshield defroster switch Air intake selector Driver temperature control dial...
Page 249
Interior Comfort Climate Control System qControl Switches OFF switch AUTO switch Pressing the OFF switch shuts off the climate control system. By pressing the AUTO switch the Temperature control dial following functions will be automatically controlled in accordance with the selected set temperature: Airflow temperature Amount of airflow...
Page 250
Interior Comfort Climate Control System Fan control dial A/C switch Fast Slow The fan has seven speeds. The selected Pressing the A/C switch while the AUTO speed will be displayed. switch is turned on will turn off the air conditioning (cooling/dehumidifying Mode selector switch functions).
Page 251
Interior Comfort Climate Control System Outside air position (indicator light DUAL switch turned off) Use this position for normal conditions and defogging. WARNING Do not use the position in cold or rainy weather: Using the position in cold or rainy weather is dangerous as it will Use the DUAL switch to change the mode cause the windows to fog up.
Page 252
Interior Comfort Climate Control System 2. Use the temperature control dial to Windshield defroster switch select a desired temperature. Press the DUAL switch or turn the front passenger temperature control dial to control the set temperature individually for the driver and front passenger.
Page 253
Interior Comfort Climate Control System qWindshield Defrosting and Defogging NOTE Press the windshield defroster switch to change the mode to the interconnection mode automatically. The system does not change to the individual operation mode by pressing the DUAL switch or turning the front passenger temperature control dial.
Interior Comfort Climate Control System Vent Operation (Rear) qAdjusting the Vents Directing airflow You can direct air flow by moving the adjustment knob. NOTE When using the air conditioner, mist may come out from the vents. This is not a sign of trouble but a result of humid air being suddenly cooled.
Page 255
Interior Comfort Climate Control System qSelecting the Airflow Mode For vehicles with rear full-auto air conditioning, the airflow mode can be selected according to the purpose of use. Instrument panel Vents Floor Vents Instrument panel and Floor Vents 6-13...
Interior Comfort Climate Control System Fully Automatic Type (Rear) Front AUTO switch REAR switch Rear Mode selector display AUTO SYNC Temperature setting display Rear airflow display Temperature control Fan control switch switch OFF switch AUTO switch Mode selector switch qControl Switches AUTO switch Rear switch Press the rear switch to operate the rear air...
Page 257
Interior Comfort Climate Control System Amount of airflow Mode selector switch Selection of airflow mode OFF switch The desired airflow mode can be selected (page 6-13). Pressing the OFF switch shuts off the qOperation of Automatic Air climate control system. Conditioning Temperature control switch Operation from front seats...
Page 258
Interior Comfort Climate Control System NOTE NOTE If the AUTO switch is pressed while the If the AUTO switch is pressed while the front A/C switch is off, the rear air front A/C switch is off, the rear air conditioning operates only to circulate air. conditioning operates only to circulate air.
Interior Comfort Audio System Antenna Operating Tips for Audio System qAM/FM Radio Antenna WARNING The rear window antenna receives both AM and FM signals. Do not adjust the audio control switches while driving the vehicle: Rear window antenna Adjusting the audio while driving the vehicle is dangerous as it could distract your attention from the vehicle operation which could lead to...
Page 260
Interior Comfort Audio System qRadio Reception Signals from an FM transmitter are similar to beams of light because they do not AM characteristics bend around corners, but they do reflect. AM signals bend around such things as Unlike AM signals, FM signals cannot buildings or mountains and bounce off the travel beyond the horizon.
Page 261
Interior Comfort Audio System Flutter/Skip noise Strong signal noise Signals from an FM transmitter move in This occurs very close to a transmitter straight lines and become weak in valleys tower. The broadcast signals are between tall buildings, mountains, and extremely strong, so the result is noise and other obstacles.
Page 262
Interior Comfort Audio System qOperating Tips for CD Player/In- The CD revolves at high speed within the unit. Defective (cracked or badly Dash CD Changer bent) CDs should never be used. Condensation phenomenon Immediately after turning on the heater when the vehicle is cold, the CD or optical components (prism and lens) in the CD player/In-dash CD changer may become clouded with condensation.
Page 263
Interior Comfort Audio System A new CD may have rough edges on The CD player/In-dash CD changer has its inner and outer perimeters. If a disc been designed to play CDs bearing the with rough edges is used, proper identification logo as shown below. No setting will not be possible and the CD other discs can be played.
Page 264
Interior Comfort Audio System Do not use record sprays, antistatic Completely read the instruction manual agents, or household spray cleaners. and cautions for CD-R/CD-RWs. Volatile chemicals such as benzine and Do not use discs with cellophane tape thinner can also damage the surface of adhering, partially peeled off labels, or the CD and must not be used.
Page 265
Interior Comfort Audio System This unit can play MP3s with sampling frequencies of 16/22.05/24/32/44.1/48 Folder : Folder : Track (File) kHz. This unit can play MP3 files that have been recorded in bit rates of 8 kbps to 320 kbps. Nonetheless, to insure enjoyment of music with consistent sound quality, it is recommended to use discs that have been recorded at a bit...
Page 266
Interior Comfort Audio System The maximum number of characters Specialized glossary that can be used for file names is as follows. However, this unit will only Abbreviation for MPEG Audio Layer 3 . display up to 32 characters, including A technical standard for audio the file extension (.mp3).
Page 267
Interior Comfort Audio System Bit rate Playable WMA file specification Refers to the volume of data per second, CD-R and CD-RW including WMA files expressed in bps (bits per second). can be played with this unit. Discs which Generally, the larger the number of the conform to the following formats can be transfer bit rate when compressing an played.
Interior Comfort Audio System Audio Set (Type A) Audio information is displayed on the information display. Power/Volume/Sound Controls ................page 6-28 Operating the Radio ....................page 6-30 Operating the Compact Disc (CD) Player .............. page 6-32 Operating the Auxiliary jack .................. page 6-35 Error Indications .....................
Page 270
Interior Comfort Audio System qPower/Volume/Sound Controls Power/Volume dial Audio control dial Power ON/OFF Audio sound adjustment Turn the ignition switch to the ACC or 1. Press the audio control dial to select the ON position. function. The selected function will be indicated.
Page 271
Interior Comfort Audio System 2. Turn the audio control dial to adjust the Select the desired ALC mode. selected functions as follows: Mode Volume change Indication Turn Left Turn Right No change Select mode Minimum Decrease Increase bass bass Medium Decrease Increase treble...
Page 272
Interior Comfort Audio System qOperating the Radio Scan button Band selector button Manual tuning dial/Auto memory button Seek tuning Channel preset buttons buttons Radio ON Tuning Press a band selector button ( ) to The radio has the following tuning turn the radio on.
Page 273
Interior Comfort Audio System NOTE Press and hold the auto memory button ) for about 2 seconds until a beep If you continue to press and hold the button, sound is heard; the system will the frequency will continue changing without automatically scan and temporarily store stopping.
Page 274
Interior Comfort Audio System qOperating the Compact Disc (CD) Player Load button Folder up button Track up/Fast- CD eject button forward button Random button Scan button CD slot Repeat button Folder down button CD play button Track down/ Reverse button Power/Volume dial Display feed dial Ejecting the CD...
Page 275
Interior Comfort Audio System Fast-forward/Reverse Repeat playback Press and hold the fast-forward button During music CD playback ( ) to advance through a track at high 1. Press the repeat button ( ) during speed. playback to play the current track Press and hold the reverse button ( ) to repeatedly.
Page 276
Interior Comfort Audio System During MP3 CD playback MP3 CD (Folder random) 1. Press the random button ( ) during playback to play the tracks in the folder File number/Elapsed randomly. FOLDER RDM is time display displayed. 2. To cancel the random playback, press Folder number/File the button again after 3 seconds.
Page 277
CD for damage, dirt, or smudges, and then properly reinsert. If the message appears again, take the unit to an Authorized Mazda Dealer for service. qOperating the Auxiliary jack You can connect portable audio units or similar products on the market to the...
Page 278
Interior Comfort Audio System qError Indications If you see an error indication on the display, find the cause in the chart. If you cannot clear the error indication, take the vehicle to an Authorized Mazda Dealer. Indication Cause Solution Insert the CD properly. If the error indication continues CD is inserted upside down to display, consult an Authorized Mazda Dealer.
Interior Comfort Audio System Audio Set (Type B) Functions and information available for the selected mode are displayed on the left and right of the audio unit screen. To select and operate a desired function, or select information, press the corresponding selection button 1 8. Selection Selection button 1...
Page 280
Interior Comfort Audio System qScreen Adjustments and Other Settings Selection Selection button 1 button 5 Selection Selection button 2 button 6 Selection Selection button 3 button 7 Selection Selection button 4 button 8 Display button Press the display button ( ) to Decrease brightness display the tone adjustment screen.
Page 281
Interior Comfort Audio System NOTE Color adjustment A language setting is unavailable for the To deepen a color satellite radio. English is constantly displayed. Press selection button 7. Screen display off To fade color Press selection button 4. Press selection button 3. Press the display button ( ) to * Adjustment is available depending on...
Page 282
Interior Comfort Audio System qPower/Volume/Sound Controls Selection Selection button 1 button 5 Selection Selection button 2 button 6 Selection Selection button 3 button 7 Selection button 8 Power/Volume dial Audio control button Power ON/OFF Audio sound adjustment Turn the ignition switch to the ACC or When the audio control button ON position.
Page 283
Interior Comfort Audio System Press selection button 8. NOTE Continuous adjustment of the bass, treble, Setting item Setting value fader, and balance can be done by long- Bass Down pressing the selection button for each Treble Down adjustment item. Fader Rear Front Balance...
Page 284
Interior Comfort Audio System ® Centerpoint Surround Volume down Press selection button 6. Press selection button 2. ® NOTE Centerpoint Surround Volume adjustment is available if Press selection button 2. ® Centerpoint or Rear Seat Surround is on. NOTE ® Centerpoint operates optimally with a 2- channel stereo CD.
Page 286
Interior Comfort Audio System qOperating the Radio Band selector button Selection Selection button 2 button 5 Selection Seek tuning button 6 buttons Selection Selection button 7 button 3 Selection Selection button 4 button 8 Scan button Manual tuning dial Mute button Auto memory button Radio ON Tuning...
Page 287
Interior Comfort Audio System NOTE Press and hold the auto memory button ). The system will automatically If you continue to press and hold the seek scan and temporarily store up to six tuning button ( ), the frequency will stations with the strongest frequencies in continue changing without stopping.
Page 288
Interior Comfort Audio System NOTE If any of the following operations is performed, the radio text information display is cleared and the normal display appears. Return button ( ) is pressed Band selector button ( ) is pressed Manual tuning dial is turned Seek tuning button ( ) is pressed 6-46...
Page 290
Interior Comfort Audio System qOperating the Satellite Radio Selection Selection SIRIUS button button 3 button 8 Selection Selection button 4 button 7 Selection Selection button 5 button 1 Selection Selection button 2 button 6 Category up button Seek tuning buttons Category down button Scan button...
Page 291
Interior Comfort Audio System NOTE What is satellite radio? This equipment has been tested and found to With over 130 channels, SIRIUS Satellite comply with the limits for a Class B digital Radio brings you more of what you love. device, pursuant to Part 15 of the FCC Rules.
Page 292
Interior Comfort Audio System SIRIUS service uses an ID code to When the SIRIUS button ( ) is identify your radio. This code is needed to pressed in a mode other than the SIRIUS activate SIRIUS service, and report any mode, the last channel in use will be problems.
Page 293
Interior Comfort Audio System Updating channels XXX% complete is Unsubscribed channel displayed when the SIRIUS channel map When a selected station has not been is changed. If the Updating channels subscribed to, the display indicates the XXX% complete display is not available, following: Updating channels is displayed.
Page 294
Interior Comfort Audio System NOTE Category up Press the category up button ( Unsubscribed channels, invalid channels, Category down parental lock channels and channel 0 are Press the category down button ( not subject to the scan, therefore these Every time the category up button ( ) is channels will skip automatically.
Page 295
(If the SIRIUS ID (ESN) for the tuner button is being pressed. does not display) When the seek tuning button ( ) is pressed, playback starts from the If ESN Fail is displayed, contact an beginning of the next program. Authorized Mazda Dealer. 6-53...
Page 296
Interior Comfort Audio System Parental lock (Registered ID code input confirmation) Parental lock, parental lock ID change, parental unlock, and parental lock ID reset 6. After inputting the four digits, turn the can be set. manual tuning dial and select OK , and then press the enter button NOTE ) to confirm the four digits.
Page 297
Interior Comfort Audio System 6. If the four digits match the registered 4. Enter Pin and - - - - are displayed, ID code, Enter Pin and - - - - are and input of the registered ID code is displayed.
Page 298
Interior Comfort Audio System NOTE Master code: The Master Code is used to initialize or re- initialize the ID code in the event that the code is not set to [0000] and/or the personalized ID code is not known. The initialization process resets the ID code to [0000].
Page 300
Interior Comfort Audio System qOperating the In-Dash CD Changer Selection Selection button 3 button 8 Selection Selection Load button CD play button CD eject button button 4 button 7 Selection Selection button 5 button 1 Selection Selection button 2 button 6 Track up Folder up button...
Page 301
Interior Comfort Audio System NOTE Multiple CD insertion If the button is not pressed and about five 1. Press and hold the load button ( seconds have elapsed while Disc Ejecting is 2. Press the load button ( ) again. displaying, CDs are automatically ejected.
Page 302
Interior Comfort Audio System NOTE NOTE If the entire title cannot be displayed, ... is Press and hold the ( ) or ( ) button to added at the end to the part of the title which continuously move up or down through the can be displayed.
Page 303
If the message appears playback to play the tracks in the again, take the unit to an Authorized current folder repeatedly. Mazda Dealer for service. Repeat Folder is displayed. qOperating the Auxiliary Jack 2. Press selection button 1 again to cancel the repeat playback.
Page 304
Interior Comfort Audio System qError Indications If you see an error indication on the display, find the cause in the chart. If you cannot clear the error indication, take the vehicle to an Authorized Mazda Dealer. Indication Cause Solution Depending on the...
The talk button, pick-up button, and hang- up button are operable with the audio unit turned off. Mazda has installed this system to prevent distraction while driving the vehicle and using audio controls on the dashboard. Always make safe driving your first priority.
Page 306
Interior Comfort Audio System Without Bluetooth Hands-Free and Without Bluetooth Hands-Free and navigation system navigation system With Bluetooth Hands-Free only/ With Bluetooth Hands-Free only/ Bluetooth Hands-Free and navigation Bluetooth Hands-Free and navigation system system qChanging the Source (Type A) Press the mode switch ( ) to change the audio source (FM1 radio →...
Page 307
Interior Comfort Audio System NOTE With Bluetooth Hands-Free only/ Bluetooth Hands-Free and navigation CD, CD changer, RSES, SIRIUS digital system satellite radio, and BT audio modes cannot be selected in the following cases: · RSES, SIRIUS digital satellite radio unit, or BT audio unit is not equipped on the audio system.
Interior Comfort Audio System í qMute Switch AUX Mode (Auxiliary í Press the mute switch ( ) once to mute input) audio, press it again to resume audio output. You can connect portable audio units or similar products on the market to the NOTE auxiliary jack to listen to music or audio If the ignition is turned off (LOCK) with the...
Page 309
Interior Comfort Audio System 2. Pass the connection plug cord through CAUTION the cutout of the console and insert the Ø Close the lid when the auxiliary plug into the auxiliary jack. jack is not in use to prevent foreign objects and liquids from penetrating the auxiliary jack.
Page 310
Interior Comfort Audio System 2. Press the power/volume dial to turn the audio system on. 3. (Type A) Press the AUX button ( ) of the audio unit or the mode switch ( of the audio control switches on the steering wheel to change to the AUX mode.
Ø This CD player should not be adjusted or repaired by anyone except qualified service personnel. If servicing is required, contact an Authorized Mazda Dealer. Ø Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous laser exposure. Never operate the CD player with the top case of the unit removed.
Interior Comfort Rear Entertainment System í Rear Entertainment System Monitor screen release knob DISC IN indicator light Disc slot Eject button Wireless headphone signal transmitter/Remote Monitor screen control signal receiver qRear Entertainment System Outline The Rear Entertainment System has a 9.0-inch wide LCD, as well as DVD video, DVD audio, video CD, audio CD, and MP3/WMA CD playback functions.
Page 313
If any problem occurs, such as a foreign material penetration, spilled liquid, smoking from internal burning, or other abnormal smells, stop operation immediately and consult an Authorized Mazda Dealer. If operation is continued, it may cause an accident, fire, or electrical shock.
Page 314
Interior Comfort Rear Entertainment System qOperating Tips for Disc Playable discs DVD video , DVD audio , video CD, audio CD, CD-R, CD-RW, DVD-R, DVD-RW and dts CD can be played. NOTE It may not be possible to play DVD video, DVD audio, video CD, audio CD, and MP3/WMA CD according to the procedures indicated in these instructions if the playback conditions have been restricted by the producer.
Page 315
Interior Comfort Rear Entertainment System DVD video DVD videos bearing the following logo can be played. DVD audio DVD audio bearing the following logo can be played. ●Region code must include 1 or ALL . ●NTSC (National Television System Committee) recorded type.
Page 316
Interior Comfort Rear Entertainment System DVD-ROM, DVD-RAM, DVD+RW, CD-ROM, CDV, CD-G, CVD, VSD, SVCD, SACD, photo CDs, non-conventional discs (e.g. heart-shaped), and partially transparent discs. Discs recorded in CD-TEXT format. HD DVD and Blu-ray discs Handling of discs Do not use non-conventional discs such as heart-shaped, octagonal discs, or discs with a memory portion that is transparent or translucent.
Page 317
Interior Comfort Rear Entertainment System Disc cleaning Do not use record sprays, antistatic agents, or household spray cleaners. Volatile chemicals such as benzine and thinner can also damage the surface of the disc and must not be used. Anything that can damage, warp or fog plastic should never be used to clean discs. Condensation Immediately after turning on the heater when the vehicle is cold, the disc or optical components (prism and lens) in the unit may become clouded with condensation.
Page 318
Interior Comfort Rear Entertainment System Playable DISC specification CD-R and CD-RW including MP3/WMA files can be played with this unit. Discs which conform to the following formats can be played. Name Standard Explanation Level 1 ISO9660 Level 2 CD-R, CD-RW format Joliet ISO9660 extension Romeo...
Page 319
Interior Comfort Rear Entertainment System This unit corresponds to multi-session recorded disc playback at a maximum of 49 sessions. Some data on multi-session recorded discs cannot be played. Playback of discs with added sessions is possible. Packet Write recorded discs cannot be played. This unit does not correspond to MP3i (MP3 interactive), MP3 PRO, and RIFF-style MP3 formats.
Page 320
Interior Comfort Rear Entertainment System Playable WMA file specification CD-R and CD-RW including WMA files can be played with this unit. Discs which conform to the following formats can be played. Playable WMA files are as follows: Item Content Specification Windows Media Audio Version7.0 22.05kHz .
Page 321
Interior Comfort Rear Entertainment System Operating tips for dts DTS and DTS Digital Surround are registered trademarks of Digital Theater Systems, Inc. qOperation Tips for Headphones To listen to audio other than from the speakers of the Rear Entertainment System, it is necessary to use the wireless headphones that are included.
Interior Comfort Rear Entertainment System Part Names qRear Entertainment System Main Unit Monitor screen release knob DISC IN indicator light Disc slot Eject button Wireless headphone signal transmitter/Remote Monitor screen control signal receiver 6-80...
Page 323
Interior Comfort Rear Entertainment System qRemote Controller Name Name RETURN button PLAY button MENU button Slow playback button ENTER/Select button POWER button STOP button SOURCE button PAUSE button Picture adjust mode button Fast-forward button Picture adjust button Rewind button SET UP button PREVIOUS (Track down) button Number keys NEXT (Track up) button...
Page 324
Interior Comfort Rear Entertainment System qHeadphone Power button Volume dial Power indicator L (left) side R (right) side Infrared receiver 6-82...
Interior Comfort Rear Entertainment System Before Operation qDisplay Opening/Closing NOTE If the display is closed while the power is CAUTION on, it automatically turns off. The display locks in two positions when Ø Close the display while the Rear opened to 100 or 120-degrees. Entertainment System is not in use.
Page 326
Interior Comfort Rear Entertainment System NOTE Inserting the disc When the eject button is pressed, the disc is Insert the disc into the disc slot with the ejected halfway. label-side up. A disc can be ejected with the Rear Entertainment System turned off. qPicture Adjustment The brightness (BRIGHT), color adjustment (TINT), color density...
Page 327
Interior Comfort Rear Entertainment System Picture adjust button ( ): Darken Picture adjust button ( ): Lighten Adjusting the color adjustment Adjusting the contrast (definition) 1. Press the picture adjustment mode 1. Press the picture adjustment mode button (PICTURE) and select the TINT button (PICTURE) and select the mode.
Page 328
Interior Comfort Rear Entertainment System Full screen Cinema screen Image is displayed on the full screen. The image is enlarged upward and downward. A 4:3 and 16:9 screen ratio image are displayed with the upper/lower part of the image cut off. NOTE Because images are enlarged lengthwise for display, a horizontal streak may be seen,...
Page 329
Interior Comfort Rear Entertainment System qRemote Controller Using the remote controller A battery has already been installed in the Operate the Rear Entertainment System remote controller. with the remote controller except for disc Remove the electrical leak-protection insertion/ejection. insulation sheet before using the remote CAUTION controller.
Page 330
Battery (CR2025 LITHIUM or equivalent) 3. Press the battery case tab in the direction of the arrow until a click sound is heard. NOTE If the remote controller is inoperable even after the batteries are replaced, consult an Authorized Mazda Dealer. 6-88...
Interior Comfort Rear Entertainment System Sound Output qSound Output from Vehicle Speakers Vehicles with audio system Change the audio system to the Rear Entertainment System mode. Sound/Music being played by the Rear Entertainment System can be heard from the vehicle speakers. For audio operation, refer to Audio System (page 6-17).
Page 332
Interior Comfort Rear Entertainment System NOTE To listen to audio other than from the speakers of the rear entertainment system, it is necessary to use the wireless headphones that are included. For headphone specification, refer to Operation Tips for Headphones (page 6-79). When the headphones are not in use, turn them off.
Page 333
Interior Comfort Rear Entertainment System When the wireless headphone receiver does not point to the Rear Entertainment System transmitter. When the signal is blocked by an obstruction such as the seat. Replacing the battery 1. Remove the screw using a coin or equivalent, and remove the cover. Remove the batteries.
Page 334
Interior Comfort Rear Entertainment System CAUTION Ø If the battery power is depleted the headphones will not operate properly. If any of the following occurs, replace the batteries. Ø The power indicator does not illuminate even when the power is turned on. Ø...
Interior Comfort Rear Entertainment System Rear Entertainment System Functions qMode The Rear Entertainment System has Disc and AUX modes. Mode Function Page DVD video, video CD, DVD audio, and audio CD can be Disc mode 6-94 played. AV equipment with output terminals for image and sound, AUX (Auxiliary) mode such as a video game player and a video camera, can be 6-108...
Interior Comfort Rear Entertainment System qBasic Operation DVD video, DVD audio, Video CD, Audio CD and Power ON/OFF MP3/WMA CD Playback Turning on the power (Disc Mode) The Rear Entertainment System automatically turns on when any of the DVD video, DVD audio, Video CD, following operations are done with the Audio CD, and MP3/WMA CD can be ignition switch in the ACC or ON...
Page 337
Interior Comfort Rear Entertainment System 2. Insert the disc into the disc slot. NOTE After the disc is inserted, the playback If the RETURN button is pressed after the starts. playback has been stopped, the resume playback function is canceled. Once the CAUTION resume playback function is canceled, the playback starts from the first chapter (DVD...
Page 338
Interior Comfort Rear Entertainment System Fast-forward skip Skipping to desired title/group Press the NEXT button ( ) to skip to The playback can be started from the the next chapter/track. desired title/group by entering the title/ group number. Reverse skip 1.
Page 339
Interior Comfort Rear Entertainment System 2. Press the ENTER button to change the Displaying/selecting top menu/disc display to the password input screen, menu then enter the password. 1. To display the top menu on the screen, For the password, see the instruction press the MENU button while the disc manual attached to the disc.
Page 340
Interior Comfort Rear Entertainment System NOTE For audio CD, the function menu is DVD audio function menu automatically displayed when playback is started. Language (sound and subtitles) selection (DVD video and DVD audio) Sound and subtitles can be changed to the desired language.
Page 341
Interior Comfort Rear Entertainment System 2. Move the cursor to the subtitle ON/ 2. Move the cursor to the display angle OFF mode by operating the select change mode by operating the select button to the left or right. button to the left or right. 3.
Page 342
Interior Comfort Rear Entertainment System 3. Set the sound output to the desired 3. Select the desired mode by operating balance by operating the select button the select button up or down. up or down. (1) During DVD audio: Press the button and the settings Each time the button is pressed, the changes in the order of L+R →L →R.
Page 343
Interior Comfort Rear Entertainment System For example, the folder numbers for Folder/File information display folders (1), (3), and (5) in the figure are window not displayed because they do not Display mode contain MP3/WMA files. Folders and files in a hierarchy are played in the order that they are recorded on the disc by the writing software.
Page 344
Interior Comfort Rear Entertainment System 2. Change the display mode by operating While in TREEIDX display mode the select button up or down. 1. Move the cursor to the folder/file information display window by Display Playback mode operating the select button to the left or All files are played repeatedly.
Page 345
Interior Comfort Rear Entertainment System qInitial Setting Function 3. Press the ENTER button. The selected menu is highlighted to indicate that the The settings set in the initial setting menu is selected. function remain after the unit is turned off or the disc is changed.
Page 346
Interior Comfort Rear Entertainment System 5. Press the ENTER button. The Changing to a language other than highlighted color returns to the English and Japanese previous color to indicate that the NOTE selected item is set. Languages other than English and Japanese can be set by entering the language code in the language code list.
Page 347
Interior Comfort Rear Entertainment System Viewing can be restricted by setting the Changing the Rating setting parent lock level. 1. Enter the password by pressing the For example, if the level is set to 6, level 7 number keys (0 to 9) or operating the or higher viewing is locked and cannot be select button up or down.
Page 348
Interior Comfort Rear Entertainment System 3. Enter the country code by pressing the Country change number keys (0 to 9) or operating the NOTE select button up or down. It is necessary to set the country code because the parent lock level is different depending on the country.
Page 349
Interior Comfort Rear Entertainment System Mark The DVD video playback status and angle display on/off, and priority of the inserted discs can be set. 3. Enter the new password by pressing the number keys (0 to 9) or operating the select button up or down.
Interior Comfort Rear Entertainment System NOTE Auxiliary Input (AUX mode) The display angle change is not available for discs other than multi-angle recorded In AUX mode, AV equipment such as a DVD discs. Refer to the instruction manual video game player or a video camera can accompanying the disc for details.
Page 351
Interior Comfort Rear Entertainment System Auxiliary terminals WARNING The auxiliary terminals consist of one Ø Never use medical instruments image input terminal and two sound input with the power outlet. terminals (for left and right). Ø Follow the cautions below to Image input terminal: Yellow prevent electrical shock.
Page 352
Interior Comfort Rear Entertainment System 2. Lightly insert the plug and turn the NOTE outlet 90 degrees, then insert it fully. The following electrical appliances may not operate even if their electrical capacity is 100 W or less. POWER OUTLET Appliances requiring large amounts of power for activation (such as cathode-ray tube televisions, refrigerators with a...
Page 353
Interior Comfort Rear Entertainment System 1. Turn the ignition switch to the LOCK 5. Press the SOURCE button and select position. the AUX mode. Refer to Mode on page 6-93. 2. If a power supply is necessary, connect the outlet to the power outlet. Refer to Power outlet on page 6-108.
Page 354
Interior Comfort Rear Entertainment System Language Code List Language Code Language Code Abkhazian 1001 Greek 1411 Afar 1000 Greenlandic 2011 Afrekaans 1005 Guarani 1613 Albanian 2816 Gujarati 1620 Amharic 1012 Hausa 1700 Arabic 1017 Hebrew 1822 Armenian 1724 Hindi 1708 Assamase 1018 Hungarian...
Page 355
Interior Comfort Rear Entertainment System Language Code Language Code Nauru 2300 Tigrinya 2908 Nepali 2304 Tonga 2914 Norwegian 2314 Tsonga 2918 Occtian 2402 Tukmen 2910 Oriya 2417 Turkish 2917 Oromo 2412 2922 Panjabi 2500 Ukrainian 3010 Pashto, Pushto 2518 Urdu 3017 Persian 1500...
Page 356
Interior Comfort Rear Entertainment System Country Code List Country Code Country Code Afghanistan 1005 Cape Verde 1221 Albania 1011 Cayman Islands 2024 Algeria 1325 Central African Republic 1205 American Samoa 1018 Chad 2903 Andorra 1003 Chile 1211 Angola 1014 China 1213 Anguilla 1008...
Page 357
Interior Comfort Rear Entertainment System Country Code Country Code French Southern Territories 2905 Lao People's Democratic 2100 Gabon 1600 Latvia 2121 Gambia 1612 Lebanon 2101 Georgia 1604 Lesotho 2118 Germany 1304 Liberia 2117 Ghana 1607 Libyan Arab Jamahiriya 2124 Gibraltar 1608 Liechtenstein 2108...
Page 358
Interior Comfort Rear Entertainment System Country Code Country Code Nigeria 2306 South Africa 3500 Niue 2320 South Georgia and the South 1618 Sandwich Islands Norfolk Island 2305 Spain 1418 Northern Mariana Islands 2215 Sri Lanka 2110 Norway 2314 Sudan 2803 Oman 2412 Suriname...
Page 359
Interior Comfort Rear Entertainment System Country Code Wallis and Futuna Islands 3205 Western Sahara 1407 Yemen 3404 Yugoslavia 3420 Zaire See Congo, The 3517 Democratic Republic of the Zambia 3512 Zimbabwe 3522 6-117...
Interior Comfort Rear Entertainment System Error Message qMessage Incorrect region code An error message is displayed if a disc Disc mode error message other than one with region code 1 or Use of Non-supported Disc including region 1 is inserted. An error message is displayed if a non- supported DVD-ROM disc, a non- supported disc format or a disc (PAL,...
Page 361
Interior Comfort Rear Entertainment System System errors (Common to each mode) Power malfunction An error message is displayed if the power supply to the rear entertainment system drops (About 9.5 V or less), and the power is turned off. The power is restored when the power supply to the rear entertainment system is 10 V or more.
If any malfunction is suspected, verify the following before requesting a repair. If the problem cannot be solved after performing the procedure, have the system inspected at an Authorized Mazda Dealer. Some functions are not available depending on the disc. Read the instruction manual attached to the disc before operating.
Page 363
Interior Comfort Rear Entertainment System Symptom Cause Action Audio output from DTS format language is selected and vehicle played back. Select audio other than DTS format. speakers but (The wireless headphones cannot play- not from back DTS format language) headphones The disc is dirty.
Page 364
Interior Comfort Rear Entertainment System Symptom Cause Action headphones' optical The headphones' batteries are weak. Replace the batteries with new ones. reception range is too narrow. There is excessive noise in the The headphones' batteries are weak. Replace the batteries with new ones. headphone audio 6-122...
Page 365
Interior Comfort Bluetooth Audio (Type B) í Bluetooth Audio (Type B) Selection AUX button button 1 Track up Selection button button 5 Selection Selection button 6 button 2 Selection Selection button 3 button 7 Track down button Play/Pause button Manual tuning dial/Enter switch Selection Return button button 4...
A2DP is a profile which transmits only audio devices can be used, consult audio to the Bluetooth unit. If your an Authorized Mazda Dealer when Bluetooth audio device corresponds only purchasing or changing devices. to A2DP, but not AVRCP, you cannot...
Interior Comfort Bluetooth Audio (Type B) Bluetooth is the registered trademark of NOTE Bluetooth SIG. Inc. Always perform Bluetooth audio device programming while the vehicle is stopped. NOTE Programming cannot be performed while It may not be possible to play a Bluetooth the vehicle is moving.
Page 368
Interior Comfort Bluetooth Audio (Type B) 7. When the pairing programming is Programming a Bluetooth audio device completed, a symbol and which has a PIN code (four digits) Pairing complete are displayed, and 1. Press selection button 2 to display the then the display returns to the normal Bluetooth audio setting menu screen.
Page 369
Interior Comfort Bluetooth Audio (Type B) 6. The Bluetooth audio device will Changing the link to only a Bluetooth request input of a PIN code. Input audio device 0000 . 1. Press selection button 2 to display the 7. When the pairing programming is Bluetooth audio setting menu screen.
Page 370
Interior Comfort Bluetooth Audio (Type B) 3. Press selection button 1, 2, 3, 4, 5, 6, or 3. Press selection button 1, 2, 3, 4, 5, 6, or 7 to select the name of the device you 7 to select the name of the device you would like to change.
Page 371
Interior Comfort Bluetooth Audio (Type B) NOTE NOTE If the device name and Bluetooth address If the Bluetooth audio device does not begin cannot be displayed, ... is added at the end playback, press the Play/Pause button to the part of the title which can be displayed. If the mode is switched from Bluetooth qHow to Use the Bluetooth Audio audio mode to another mode (radio mode),...
Page 372
Interior Comfort Bluetooth Audio (Type B) File (track) search File (track) up Press the track up button ( ) or turn the file dial clockwise. File (track) down Press the track down button ( ) or turn the file dial counterclockwise. Fast-forward/Reverse (only AVRCP Ver.
Page 373
Bluetooth devices (Mobile phone) are Performing phonebook registration some which will not connect with while driving the vehicle could be a your Mazda or will have limited distraction to your driving and result function. Therefore, consult Mazda in an accident. In addition, a mistake...
Interior Comfort Bluetooth Hands-Free (Voice Recognition) OPP (Object Push Profile) Ver. 1.1 Talk button, Pick-Up button and Hang- Up button Basic functions of Bluetooth Hands-Free can be used for such things as making calls or hanging up using the talk button, pick-up button and hang-up button on the steering wheel.
Page 375
Interior Comfort Bluetooth Hands-Free (Voice Recognition) qVoice Information display (Type A/ Navigation system) To prevent the deterioration in voice When available, the information display recognition rate and voice quality, the shows telephone numbers, Bluetooth following points must be observed: Hands-Free messages, and operation It is not necessary to face the status.
Interior Comfort Bluetooth Hands-Free (Voice Recognition) NOTE Bluetooth Hands-Free Activation Method If the voice recognition performance is not satisfactory, refer to Voice Recognition Press the pick-up button (with/without Learning Function (Speaker Enrollment) navigation system) or talk button with a (page 6-154). short press (without navigation system) or a long press (with navigation system).
Page 377
Interior Comfort Bluetooth Hands-Free (Voice Recognition) NOTE Voice guidance interrupt operation For vehicles with the navigation system, you Voice guidance can be skipped by can also press the talk button with a short pressing the talk button with a short press press and say: [Beep] Telephone or while it is being heard.
Interior Comfort Bluetooth Hands-Free (Voice Recognition) 3. (Type A) Basic Bluetooth Hands- Prompt: Select one of the following: Free Operation Pairing options, confirmation prompts, language, passcode, or select phone. qBluetooth Hands-Free Preparation (Type B/Navigation system) Prompt: Select one of the following: Language setting Pairing options, confirmation prompts, The available languages are English,...
Page 379
Interior Comfort Bluetooth Hands-Free (Voice Recognition) 2. Say: [Beep] French (Say the desired NOTE language: English , French , or A device can be programmed only when the Spanish .) (Change the desired vehicle is parked. If the vehicle starts to language by saying the language move, the pairing procedure will end.
Page 380
For the operation of the device, refer to its Pairing options, confirmation prompts, instruction manual. language, passcode, or select phone. 15. Select Mazda from the device list (Type B/Navigation system) searched by the device. Prompt: Select one of the following: Pairing options, confirmation prompts, 16.
Page 381
Interior Comfort Bluetooth Hands-Free (Voice Recognition) NOTE 8. Prompt: Dialing (Type B/Navigation system) (Type B/Navigation system) Device registration can also be done by operating the panel buttons on the 1. Press the pick-up button (with/without navigation unit. Refer to Bluetooth Audio navigation system) or talk button with Preparation (page 6-125) (For audio unit) a short press (without navigation...
Page 382
Interior Comfort Bluetooth Hands-Free (Voice Recognition) qVolume Adjustment NOTE The Dial command and a telephone number The power/volume dial of the audio unit can be combined. or the navigation system is used to adjust Ex. In Step 2, say, Dial 123-4567 , then, the volume.
Interior Comfort Bluetooth Hands-Free (Voice Recognition) 12. Say: [Beep] Yes Convenient Use of the 13. Prompt: Number, please. Hands-Free System 14. Say: [Beep] XXXXXXXXXXX qPhonebook Usage (Ex. 555-1234 ) (Say the phone number to be registered.) Phonebook registration 15. Prompt: XXXXXXXXXXX (Ex. Phone numbers can be registered to the 555-1234 ) (Phone number Bluetooth Hands-Free phonebook.
Page 384
Interior Comfort Bluetooth Hands-Free (Voice Recognition) 6. Say: [Beep] XXXXX... (Ex. Mary's 17. Prompt: Number saved. Would you phone ) (Say a voice tag for the name like to add another number for this registered.) entry? 7. Prompt: Adding XXXXX... (Ex. 18.
Page 385
Interior Comfort Bluetooth Hands-Free (Voice Recognition) 7. Prompt: X (Number of locations 3. Prompt: Name please. which include data) numbers have been 4. Say: [Beep] XXXXX... (Ex. John's imported. What name would you like phone ) (Say a voice tag registered in to use for these numbers? the phonebook.) 8.
Page 386
Interior Comfort Bluetooth Hands-Free (Voice Recognition) qEmergency Calls qTransferring a Call A call can be made to the emergency Transferring a call from Hands-Free to phone number (911) using the voice input a device (Mobile phone) command. Communication between the hands-free unit and a device (Mobile phone) is 1.
Page 387
Interior Comfort Bluetooth Hands-Free (Voice Recognition) 3. Prompt: Swapping calls 7. When Yes is spoken, the procedure proceeds to Step 8. NOTE When No is spoken, the procedure To refuse an incoming call, press the hang- returns to Step 3. up button.
Page 388
Interior Comfort Bluetooth Hands-Free (Voice Recognition) 1. Press the pick-up button (with/without NOTE navigation system) or talk button with If there was no previous phone number a short press (without navigation registered to a location (Ex. Work ), the system) or a long press (with prompt will only read out Number, please .
Page 389
Interior Comfort Bluetooth Hands-Free (Voice Recognition) 5. Prompt: Please say the name of the 4. Say: [Beep] Erase all entry you would like to delete or say, 5. Prompt: Are you sure you want to List names . erase everything from your Hands Free 6.
Page 390
Interior Comfort Bluetooth Hands-Free (Voice Recognition) 5. Prompt: XXXXX..., XXXXX..., 2. Say: [Beep] XXXX... send (Say XXXXX... (Ex. John's phone , Mary's DTMF code) phone, Bill's phone) (Voice guidance 3. Prompt: Sending XXXX... (DTMF reads out the voice tags registered to code) the phonebook.) Press the talk button with a short press...
Interior Comfort Bluetooth Hands-Free (Voice Recognition) 5. Prompt: Select one of the following: Hands-Free Setting Pair, edit, delete, or list. qDevice 6. Say: [Beep] List Device registration 7. Prompt: XXXXX..., XXXXX..., XXXXX... (Ex. Device A, device B, For the registration of a Bluetooth device C) (The voice guidance reads equipped device to Bluetooth Hands-Free, out the device tags registered to the...
Page 392
Interior Comfort Bluetooth Hands-Free (Voice Recognition) 8. Say: [Beep] Yes Device selection If several devices have been programmed, 9. Prompt: XXXXX... (Ex. device B...) the Bluetooth unit links the device last (Device tag) will temporarily override programmed. If you would like to link a phone priorities, returning to main different programmed device, it is menu.
Page 393
Interior Comfort Bluetooth Hands-Free (Voice Recognition) NOTE NOTE A registered device (Mobile phone) can be (Type B) Device (Music player) selection can also be deleted using the registration list. done by operating the panel button (page 6. Say: [Beep] Delete 6-125).
Page 394
Interior Comfort Bluetooth Hands-Free (Voice Recognition) 3. (Type A) Passcode setting Prompt: Select one of the following: 1. Press the pick-up button (with/without Pairing options, confirmation prompts, navigation system) or talk button with language, passcode, or select phone. a short press (without navigation (Type B/Navigation system) system) or a long press (with Prompt: Select one of the following:...
Page 395
Interior Comfort Bluetooth Hands-Free (Voice Recognition) 2. Say: [Beep] Setup Using Bluetooth Hands-Free with a passcode 3. (Type A) 1. Press the pick-up button (with/without Prompt: Select one of the following: navigation system) or talk button with Pairing options, confirmation prompts, a short press (without navigation language, passcode, or select phone.
Page 396
Interior Comfort Bluetooth Hands-Free (Voice Recognition) qVoice Recognition Learning 1. Press the pick-up button (with/without navigation system) or talk button with Function (Speaker Enrollment) a short press (without navigation The voice recognition learning function system) or a long press (with enables voice recognition appropriate to navigation system).
Page 397
Interior Comfort Bluetooth Hands-Free (Voice Recognition) 3. Prompt: This operation must be 3. Prompt: Enrollment is enabled/ performed in a quiet environment while disabled. Would you like to disable/ the vehicle is stopped. See the owner's enable or retrain? manual for the list of required training 4.
Page 398
Interior Comfort Bluetooth Hands-Free (Voice Recognition) (For example, 1234 must be read out 3. Prompt: Enrollment is enabled/ one, two, three, four , not twelve, thirty disabled. Would you like to disable/ four .) enable or retrain? Do not read out parentheses. ( and 4.
Interior Comfort Bluetooth Hands-Free (Voice Recognition) Safety Certification When Bluetooth Hands- Free Cannot be Used FCC ID: CB2MBLUEC07 IC:279B- MBLUEC07 Bluetooth Hands-Free cannot be used This device complies with Part 15 of the under the following conditions: FCC Rules and with RSS-210 of Industry The device is outside of the Canada.
Page 400
Interior Comfort Bluetooth Hands-Free (Voice Recognition) Mazda Bluetooth Hands- Free Customer Service For toll-free Bluetooth Hands-Free customer service call 800-430-0153 or go to www.MazdaUSA.com/bluetooth for assistance. 6-158...
Page 401
Interior Comfort Bluetooth Hands-Free (Panel Operation) í Bluetooth Hands-Free Phone button Selection Selection button 1 button 5 Selection Selection button 6 button 2 Selection Selection button 3 button 7 Selection button 4 Power/Volume dial Return button Manual tuning dial/Enter switch qWhat is Bluetooth Hands-Free? Bluetooth equipped device (Mobile phone)
Page 402
If the ignition switch is turned off during a some which will not connect with hands-free call, the line is transferred to the your Mazda or will have limited device (Mobile phone) automatically. function. Therefore, consult Mazda If the device (Mobile phone) is in a location...
Interior Comfort Bluetooth Hands-Free (Panel Operation) Pick-up button and Hang-up button Basic Bluetooth Hands- Basic functions of Bluetooth Hands-Free Free Operation can be used for such things as making calls or hanging up using the pick-up qBluetooth Hands-Free Preparation button and hang-up button on the steering wheel.
Page 404
Interior Comfort Bluetooth Hands-Free (Panel Operation) NOTE Programming a Bluetooth Hands-Free device which has a PIN code (four A device can be programmed only when the digits) vehicle is parked. If the vehicle starts to move, the pairing procedure will end. 1.
Page 405
Interior Comfort Bluetooth Hands-Free (Panel Operation) 7. When the pairing programming is 7. When the pairing programming is completed, a symbol and completed, a symbol and Pairing complete are displayed, and Pairing complete are displayed, and then the display returns to the normal then the display returns to the normal display.
Interior Comfort Bluetooth Hands-Free (Panel Operation) qHanging Up a Call Convenient Use of the Press selection button 5 or the hang-up Hands-Free System button of the audio control switch during qPhonebook Usage a call. qVolume Adjustment NOTE Do this function only when parked. It is too The power/volume dial of the audio unit distracting to attempt while driving and you is used to adjust the volume.
Page 407
Interior Comfort Bluetooth Hands-Free (Panel Operation) 2. Turn the manual tuning dial to select a Making a call using the outgoing call list and then press the enter button record ) to display the Bluetooth 1. Press selection button 3 to display the Hands-Free phonebook screen outgoing call record screen.
Page 408
Interior Comfort Bluetooth Hands-Free (Panel Operation) qDTMF (Dual Tone Multi- Making a call using the incoming call record Frequency Signal) Transmission 1. Press selection button 4 to display the This function is used when transmitting incoming call record screen. DTMF via the audio control panel's manual tuning dial.
Interior Comfort Bluetooth Hands-Free (Panel Operation) 4. When the link change is completed, a Hands-Free Setting symbol and Link Changed are displayed, and then it returns to the qDevice normal display. If an error occurs while trying to link a Device registration device, Error is displayed and the For the registration of a Bluetooth...
Page 410
Interior Comfort Bluetooth Hands-Free (Panel Operation) NOTE NOTE If a link error occurs, check the Press the return button ( ) to return programming status of the Bluetooth to the previous display. Hands-Free device and the location of the 6. When the link deletion is completed, device in the vehicle (not in the trunk or a Deleted is displayed, and then it metal-type box), and then try the link...
Interior Comfort Bluetooth Hands-Free (Panel Operation) Safety Certification When Bluetooth Hands- Free Cannot be Used FCC ID: CB2MBLUEC07 IC:279B- MBLUEC07 Bluetooth Hands-Free cannot be used This device complies with Part 15 of the under the following conditions: FCC Rules and with RSS-210 of Industry The device is outside of the Canada.
Interior Comfort Bluetooth Hands-Free (Panel Operation) Mazda Bluetooth Hands- Free Customer Service For toll-free Bluetooth Hands-Free customer service call 800-430-0153 or go to www.MazdaUSA.com/bluetooth for assistance. 6-170...
Interior Comfort Rear View Monitor í Rear View Monitor The rear view monitor is a visual assist system when reversing the vehicle that provides images from the rear of the vehicle. WARNING The rear view monitor is only a visual assist device when reversing the vehicle. The images on the screen may be different from the actual conditions.
Page 414
If the camera temperature changes rapidly, such as by pouring hot water on it under cold temperature conditions, the rear view monitor may not operate correctly. When replacing the tires, consult an Authorized Mazda Dealer. Replacing the tires could result in deviation of the guide lines which appear on the display.
Page 415
Interior Comfort Rear View Monitor qDisplayable Range on the Screen The images on the screen may be different from the actual conditions. (Screen display) Garnish Bumper (Actual view) Object NOTE The displayable range varies depending on the vehicle and road conditions. The displayable range is limited.
Page 416
Interior Comfort Rear View Monitor qViewing the Display Guide lines which indicate the width of the vehicle (green) are displayed on the screen as a reference to the approximate width of the vehicle in comparison to the width of the parking space you are about to back into.
Page 417
Interior Comfort Rear View Monitor qRear View Monitor Operation The operation of the rear view monitor when reversing the vehicle varies depending on the traffic, road, and vehicle conditions. The amount of steering and the timing also varies depending on conditions, so confirm the surrounding conditions directly with your eyes and steer the vehicle in accordance with the conditions.
Page 418
Interior Comfort Rear View Monitor 5. Once they are parallel, straighten the wheels and back your vehicle slowly into the parking space. Continue checking the vehicle's surroundings and then stop the vehicle in the best possible position. (If the parking space has division lines, check whether the vehicle width guide lines are parallel to them.) (Screen display) (Actual view)
Page 419
Interior Comfort Rear View Monitor NOTE Because there may be a difference between the displayed image, such as indicated below, and the actual conditions when parking, always verify the safety at the rear of the vehicle and the surrounding area directly with your eyes. In the image of the parking space (or garage) displayed below, even though the back end and distance guide lines appear parallel in the monitor, they may not actually be parallel on the ground.
Page 420
Interior Comfort Rear View Monitor qVariance Between Actual Road Conditions and Displayed Image Some variance occurs between the actual road and the displayed road. Such variance in distance perspective could lead to an accident. Note the following conditions that may cause a variance in distance perspective.
Page 421
Interior Comfort Rear View Monitor When there is a steep grade behind the vehicle When there is a steep upgrade (downgrade) behind the vehicle, the object displayed on the screen appears farther (downgrade: closer) than the actual distance. Appears Appears farther than closer than actual...
Page 422
Interior Comfort Rear View Monitor Three-dimensional object on vehicle rear Because the distance guide lines are displayed based on a flat surface, the distance to the three-dimensional object displayed on the screen is different from the actual distance. (Screen display) (Actual condition) Sensed distance on screen A>B>C (Actual distance) B>C=A...
Interior Comfort Interior Equipment qVanity Mirrors Sunvisors To use the vanity mirror, lower the When you need a sunvisor, lower it for sunvisor. use in front or swing it to the side. The vanity mirror light will illuminate when you open the cover. Sunvisor qSide Extension Sunvisors The visor extender extends the sunvisor's...
Interior Comfort Interior Equipment qOverhead Lights Interior Lights When the center/rear overhead light qIlluminated Entry System switch is in the DOOR position, the center/rear overhead light can be turned When the illuminated entry system on or off using the front overhead light operates, the overhead light (switch is in switch.
Page 425
Interior Comfort Interior Equipment qLuggage Compartment Light Center/Rear Switch Switch Overhead Lights Luggage Compartment Light Position Position Light off Light off Light on or off in accordance with the Light on when the liftgate is open operation of front overhead light switch qCourtesy Lights Light on...
Interior Comfort Interior Equipment Information Display Trip computer Clock Without navigation system (Type B) Climate control display (Front passenger)/ Climate control Ambient temperature display display (Driver) With navigation system Without navigation system (Type A) Clock/Trip computer Audio display Hands-free display Without navigation system Type A Type B...
Page 427
Interior Comfort Interior Equipment qClock 2. Adjust the time using the time setting buttons ( , ). The hours advance NOTE while the time setting button ( ) is Without navigation system (Type A) pressed. The minutes advance while When the trip computer is displayed, press the the time setting button ( ) is pressed.
Page 428
If you have any problems with your trip Significantly cold or hot temperatures. computer, consult an Authorized Mazda Sudden changes in ambient temperature. Dealer. The vehicle is parked. The vehicle is driven at low speeds.
Page 429
Interior Comfort Interior Equipment CANADA CANADA When you've slowed to about 5 km/h (3 To clear the data being displayed, press mph), L/100 km ( mpg) will be the INFO switch for more than 1.5 displayed. second. After pressing the INFO switch, L/100 Average fuel economy mode km (...
Page 430
Interior Comfort Interior Equipment CANADA U.S.A. NOTE CANADA Even though the distance-to-empty display may indicate a sufficient amount of remaining mileage before refueling is required, refuel as soon as possible if the fuel gauge needle nears E or the low fuel warning light illuminates.
Interior Comfort Interior Equipment qFront Cup Holder To use the cup holder, push the release WARNING button. Never use a cup holder to hold hot liquids while the vehicle is moving: Using a cup holder to hold hot liquids while the vehicle is moving is dangerous.
Page 432
Interior Comfort Interior Equipment í qRear Left-side Second-row seat Cup holders are located in the armrest. Third-row seat Cup holders are located in the third-row seat side trims. Right-side í 6-190 Some models.
Interior Comfort Interior Equipment Bottle Holder Storage Compartments WARNING Bottle holders are on the inside of the doors. Keep storage boxes closed when driving: Driving with the storage boxes open is dangerous. To reduce the possibility of injury in an accident or a sudden stop, keep the storage boxes closed when driving.
Page 434
Interior Comfort Interior Equipment qCoin Box qCenter Console To open, press the release catch down and To open, push the button. pull the lid downward. í qArmrest Box qGlove Box To open, pull the release catch. To open the glove box, pull the latch toward you.
Page 435
Interior Comfort Interior Equipment Use the loops in the luggage compartment 2. Secure the trunk board using the straps to secure cargo with a rope or net. The on the third-row seatbacks. tensile strength of the loops is 196 N (20 kgf, 44 lbf).
Page 436
Interior Comfort Interior Equipment qLuggage Compartment Golf bags can be carried in the luggage compartment. To carry two golf bags, use the following procedure: 1. Put one golf bag in the luggage compartment with its top pointing to the left. Shopping bag hook (tensile strength:3 kg (6.6 lb))
Interior Comfort Interior Equipment Rear Accessory Sockets Only use genuine Mazda accessories or the equivalent requiring no greater than 120 W (DC 12 V, 10 A). Front The ignition switch must be in the ACC or ON position. CAUTION To prevent accessory socket damage...
Interior Comfort Interior Equipment í Power Outlet The power outlet is positioned as shown in the figure. For more details, refer to Auxiliary terminals and power outlet (page 6-108). í 6-196 Some models.
Page 439
In Case of an Emergency Helpful information on what to do in an emergency. Parking in an Emergency ............. 7-2 Parking in an Emergency ............7-2 Flat Tire ..................7-3 Spare Tire and Tool Storage ............7-3 Changing a Flat Tire ..............7-8 Overheating .................
In Case of an Emergency Parking in an Emergency Parking in an Emergency The hazard warning lights should always be used when you stop on or near a roadway in an emergency. The hazard warning lights warn other drivers that your vehicle is a traffic hazard and that they must take extreme caution when near it.
In Case of an Emergency Flat Tire Spare Tire and Tool Storage Spare tire and tools are stored in the locations illustrated in the diagram. Spare tire carrier bolt socket Flat tire belt Tiedown eyelet Jack lever Lug wrench Jack...
Page 442
If the jack is not completely secured, it could rattle while driving. Make sure the jack screw is sufficiently tightened. qSpare Tire Your Mazda has a temporary spare tire. Jack screw The temporary spare tire is lighter and smaller than a conventional tire, and is...
Page 443
Ø Do not use your temporary Lug wrench spare tire on any other vehicle; it has been designed only for Jack lever your Mazda. Ø Use only one temporary spare Socket tire on your vehicle at the same time. Bolt...
Page 444
In Case of an Emergency Flat Tire 5. Slowly turn the lug wrench NOTE counterclockwise until the spare tire A flat tire which has been removed from the reaches the ground and the cable vehicle for repair cannot be carried in the becomes loose.
Page 445
If you hear rattling from the spare tire carrier while the vehicle is moving, the spare tire carrier cable may be cut. Have it repaired at an Authorized 2. Raise the spare tire slowly in reverse Mazda Dealer as soon as possible. order of removal.
CAUTION (With Tire Pressure Monitoring System) The wheels equipped on your Mazda NOTE are specially designed for installation When blocking a tire, use rocks or wood blocks of the tire pressure sensors. Do not...
Page 447
Use only the jack provided with your Mazda: Using a jack that is not designed for your Mazda is dangerous. The vehicle could slip off the jack and seriously injure someone. Never place objects under the jack: 2. Place the jack under the jacking...
Page 448
Mazda is firmly in position and that it key to unlock them. This key is attached cannot slip or move.
Page 449
In Case of an Emergency Flat Tire 3. Install the lug nuts with the beveled To install the nut edge inward; tighten them by hand. 1. Place the key on top of the nut, and be sure to hold the key square to it. If you hold the key at an angle, you may damage both key and nut.
Page 450
Because the wheel studs and lug nuts on your Mazda have metric threads, using a non-metric nut is dangerous. On a metric stud, it would not secure the wheel and would damage the 11.
Page 451
In Case of an Emergency Flat Tire 13. Check the tire inflation pressure. Refer to the specification charts on page 10-6. 14. Have the flat tire repaired or replaced as soon as possible. WARNING Do not drive with any tires that have incorrect air pressure: Driving on tires with incorrect air pressure is dangerous.
Stop the engine and call an Authorized Mazda Dealer. Do not remove either cooling system caps when the engine and 6. Make sure the cooling fan is operating,...
Page 453
Carefully add coolant as required (page 8-21). CAUTION If the engine continues to overheat or frequently overheats, have the cooling system inspected. The engine could be seriously damaged unless repairs are made. Consult an Authorized Mazda Dealer. 7-15...
In Case of an Emergency Emergency Starting Jump-Starting Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel unsure about jump-starting, we strongly recommend that you have a competent service technician do the work. WARNING Follow These Precautions Carefully: To ensure safe and correct handling of the battery, read the following precautions carefully before using the battery or inspecting it.
Page 455
In Case of an Emergency Emergency Starting Keep all flames, including cigarettes, and sparks away from open battery cells: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries.
1. Make sure the booster battery is 12 V Push-Starting and that its negative terminal is grounded. Do not push-start your Mazda. 2. If the booster battery is in another NOTE vehicle, don't allow both vehicles to You can't start a vehicle with an automatic touch.
Towing Description Do not tow the vehicle pointed We recommend that towing be done only backward with driving wheels on the by an Authorized Mazda Dealer or a ground. This may cause internal commercial tow-truck service. damage to the transaxle.
In Case of an Emergency Emergency Towing WARNING Tiedown Hooks Always tow a AWD vehicle with all four CAUTION wheels off the ground: Towing a AWD vehicle with either the Do not use the front and rear front or rear wheels on the ground is tiedown eyelets for towing the dangerous as the drive train could be vehicle.
Page 459
In Case of an Emergency Emergency Towing Rear Rear Lug wrench 4. Hook the tying rope to the tiedown CAUTION eyelet. Ø Do not use excessive force as it Front may damage the cap or scratch the painted bumper surface. Ø...
In Case of an Emergency Emergency Towing CAUTION Recreational Towing If the tiedown eyelet is not securely An example of recreational towing is tightened, it may loosen or disengage towing your vehicle behind a motorhome. from the bumper when tying down The transaxle is not designed for towing the vehicle.
Page 461
Maintenance and Care How to keep your Mazda in top condition. Introduction .................. 8-2 Introduction ................8-2 Scheduled Maintenance ..............8-3 Scheduled Maintenance (USA, Canada, and Puerto Rico) ..8-3 Scheduled Maintenance (Mexico) ..........8-9 Owner Maintenance ..............8-16 Owner Maintenance Schedule ..........8-16 Owner Maintenance Precautions ..........
Claims against the warranty resulting from lack of maintenance, as opposed to defective materials or authorized Mazda workmanship, will not be honored. Any auto repair shop using parts equivalent to your Mazda's original equipment may perform maintenance. But we recommend that it always be done by an Authorized...
Maintenance and Care Scheduled Maintenance Scheduled Maintenance (USA, Canada, and Puerto Rico) Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions apply. Repeated short-distance driving Driving in dusty conditions Driving with extended use of brakes Driving in areas where salt or other corrosive materials are used Driving on rough or muddy roads Extended periods of idling or low-speed operation...
Page 464
Maintenance and Care Scheduled Maintenance qSchedule 1 Number of months or kilometers (miles), whichever comes first Months Maintenance Interval ×1000 km ×1000 miles 22.5 37.5 52.5 ENGINE Inspect every 168,000 km (105,000 miles) Drive belts Replace every 240,000 km (150,000 miles) Engine oil Engine oil filter COOLING SYSTEM...
Page 465
*2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 466
Maintenance and Care Scheduled Maintenance qSchedule 2 Number of months or kilometers (miles), whichever comes first Months Maintenance Interval ×1000 km ×1000 miles ENGINE Inspect every 160,000 km (100,000 miles) Drive belts Replace every 240,000 km (150,000 miles) Puerto Rico Replace every 5,000 km (3,000 miles) or 3 months Engine oil Others...
Page 467
Maintenance and Care Scheduled Maintenance Number of months or kilometers (miles), whichever comes first Months Maintenance Interval ×1000 km ×1000 miles CHASSIS and BODY Brake lines, hoses and connections Brake fluid level Disc brakes Tire (Rotation) Rotate every 8,000 km (5,000 miles) Tire inflation pressure and tire wear Steering operation and linkages Power steering fluid level...
Page 468
*2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Maintenance and Care Scheduled Maintenance Scheduled Maintenance (Mexico) Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions apply. Repeated short-distance driving Driving in dusty conditions Driving with extended use of brakes Driving in areas where salt or other corrosive materials are used Driving on rough or muddy roads Extended periods of idling or low-speed operation Driving for long periods in cold temperatures or extremely humid climates...
Page 470
Maintenance and Care Scheduled Maintenance qSchedule 1 Number of months or kilometers, whichever comes first Maintenance Interval Months ×1000 km 90 100 110 120 ENGINE Inspect every 40,000 km or 2 years Drive belts Replace every 240,000 km Engine oil Engine oil filter COOLING SYSTEM Cooling system...
Page 471
*2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
Page 472
Maintenance and Care Scheduled Maintenance qSchedule 2 Number of months or kilometers, whichever comes first Maintenance Interval Months ×1000 km ENGINE Inspect every 40,000 km or 2 years Drive belts Replace every 240,000 km Engine oil Engine oil filter COOLING SYSTEM Cooling system Replace at first 190,000 km or 10 years;...
Page 473
*2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
Page 474
Maintenance and Care Scheduled Maintenance (Cont.) Number of months or kilometers, whichever comes first Maintenance Interval Months ×1000 km 95 100 105 110 115 120 ENGINE Inspect every 40,000 km or 2 years Drive belts Replace every 240,000 km Engine oil Engine oil filter COOLING SYSTEM Cooling system...
Page 475
*2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
The owner or a qualified service technician should make these vehicle inspections at the indicated intervals to ensure safe and dependable operation. Bring any problem to the attention of an Authorized Mazda Dealer or qualified service technician as soon as possible.
Improper owner maintenance during the warranty period may affect warranty coverage. For details, read the separate Mazda Warranty statement provided with the vehicle. If you're unsure about any servicing or maintenance procedure, have it done by an Authorized Mazda Dealer.
Institute (API). An oil with this trademark NOTE symbol conforms to the current engine Changing the engine oil should be done by an and emission system protection standards Authorized Mazda Dealer. and fuel economy requirements of the International Lubricant Standardization qRecommended Oil and Approval Committee (ILSAC), Use SAE 5W-20 engine oil.
Page 480
Maintenance and Care Owner Maintenance The quality designation SM, or ILSAC CAUTION must be on the label. Do not add engine oil over MAX. This may cause engine damage. –30 –10 –20 6. Make sure the O-ring on the dipstick is positioned properly before reinserting the dipstick.
When the engine and radiator are hot, scalding coolant and steam may shoot out under pressure and cause serious injury. NOTE Changing the coolant should be done by an Authorized Mazda Dealer. 8-21...
Page 482
If the FL22 mark is shown on or near the Ø Radiator coolant will damage cooling system cap, it is recommended to use paint. Mazda Genuine FL22 engine coolant (page Rinse it off quickly if spilled. 8-3). Ø Use only soft (demineralized) water in the coolant mixture.
If it immediately flush your eyes with is excessively low, have the brake system water and get medical attention. inspected by an Authorized Mazda Brake fluid spilled on a hot engine Dealer. could cause a fire.
Overfilling can cause foaming, loss of fluid, and transaxle malfunction. Ø It is recommended to use Mazda Genuine automatic transaxle fluid (page 10-4). 1. Park on a level surface and set the parking brake firmly.
Page 485
Maintenance and Care Owner Maintenance 5. Pull it out again. Fully insert the dipstick. When adding The proper fluid level is marked on the fluid, inspect with the dipstick to make dipstick as follows. sure it does not pass full. NOTE Inspect the fluid on both sides of the dipstick in a well lit area for an accurate reading.
Maintenance and Care Owner Maintenance Inspect fluid level in the washer fluid Washer Fluid reservoir; add fluid if necessary. qInspecting Washer Fluid Level WARNING Use only windshield washer fluid or plain water in the reservoir: Using radiator antifreeze as washer fluid is dangerous.
Be careful not to pinch hands or fingers as it may cause injury, or damage the wipers. When washing or servicing your Mazda, make sure the wiper lever is in the OFF position. Contamination of either the windshield or the blades with foreign matter can reduce wiper effectiveness.
Page 488
Maintenance and Care Owner Maintenance qReplacing Windshield Wiper Blades 4. Tilt the blade assembly and remove it from the arm. When the wipers no longer clean well, the blades are probably worn or cracked. Replace them. CAUTION To prevent damage to the wiper arms and other components, don't try to sweep the wiper arm by hand.
Page 489
Maintenance and Care Owner Maintenance 6. Remove the metal stiffeners from each 7. Carefully insert the new blade rubber. blade rubber and install them in the Then install the blade assembly in the new blade. reverse order of removal. CAUTION qReplacing Rear Window Wiper Ø...
Page 490
Maintenance and Care Owner Maintenance 2. Firmly rotate the wiper blade to the 4. Remove the metal stiffeners from each right until it unlocks, then remove the blade rubber and install them in the blade. new blade. CAUTION CAUTION To prevent damage to the rear Don't bend or discard the stiffeners.
Maintenance and Care Owner Maintenance Battery WARNING Wash hands after handling the battery and related accessories: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm. Read the following precautions carefully before using the battery or inspecting to ensure safe and correct handling: Always wear eye protection when working near the battery:...
Page 492
Maintenance and Care Owner Maintenance Keep all flames, including cigarettes, and sparks away from open battery cells: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries.
(radial, bias-belted, bias-type) on all four wheels. Using Wrong-Sized Tires: Using any other tire size than what is specified for your Mazda (page 10-6) is dangerous. It could seriously affect ride, handling, ground clearance, tire clearance, and speedometer Refer to the specification charts (page calibration.
Page 494
Maintenance and Care Owner Maintenance NOTE Improper wheel alignment Out-of-balance wheel Always check tire pressure when tires are Severe braking cold. Warm tires normally exceed recommended After rotation, inflate all tire pressures to pressures. Don't release air from warm tires specification (page 10-6) and inspect the to adjust the pressure.
Page 495
6 years or older. Heat caused by hot climates wheels or both, have the work done or frequent high loading conditions can by an Authorized Mazda Dealer, or accelerate the aging process. You should the tire pressure sensors may be replace the spare tire when you replace the damaged.
Page 496
(page 8-34). tires or wheels or both, have the work done by an Authorized NOTE Mazda Dealer, or the tire Tires degrade over time, even when they are pressure sensors may be not being used on the road. It is recommended damaged.
Maintenance and Care Owner Maintenance Light Bulbs Overhead light (Center) Overhead light (Rear) Overhead light/Map lights (Front) Side turn signal lights Vanity mirror lights Courtesy lights Parking lights Front side marker lights Headlights (High beam) Front turn signal lights Fog lights Headlights (Low beam) High-mount brake light Luggage...
Page 498
Consult an Authorized Mazda Dealer when the replacement is necessary. Never touch the glass portion of a halogen bulb with your bare hands and 4.
Page 499
Low-beam bulb (Xenon fusion bulb) You cannot replace the low beam bulbs by yourself. The bulbs must be replaced at an Authorized Mazda Dealer. (Halogen bulbs) 1. Make sure the headlight switch is off. 2. Lift the hood. 8-39...
Page 500
To replace the bulb, contact an Authorized connector with your finger and pulling Mazda Dealer the connector downward. If the halogen bulb is accidentally touched, it should be cleaned with rubbing alcohol before being used.
Page 501
7. Install the coolant reservoir. If you are unsure of how tight the bolts should be, have them inspected at an Authorized Mazda Dealer. Bolt tightening torque 6.9 11.8 4. Turn the socket and bulb assembly N·m (kgf·m, ft·lbf) (0.7 1.2, 5.1 8.7)
Page 502
, Brake lights, Taillights, High-mount brake light Due to the complexity and difficulty of the procedure, the LED bulbs should be replaced by an Authorized Mazda Dealer. NOTE LED bulb replacement is not possible. The rear combination component must be replaced.
Page 503
Maintenance and Care Owner Maintenance Rear turn signal lights, Rear side- Rear turn signal lights marker light 1. Turn the bolts counterclockwise and remove them. Rear side-marker light 2. Pull the unit rearward to remove it. 4. Disconnect the bulb from the socket. 5.
Page 504
4. Install the new bulb in the reverse order of removal. NOTE To replace the bulb, contact an Authorized Mazda Dealer. License plate lights 1. Wrap a flathead screwdriver with a soft cloth to prevent damage to the lens and...
Page 505
Maintenance and Care Owner Maintenance Overhead light (Center, Rear) Vanity mirror lights Luggage compartment light 3. Install the new bulb in the reverse order of removal. Courtesy lights 8-45...
If the same fuse blows again, avoid using that system and consult an Authorized Mazda Dealer as soon as possible. 4. Pull the fuse straight out with the fuse puller provided on the fuse block qFuse Replacement located in the engine compartment.
Page 507
2. Remove the fuse block cover or the relay box cover. Fuse block WARNING Do not replace the main fuse by yourself. Have an Authorized Mazda Dealer perform the replacement: Replacing the fuse by yourself is dangerous because the MAIN fuse is a high current fuse. Incorrect...
Page 508
Maintenance and Care Owner Maintenance qFuse Panel Description Fuse block (Engine compartment) FUSE DESCRIPTION PROTECTED COMPONENT RATING MAIN 150 A For protection of all circuits ENGINE 20 A Transaxle control system R HEATER 40 A Heater í P.SEAT R 30 A Power seat (RH) HEATER 50 A...
Page 509
Maintenance and Care Owner Maintenance FUSE DESCRIPTION PROTECTED COMPONENT RATING OUTLET CTR 15 A Accessory socket (Center) OUTLET RR 15 A Accessory socket (Rear) í AC PWR 15 A Moon roof , DC/AC inverter í S.WARM 15 A Seat warmer A/C MAG 10 A Air conditioner...
Page 510
Maintenance and Care Owner Maintenance í Relay box (Engine compartment) FUSE DESCRIPTION PROTECTED COMPONENT RATING 7.5 A Injectors í 8-50 Some models.
Page 511
Maintenance and Care Owner Maintenance Fuse block (Glove box) FUSE DESCRIPTION PROTECTED COMPONENT RATING OUTLET FR 15 A Accessory socket (Front) MIRROR 7.5 A Power control mirror METER 10 A Instrument cluster 7.5 A ABS, Air bag ENG.IGA 7.5 A Engine control system 7.5 A Ignition system...
Page 512
Maintenance and Care Owner Maintenance FUSE DESCRIPTION PROTECTED COMPONENT RATING OUTLET CTR OUTLET RR WIPER 30 A Windshield wiper and washer P.WIND 30 A Power windows 8-52...
Prevention Industrial pollutants and vehicle emissions drift into the air and mix with rain or dew It is necessary to have your Mazda washed and waxed to preserve its finish to form acids. These acids can settle on a according to the instructions in this vehicle's finish.
Page 514
The rings Chipped paint can lead to rust forming on can damage your vehicle's finish. your Mazda. Before this happens, repair the damage by using Mazda touch-up paint Prevention according to the instructions in this section.
Insects, tar, tree sap, bird droppings, NOTE industrial fallout, and similar deposits can Mazda is not responsible for scratches damage the finish if not removed caused by automatic car washes or immediately. When prompt washing with improper washing.
Page 516
CAUTION pressure car washers are available depending on the type of car wash If your Mazda is damaged and needs machine. If the car washer nozzle is put metal parts repaired or replaced, too close to the vehicle, the force of the...
Page 517
Road chemicals and salt used for ice and Of course there will be no problem if you snow removal and solvents used for dust assign the work to an Authorized Mazda control may collect on the underbody. If Dealer. not removed, they will speed up rusting...
They'll damage and discolor it. coating periodically. If these solutions get on the dashboard, wipe them off immediately. An Authorized Mazda Dealer are well informed on how repairs should be made. CAUTION Consult an Authorized Mazda Dealer. Do not use glazing agents.
Page 519
Appearance Care To keep the fabric looking clean and WARNING fresh, take care of it. Otherwise its color Have an Authorized Mazda Dealer will be affected, it can be stained easily, replace damaged seat belts and its fire-resistance may be reduced.
Mazda Importer/Distributors ....9-13 Importer/Distributor ......9-13 Distributor in Each Area ....9-13 Warranty ..........9-15 Warranties for Your Mazda ....9-15 Outside the United States and Canada ..........9-16 Outside the United States ....9-17 Outside Canada ......... 9-18...
Answers to many questions, including how to locate or contact a local Mazda dealership in the U.S., can be found here. E-mail: click on Contact Us located on the Inside Mazda tab, or at the bottom of the page at www.mazdaUSA.com...
Page 523
Mazda North American Operations realizes that mutual agreement on some issues may not be possible. As a final step to ensure that your concerns are being fairly considered, Mazda North American Operations has agreed to participate in a dispute settlement program administered by the Better Business Bureau (BBB) system, at no cost to you the consumer.
Mazda or one of our dealers, and a statement of the relief you are seeking. 5. BBB AUTO LINE staff may try to help resolve your dispute through mediation. If...
AND the nonconformity has been subject to repair two or more times by Mazda or its agents AND the buyer or lessee has directly notified Mazda of the need for the repair of the nonconformity; OR...
Page 526
11. If you accept the arbitrator's decision, Mazda will be bound by the decision, and will comply with the decision within a reasonable time not to exceed 30 days after we receive notice of your acceptance of the decision.
Page 527
Your complete and permanent satisfaction is of primary concern to Mazda. All Authorized Mazda Dealers have both the knowledge and tools to keep your Mazda in top condition. In our experience, any questions, problems, or complaints regarding the operation of your Mazda or any other general service transactions are most effectively resolved by your dealer.
Page 528
If a specific item of concern arises, where a solution cannot be reached between an owner, Mazda, and/or one of it's dealers (that all parties cannot agree upon), the owner may wish to use the services offered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 529
1 (800) 207-0685 Ontario 1 (800) 207-0685 Atlantic Canada 1 (800) 207-0685 Quebec 1 (800) 207-0685 qRegional Offices REGIONAL OFFICES AREAS COVERED MAZDA CANADA INC. WESTERN REGION ALBERTA, 8171 ACKROYD ROAD BRITISH COLUMBIA, SUITE 2000 MANITOBA, RICHMOND B.C. SASKATCHEWAN, V6X 3K1...
Page 530
1 Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 531
1: Contact Your Mazda Dealer Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 532
Customer Information and Reporting Safety Defects Customer Assistance In order to serve you efficiently and effectively, please help us by providing the following information: 1. Your name, address, and telephone number 2. Year and model of vehicle 3. Vehicle Identification Number (17 digits, noted on your registration or title or located on the upper driver's side corner of the dash) 4.
Irvine, CA 92623-9734 U.S.A. (905) 787-7000 (outside Canada) TEL: 1 (800) 222-5500 (in U.S.A.) qPUERTO RICO/U.S. Virgin Island (949) 727-1990 (outside U.S.A.) Plaza Motors Corp. (Mazda de Puerto Rico) P.O. Box 362722, San Juan, Puerto Rico 00936-2722 TEL: (787) 641-9300...
Page 534
Customer Information and Reporting Safety Defects Mazda Importer/Distributors Triple J Saipan, Inc. (d.b.a. Triple J Motors) P.O. Box 500487 Saipan, MP 96950-0487 TEL: (670) 234-7133/3051 9-14...
Page 535
Federal Emission Control Warranty (U.S.A. only) Emission Defect Warranty Emission Performance Warranty California Emission Control Warranty (U.S.A. only) Emission Control Warranty (Canada only) Replacement Parts and Accessories Limited Warranty Tire Warranty NOTE Detailed warranty information is provided with your Mazda. 9-15...
Page 536
Proper repair facilities, tools, testing equipment, and replacement parts may not be available. The Mazda warranty applies only to Mazda vehicles registered and normally operated in the United States, its territories, and Canada. 9-16...
We strongly recommend that you NOT take your Mazda outside the United States. However, in the event that you are moving to Canada permanently, Mazda vehicles built for use in the United States could be eligible for exportation to Canada with specific vehicle modifications to comply with the Canadian Motor Vehicle Safety requirements (CMVSS).
We strongly recommend that you NOT take your Mazda outside Canada. However, in the event that you are moving to the United States permanently, Mazda vehicles built for use in Canada could be eligible for exportation to the United States with specific vehicle modifications to comply with the United States Federal Motor Vehicle Safety Standards (FMVSS).
Parts, servicing techniques, and tools necessary to maintain and repair your vehicle may be unavailable. There might not be an Authorized Mazda Dealer in the country you plan to take your vehicle. The Mazda warranty is valid only in certain countries.
Non-genuine parts and accessories for Mazda vehicles can be found in stores. These may fit your vehicle, but they are not approved by Mazda for use with Mazda vehicles. When you install non-genuine parts or accessories, they could affect your vehicle's performance or safety systems;...
Customer Information and Reporting Safety Defects Cell Phones Cell Phones Warning WARNING Please comply with the legal regulations concerning the use of communication equipment in vehicles in your State or Province: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous.
Customer Information and Reporting Safety Defects Uniform Tire Quality Grading System (UTQGS) Uniform Tire Quality Grading System (UTQGS) This information relates to the tire grading system developed by the U.S. National Highway Traffic Safety Administration for grading tires by tread wear, traction, and temperature performance.
Page 543
These grades will be added to the sidewalls of passenger vehicle tires over the next several years according to a schedule established by the NHTSA and the tire manufacturers. The grade of tires available as standard or optional equipment on Mazda vehicles may vary with respect to grade.
Customer Information and Reporting Safety Defects Tire Information (except Canada) Tire Labeling Federal law requires tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire and also provides a tire identification number for safety standard certification and in case of a recall.
Page 545
Customer Information and Reporting Safety Defects Tire Information (except Canada) 11. Tread wear, traction and temperature grades 12. Max. permissible inflation pressure 13. SAFETY WARNING P215/65R15 95H is an example of a tire size and load index rating. Here is an explanation of the various components of that tire size and load index rating.
Page 546
Customer Information and Reporting Safety Defects Tire Information (except Canada) H is the speed rating. The speed rating denotes the maximum speed for which the use of the tire is rated. Letter Rating Speed Rating 99 mph 106 mph 112 mph 118 mph 124 mph 130 mph...
Page 547
Customer Information and Reporting Safety Defects Tire Information (except Canada) Tread Wear, Traction and Temperature Grades Tread wear: The tread wear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
Page 548
Customer Information and Reporting Safety Defects Tire Information (except Canada) qInformation on Temporary Tires Please refer to the diagram below. 1. Temporary tires 2. Nominal width of tire in millimeters 3. Ratio of height to width (aspect ratio) 4. Diagonal 5.
Page 549
Customer Information and Reporting Safety Defects Tire Information (except Canada) 70 is the aspect ratio. This two-digit number indicates the tire's ratio of height to width. D is the tire construction symbol. D indicates diagonal ply construction . 16 is the wheel rim diameter in inches. 90 is the Load Index.
Customer Information and Reporting Safety Defects Tire Information (except Canada) Location of the Tire Label (Placard) You will find the tire label containing tire inflation pressure by tire size and other important information on the driver's side B-pillar or on the edge of the driver's door frame. SAMPLE qRecommended Tire Inflation Pressure On the tire label you will find the recommended tire inflation pressure in both kPa and psi...
Page 551
Customer Information and Reporting Safety Defects Tire Information (except Canada) WARNING Always check the tire inflation pressures on a regular basis according to the recommended tire inflation pressure on the tire label and in conjunction with the information in this owner's manual: Driving your vehicle with under-inflated tires is dangerous.
Page 552
Customer Information and Reporting Safety Defects Tire Information (except Canada) qGlossary of Terms Tire Placard: A label indicating the OE tire sizes, recommended inflation pressure, and the maximum weight the vehicle can carry. Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size, and date of manufacture.
Customer Information and Reporting Safety Defects Tire Information (except Canada) Tire Maintenance Improper or inadequate vehicle maintenance can cause tires to wear abnormally. Here are some important maintenance points: qTire Inflation Pressure Inspect all tire pressure monthly (including the spare) when the tires are cold. Maintain recommended pressures for the best ride, top handling, and minimum tire wear.
Page 554
Customer Information and Reporting Safety Defects Tire Information (except Canada) qReplacing a Tire WARNING Always use tires that are in good condition: Driving with worn tires is dangerous. Reduced braking, steering, and traction could result in an accident. If a tire wears evenly, a wear indicator will appear as a solid band across the tread. Replace the tire when this happens.
Page 555
Customer Information and Reporting Safety Defects Tire Information (except Canada) CAUTION If you feel a sudden vibration or ride disturbance while driving or you suspect your tire or vehicle has been damaged, immediately reduce your speed. Drive with caution until you can safely pull off the road. Stop and inspect the tire for damage. If the tire is under-inflated or damaged, deflate it, remove the tire and rim and replace it with your spare tire.
Customer Information and Reporting Safety Defects Tire Information (except Canada) Vehicle Loading This section will guide you in the proper loading of your vehicle and/or trailer, to keep your loaded vehicle weight within its design rating capability, with or without a trailer. Properly loading your vehicle will provide maximum return of vehicle design performance.
Page 557
Customer Information and Reporting Safety Defects Tire Information (except Canada) Payload is the combination weight of cargo and passengers that the vehicle is designed to carry. The maximum payload for your vehicle can be found on the Tire and Load Information label on the driver's door frame or door pillar.
Page 558
Customer Information and Reporting Safety Defects Tire Information (except Canada) CARGO Cargo Weight includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight.
Page 559
Customer Information and Reporting Safety Defects Tire Information (except Canada) GAWR (Gross Axle Weight Rating) is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the driver's door frame or door pillar. The total load on each axle must never exceed its GAWR.
Page 560
Customer Information and Reporting Safety Defects Tire Information (except Canada) SAMPLE WARNING Exceeding Axle Weight Rating Limits: Exceeding the Safety Certification Label axle weight rating limits is dangerous and could result in death or serious injury as a result of substandard vehicle handling, performance, engine, transmission and/or structural damage, serious damage to the vehicle, or loss of control.
Page 561
Customer Information and Reporting Safety Defects Tire Information (except Canada) GCW (Gross Combination Weight) is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combination Weight Rating) is the maximum allowable weight of the vehicle and the loaded trailer - including all cargo and passengers - that the vehicle can handle without risking damage.
Page 562
Customer Information and Reporting Safety Defects Tire Information (except Canada) WARNING Exceeding GVWR or GAWR Specifications: Exceeding the GVWR or the GAWR specified on the certification label is dangerous. Exceeding any vehicle rating limitation could result in a serious accident, injury, or damage to the vehicle.
Customer Information and Reporting Safety Defects Tire Information (except Canada) Steps for Determining the Correct Load Limit: Steps for Determining Correct Load Limit: (1) Locate the statement The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs on your vehicle's placard. (2) Determine the combined weight of the driver and passengers that will be riding in your vehicle.
7755 Irvine Center Drive Irvine, California 92618-2922 P.O. Box 19734 Irvine, CA 92623-9734 Customer Assistance Center or toll free at 1 (800) 222-5500 If you live outside of the U.S.A., please contact the nearest Mazda Distributor shown (page 9-13) in this booklet. 9-44...
Page 565
Customer Information and Reporting Safety Defects Reporting Safety Defects Reporting Safety Defects (Canada) Canadian customers who wish to report a safety-related defect to Transport Canada, Defect Investigations and Recalls, may telephone the toll free hotline 1-800-333-0510, or contact Transport Canada by mail at: Transport Canada, ASFAD, Place de Ville Tower C, 330 Sparks Street, Ottawa ON K1A 0N5.
Factory-authorized Mazda service publications are available for owners who wish to do some of their own maintenance and repair. When requesting any of our publications through an Authorized Mazda Dealer, refer to the chart below. If they do not have what you need in stock, they can order it for you.
Page 567
Customer Information and Reporting Safety Defects Service Publications qNAVIGATION SYSTEM OWNER'S MANUAL: This booklet contains information regarding the proper operation and use of the navigation system. This is not a technician's manual. 9-47...
Specifications Technical information about your Mazda. Identification Numbers ............... 10-2 Vehicle Information Labels ............. 10-2 Specifications ................10-4 Specifications ................10-4 10-1...
Identification Numbers qChassis Number Vehicle Information Labels Open the cover shown in the figure to qVehicle Identification Number check the chassis number. The vehicle identification number legally identifies your vehicle. The number is on a plate attached to the cowl panel located on the left corner of the dashboard.
Page 572
Mazda Genuine JWS3309 Transfer case oil API Service GL-5 (SAE 75W-140) Rear differential oil API Service GL-5 (SAE 80W-90) Power steering fluid Mazda Genuine ATF M-III, M-V, or equivalent (e.g. Dexron® II) Brake fluid SAE J1703, or FMVSS116 DOT-3 10-4...
Page 573
Specifications qCapacities (Approximate Quantities) Item Capacity With oil filter replacement 5.2 L (5.5 US qt, 4.6 Imp qt) Engine oil Without oil filter replacement 4.7 L (5.0 US qt, 4.2 Imp qt) With Towing Package 13.3 L (14.1 US qt, 11.7 Imp qt) Coolant Without Towing Package 12.9 L (13.6 US qt, 11.4 Imp qt)
Page 574
NOTE The tires have been optimally matched with the chassis of your vehicle. When replacing tires, Mazda recommends that you replace tires of the same type originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer. í...
Page 575
Specifications Check the tire pressure label for tire size and inflation pressure. Refer to Tire Inflation Pressure on page 8-33. Standard tire Inflation pressure Tire size Front Rear P245/60R18 104H 250 kPa (36 psi) 250 kPa (36 psi) P245/50R20 102V 230 kPa (34 psi) 230 kPa (34 psi) Temporary spare tire...
Page 579
Convenient Use of the Hands-Free Cell Phones ........9-21 System ........6-164 Center Console ........ 6-192 Hands-Free Setting ....6-167 Child Restraint Mazda Bluetooth Hands-Free Child restraint precautions ..2-35 Customer Service ..... 6-170 Installing child-restraint Safety Certification ....6-169 systems ........2-39...
Page 580
Index Flasher Driving Tips ........4-6 Hazard warning ......5-70 Automatic transaxle ....5-15 Headlights ........5-60 Break-in period ......4-6 Flat Tire ..........7-3 Driving in flooded area ....4-12 Changing ........7-8 Driving on uneven road ..... 4-13 Spare tire and tool storage ....
Page 581
Index Keyless Entry System ....... 3-24 HomeLink Wireless Control Keys ..........3-23 System ..........5-71 Hood Release ........3-49 Horn ..........5-70 Label Information ......10-2 Lane-Change Signals ......5-63 Liftgate ..........3-33 Ignition Light Bulbs Keys ........... 3-23 Replacement ....... 8-37 Switch ..........
Page 582
Index Overloading ........4-12 Seat Belt System 3-point type ........ 2-23 Automatic locking ...... 2-22 Belt minder ......... 2-33 Paint Damage ........8-53 Center-rear lap/shoulder ..... 2-28 Parking Brake ........5-6 Emergency locking ....2-21 Parking in an Emergency ....7-2 Extender ........
Page 583
Index SRS Air Bags Tire Pressure Monitoring System ..5-27 Driver and front passenger occupant System error activation ....5-31 classification system ....2-64 Tire pressure monitoring system How the SRS air bags work ..2-57 warning light ......5-29 Limitations to SRS air bag ..
Page 584
Index Warning Lights ......... 5-43 ABS ..........5-46 Air bag system ......5-48 Automatic transaxle ....5-51 AWD .......... 5-51 Brake system ......5-45 Charging system ......5-47 Check engine ......5-47 Check fuel cap ......5-49 Door-ajar ........5-51 Engine oil pressure .....
