Configure Your Netopia Gateway
4
When you use the Netopia Installation Guide Wizard, it will automatically run your Web browser at the appropri-
ate time, and take you to your Gateway's web-based Quickstart page. If it fails to do this, you can access the con-
figuration pages at any time as follows:
1.
Run a Web browser, such as Firefox, Safari, or Microsoft Internet Explorer, and enter
http://192.168.1.254
in the URL Address text box.
2.
For security purposes you must create a password for your Gateway. Enter a new password,
repeat it, and click the Submit button.
3.
Enter the Username and Password assigned to you by your service provider.
Click the
Connect to the Internet
button.
After your Gateway negotiates its connection, you will be redirected to a Netopia web page where you may regis-
ter your Gateway.
Congratulations! Your connection is up and running and you should be able to browse the Internet by typing a
URL address in your browser's Address text box or by selecting any of your favorite bookmarks.
Netopia Part Number: 6180143-AT-01
Copyright 2005, Netopia, Inc. Netopia and the Netopia logo are registered trademarks belonging to Netopia, Inc.,
registered U.S. Patent and Trademark Office. Broadband Without Boundaries is a trademark belonging to Netopia,
Inc. All other trademarks are the property of their respective owners. All rights reserved.
Press Return.
You will be asked to log in to your Gateway with a
UserName and Password.
The default UserName is admin . Enter the Password
you just created. Type these in their respective fields
and click OK .
The browser displays the
Quickstart
page.
Quickstart Guide
®
Netopia
2240N-VGx DSL Gateway
Checklist
1
Check your package contents. It should contain the items shown here:
Netopia Gateway
Power
Supply
If you don't have everything, contact your supplier immediately.
Technical Support:
If you have any questions or run into any difficulty, answers to many frequently asked product-related questions,
as well as full product documentation with advanced configuration instructions, are also available on-line at:
http://www.netopia.com/support
The Netopia CD also contains a Documentation folder with Important Safety Instructions and other
documentation.
Note the serial number (SN:) of your Gateway. It is located on the label on the bottom of the Gateway below the
model number. You will need the Gateway's serial number if you need to call for technical support.
4
B
ROADBAND WITHOUT
Single-Port Ethernet
CD & Quickstart Guide
Gray RJ-11
Yellow RJ-45
Telephone Cable
Ethernet Cable
B
™
OUNDARIES
1
Summary of Contents
-
Page 1
Configure Your Netopia Gateway When you use the Netopia Installation Guide Wizard, it will automatically run your Web browser at the appropri- ate time, and take you to your Gateway’s web-based Quickstart page. If it fails to do this, you can access the con- figuration pages at any time as follows: Run a Web browser, such as Firefox, Safari, or Microsoft Internet Explorer, and enter http://192.168.1.254...
-
Page 2
Set up your Gateway Decide on a location for the Gateway. Put the Gateway in a location where air can circulate freely around it. Power the Gateway. Connect the power supply to the power jack on the back panel of the Gateway. Then, plug the power supply into an electrical outlet.
