FCC ID in the format FCC-ID: IHDT56KB1 on the product label. Motorola has not approved any changes or modifications to this device by the user. Any changes or modifications could void the user’s authority to operate the equipment. See 47 CFR Sec. 15.21.
Page 4
Motorola reserves the right to change or modify any information or specifications without notice or obligation.
Page 5
HELLOMOTO Introducing your new Motorola wireless phone. Here’s a quick anatomy lesson. Volume Keys PTT Button Audio Jack Micro USB Connector Connects charger and accessories. Left Soft Key Perform function in lower left display. Messaging Key Menu Key Web Key...
check it out Voicemail LED Text Message LED Bluetooth LED Press and hold the Power Key for a few seconds, or until the screen lights up, to turn on your phone. Customizable r key that can be used to open the Settings screen.
settings menu Display/Info • Wallpaper • Text Size • Theme • Home Icons • Backlight • Clock • Menu View • Large Dialing • Language Phone Calls • Set Line • Any Key Ans • Auto Redial • Call Waiting •...
Use and Care To care for your Motorola phone, please keep it away from: liquids of any kind Don’t expose your phone to water, rain, extreme humidity, sweat, or other moisture. If it does get wet, don’t try to...
essentials Caution: Before using the phone for the first time, read the Important Safety and Legal information included in the gray-edged pages at the back of this guide. about this guide This guide shows how to locate a menu feature as follows: Find it: / >...
SIM card from your phone unless absolutely necessary. essentials battery Battery Use & Battery Safety • Motorola recommends you always use Motorola-branded batteries and chargers. The warranty does not cover damage caused by non-Motorola batteries and/or chargers. Caution: Use of an unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazard.
Page 15
Battery or Unable to Charge, take the following steps: • Remove the battery and inspect it to confirm it bears a Motorola “Original Equipment” hologram; • If there is no hologram, the battery is not a qualified battery; • If there is a hologram, replace the battery and retry charging it;...
appliance or heat source, such as a hair dryer or microwave oven. • Use care when handling a charged battery: Particularly when placing it inside a pocket, purse, or other container with metal objects. Contact with metal objects (e.g., jewelry, keys, beaded chains) could complete an electrical circuit (short circuit), causing the battery to become very hot, which...
USB connector on your phone as shown. charge from your computer You can partially charge your phone’s battery by connecting a Motorola-approved USB cable from your phone’s micro-USB port to a high power USB connector on a essentials...
computer (not a low-power one, such as the USB connector on your keyboard or bus-powered USB hub). Typically, USB high-power connectors are located directly on your computer. enable security You must enable security the first time you power on you phone or within 10 days of first activation of your phone.
advanced calling feature call waiting To accept the second call and put the active call on hold press K under Yes. To accept the second call and end the active call press 3-way call Make or receive a phone call and press / >...
send call alerts Sending a call alert discretely lets the recipient know that you want to talk to him or her on a Private call. When you send a call alert, the recipient’s handset displays your name and emits a series of beeps or vibrations.
to answer a call alert 1 Press the PTT button to start a Private call with the sender. 2 Queue the call alert by pressing K under Queue. 3 Clear the call alert by pressing K under Clear. store a phone number or private ID You can store a phone number or private ID in Contacts:...
feature set ringer ID Press K under Contacts. Select a contact and press / > Edit. Select Ringer and chose your desired ring tone. Press K under Done. call a stored phone number or private ID Find it: / > L. 1 Scroll to the Contacts entry.
and receive messages that may include text, pictures, videos, and audio files. create and send messages 1 From the home screen press K under Mesgs > [Create Message]. 2 Enter the phone number of the person you want to send the message to and press r or press K under Search.
more message options To view more message fields in a message you are creating, select ...More... The following options become available: option Subject: Create or edit the subject line. Attach: Attach a picture, audio file or voice record. Cc: Send a copy of this message to someone else.
Page 25
remove an inserted item To remove an item from the message you are creating, highlight it and press K under Delete. attach a picture, video, or audio recording You can attach one or more pictures, audio or voice recordings from your phone into the body of the message.
3 Take the picture. For instructions on how to take the picture see “camera” on page 45. 4 When you have captured the picture you want, press K under Save. To discard the picture, press K under Discard. You can then take another picture. 5 When finished, press K under Done.
6 The voice record is attached to the message and saved to the media center and the list of voice records. remove an attachment To remove an attachment in a message you are creating: 1 Select Attach. 2 Scroll to the attachment you want to remove.
2 To dismiss the message notification press K under Exit. While reading a text and numeric message that contains a phone number, you can press , to call that number. threaded inbox The threaded Inbox allows you to organize your messages by subject or sender. 1 From the Inbox, highlight a message.
2 Press / > Lock Message or Unlock Message. call a number in a message If a message you receive contains a phone number, Private ID, or Talkgroup ID in the From field, the To field, the Cc field, the Subject field, or the body of the message, you can call or send a call alert to that number.
To store the number or email address to an existing entry, select the entry. 5 With the Contacts type field highlighted, press ; left or right to display the Contacts type you want to assign the number or email address. 6 Press K under Save.
embedded objects and attachments If a message contains pictures, videos, or audio files in the body of the message, highlight each picture, video, or audio recording to view or play it. If a message contains a picture, video, or audio recording as an attachment, open the attachment to view the picture or play the video or audio recording.
1 View the message. 2 Highlight the picture, video, or audio recording you want to delete and press /. 3 Select Delete Picture, Delete Video, or Delete Audio. save attachments 1 View the message. 2 Highlight the attachment you want to save.
3 Press K under Cancel. sent items The Sent Items box holds sent messages. forward items from sent items 1 Scroll to the message you want to forward. 2 Press / > Forward. 3 Make edits if you wish, select the recipient and press K under Send.
The following options become available: option Signature: Allows you to create a signature that is automatically inserted at the end of your messages. Signatures can be edited before sending the message. Quick Notes: Lets you create new Quick Notes and edit or delete Quick Notes you created. Cleanup: Controls how long messages remain in the Inbox and Sent Items before being deleted.
Page 35
This option is available from many context-sensitive menus when you are using MMS. The following options become available: option Friendly Name: Allows you to create a friendly name. Your friendly name is displayed in the From field on other iDEN handsets when your message is received.
Page 36
3 Enter text from the keypad and press r. edit quick notes or replies You can edit only Quick Note phrases you have created. 1 From the Setup menu, select Quick Notes, or select MMS Setup > Replies. 2 Select the quick note or reply you want to edit.
2 Choose a clean up option from the following list: option Off: Messages are never automatically deleted. 5 Messages: If you have more than 5 messages, messages are deleted in the order they were received, starting with the oldest, until 5 are left. 10 Messages: If you have more than 10 messages, messages are deleted in the order they were received, starting with the...
delete a thread To delete a thread from the Inbox: 1 From the Inbox, select a thread. 2 Press / > Delete Thread. 3 Press K under Yes to confirm. message notifications When you receive a message, your phone notifies you with text on the display, a notification tone or vibration.
Your phone can be connected to a computer via USB for use as a modem. For more specific information on how to setup your phone for use with your computer please visit www.motorola.com/support and look under the FAQ section. essentials...
basics See page 1 for a basic phone diagram. display The home screen shows when you turn on the phone. To dial a number from the home screen, press number keys and ,. Note: Your home screen may look different. Ready 10:05pm 10/23 Time...
2 Active Phone Line: $ indicates phone line 1 is ready to make calls; ( indicates phone line 2 is ready to make calls. 3 Speaker On/Off: Sounds associated with Private calls and group calls can be set to come through the earpiece rather than through the speaker.
Page 42
2 Select one of the following options: entry method Alpha Press a key several times for different characters. Word Enter words using a predictive text entering system that lets you enter a word with fewer keypresses. Text Selects the desired entry Settings languages and Word Prediction features.
To accept a word completion (such as Billion when you entered Bill), press the navigation key to the right. To enter Bill, press the navigation key to the left. If next word prediction is turned on, when you hit space, you will be presented with a predicted word option.
volume Press the volume keys up or down to: • turn off an incoming call alert • change the earpiece volume during calls • change the ringer volume from the home screen Tip: You can quickly set your ringer to Vibrate All by holding the down volume key in the home screen.
Your phone can be connected to a PC, laptop, or PDA via USB for use as a GPS receiver. For more specific information on how to setup your phone for use with your computer please visit www.motorola.com/support and look under the FAQ section. features for the hearing impaired...
Page 46
If your HA has a telecoil, activate its switch, then also rotate the handset as illustrated to align the telecoils. Note: Some automatically switched hearing aids may need an auxiliary switching magnet. If you are unsure whether your HA is telecoil equipped or needs an auxiliary magnet, please refer to your HA user guide or contact a hearing aid professional or supplier.
main attractions media center The media center lets you access pictures, audio recordings, and videos stored in your phone’s memory. The following audio recordings can be accessed through the media center: • Voice records • Musical ring tones in the list of ring tones •...
Image files supported by the Media Center include: Format Max. Image Size (in pixels) 128 x 160 .png 128 x 160 .gif 640 x 480 .jpg 128 x 160 .wbmp Video files supported by the Media Center include: Format Frame Rate and Max.
Page 50
access the camera To access the camera, press e. To take pictures aim the camera lens and press K under Capture or press r. To save the picture, press r. To discard the picture without saving it, press K under Discard. From the camera viewfinder, you can press / to enter Menu Options.
option Camera Setup: To access the camera set up screen. access the media center You can access the media center from the camera at any time by pressing / > Media Center, except when you are using the Camera Setup menu or viewing the memory screen. The media center contains all your pictures, music files, and videos located on your phone’s memory.
PTX features With Push To View features, your phone can send and receive the following items through Private calls with other phones that have this capability: • Short text messages • Pictures • Datebook events • My Info • Contact information •...
begin a message and choose a recipient You can begin a message during a Private call, from the Contacts list, the Recent Calls list, or from the PT Manager. begin a message during a Private call While in a Private call, press / > Use PTT Feature >...
changes the Quick Note for this message only and will not change the Quick Note on the list. send a completed message After you have completed your message, press the PTT button to send it. receive messages When you receive a message, a message notification appears on the display.
A list of pictures that can be included in a Private call appears. 2 Select the picture you want to send. 3 Press the PTT button to send the picture. 4 Wait while the picture is transmitted. The Private call is temporarily interrupted while a picture is transmitted.
5 Once picture has been sent, when prompted press the PTT button to resume the call. receive a picture When someone sends you a picture, your phone emits a tone or vibrates and a message appears asking if you want to accept the picture.
send my info 1 While in a Private Call press / > Send via PTT > Send My Info, and push the PTT button to send. 2 From the home screen press / > My Info > / > Send via PTT. Enter a Private ID or press K under Browse to chose a recipient from Contacts, Recent Calls or Memo, and press r.
Private ID are not stored in the recipient’s Contacts. send contact information 1 While in a Private Call press / > Use PTT Feature. 2 Select Send Contact and select the contact information you want to send. 3 Push the PTT button to send. 1 From the home screen press / >...
one touch PTT Find it: / > > 2-Way Radio > One Touch PTT. One Touch PTT sets your phone to do any of the following each time you press the PTT button from the home screen: option Off: Nothing happens when you press the PTT button from the home screen.
To view a list of Contacts and SDG lists with Private IDs in Contacts: Find it: / > Quick PTT To move between Contacts, Recent Calls, or Memo, press the navigation key left or right. To make a Private call or SDG call: 1 Select the entries you want.
® Bluetooth Find it: / > turn Bluetooth on or off You can turn your phone’s Bluetooth feature on or off. While Bluetooth power is on, your phone can communicate with other devices. Find it: / > > Setup > Power 1 Select On to power Bluetooth On.
1234 as your phone’s PIN. 5 Press K under Ok. This handset offers the Bluetooth auto pair feature with auto pair compatible Motorola devices. When bonded via Bluetooth with a certain device, the pin will not be required. connect your handset with another Bluetooth device Find it: / >...
Page 63
The receiving device must be within 32 feet (10 meters) of your phone in order to connect. Note: Files sent or received may be up to 1 MB, depending on your service provider. sending information 1 From within Contacts, datebook, or Media Center, select the Contacts entry, Datebook event, audio file, video, or picture you want to send.
call features turn off a call alert You can press the volume keys to turn off a call alert before answering the call. recent calls The recent calls list contains information associated with calls you have made and received and call alerts you have received. When you send or receive Private calls, the recent call list contains the following PTX items with those calls:...
Find it: / > Recent Calls. 1 Scroll to or select the item you want to store. 2 Press K under Save to store the information as a new entry in the Contacts list. 3 Select an existing contact and update the information.
different numbers depending on the reason you missed the call. You can forward phone lines 1 and 2 independently. Find it: / > Call Forward. 1 To forward all calls select All Calls and select To to enter the phone number you want all your calls forwarded to.
emergency calls Your service provider programs one or more emergency phone numbers that you can call under any circumstances. Emergency calls can be made without a SIM card, when your phone is locked, or when the SIM card is blocked. Note: Emergency numbers vary by country.
speed dial Each phone number stored in Contacts is assigned a Speed Dial number, which you can use to call that number. 1 From the home screen, use the keypad to enter the Speed Dial number assigned to the phone number you want to call. 2 Press #.
selective dynamic group (SDG) calls A SDG call is similar to a Private call, but is made to all members of a SDG list at once. A SDG list is a group of Private IDs that you create using your phone. A SDG list must contain at least 2 members and can contain up to 20 members.
Page 70
add private numbers You can add Private IDs to a SDG list by selecting them from Contacts, the recent calls list, or memo. You can add all members in an existing SDG list by selecting the list. You can select more than one member from Contacts and the recent calls list.
Page 71
4 Press K under Yes to confirm. delete a SDG list from Contacts 1 Scroll to the SDG list you want to delete. 2 Press / > Delete SDG List. make SDG Calls 1 From Contacts or the recent calls list, scroll to or select the SDG list you want.
Page 72
SDG Call Details During a SDG call, you can view details about the other SDG list members, such as their name or Private ID, and their status on the call. To view SDG call details, press K under Details. In the SDG Call Details view, these icons appear next to member names or Private IDs: F The member of the SDG list who is speaking.
MOTOtalk Note: This feature may not be offered by your service provider. With MOTOtalk, you can make and receive Two-Way Radio calls without network coverage. If you are travelling outside your service provider's coverage area, receiving a poor signal, or otherwise want to temporarily avoid using your service provider's network, you can switch to MOTOtalk and talk with anyone on your code and channel who is...
switching to MOTOtalk To set your phone to MOTOtalk: 1 From the home screen press / > MOTOtalk and press r. 2 Select Go to MOTOtalk. Switching to MOTOtalk Please Wait displays. After a few seconds, the MOTOtalk idle screen displays. When MT Ready displays, you can begin using MOTOtalk.
For code calls, all parties must be on the same channel and code. For private MOTOtalk calls, the person you are calling must be in MOTOtalk and set to the same channel to receive your call. Note: When making a code call, all parties that are on your code and channel can hear your conversation.
2 Release the PTT button to listen. If you receive an error message: • No one is on your channel or code. • You are out of range. receiving code calls When you receive a code call, Receive will appear on the display. After hearing the MOTOtalk tone, you have 6 seconds to reply before the call times out.
private MOTOtalk calls If you want to have a private conversation without other parties listening in, you can make a private MOTOtalk call. The person you are calling must be in MOTOtalk and set to the same channel to receive your call. private only To set MOTOtalk to ignore code calls, so that you only make or receive private MOTOtalk...
• The person that you are trying to reach is set to a different channel. • The person that you are trying to reach is out of range. receiving a private MOTOtalk call The number or name of the person who is calling will appear in the display.
setup options You can set up MOTOtalk options on the MT Options screen. You can access this screen in both network and MOTOtalk modes. To access setup options: 1 Press / > MOTOtalk or MT Options. 2 Select Setup. You can set the following MOTOtalk options: •...
Page 80
1 From the Setup screen, scroll to State Tone and press r. 2 Select the interval after which you want the tone to sound. For example, if you select 1 hour, you will be notified every hour that you are in MOTOtalk. To turn off State Tone: 1 From the Setup screen, scroll to State Tone and press r.
customize ring tones To set the ring tone your phone makes when you receive phone calls, call alerts, message notifications, pictures sent using Send via PTT or Datebook reminders: Find it: / > Ring Tones 1 Make sure Vibrate All is set to Off. 2 Scroll through the list of ring tones and select the one you want to assign.
Setting this option to On lets you turn Vibrate All off by pressing the up volume control. Setting this option to Locked requires you to press and hold the up volume control to turn Vibrate All off. The Locked option helps prevent you from accidentally turning Vibrate All off.
wallpaper Set a previously saved photo or picture as a wallpaper (background) image in your phone’s external display, internal screen or throughout all menu screens. Find it: / > > Display/Info > Wallpaper 1 Select Wallpaper. 2 Scroll through the list of pictures and press r to select a picture.
Page 84
feature receive To view the information datebook while still in the Private call press r. events via The 5 most recent events received from a Private ID are stored with that Private ID on the recent calls list. To store events to the Datebook press K under Save while viewing the event you want to store.
options Clock: Controls whether the time and date appear on the home screen; sets time and date format; sets year. hide or show location information Your phone is equipped with a Location feature for use in connection with location- based services that may be available in the future.
Page 86
option Ask Access: When an application attempts to view the location of your phone, you will be prompted to give permission. However, location information may still be available to the phone’s owner, fleet manager, or account administrator. change GPS PIN When you receive your phone, your GPS PIN is 0000.
RF energy. Portable Radio Product Operation and EME Exposure Your Motorola radio product is designed to comply with the following national and international standards and guidelines regarding exposure of human beings to radio frequency electromagnetic energy (EME): •...
Motorola approved clip, holder, holster, case or body harness. If you do not use a body-worn accessory supplied or approved by Motorola and are not using the mobile device in the intended use positions along side the head in...
This device supports Bluetooth 1.2 including HSP, HFP, OPP, DUN, PBAP, and BPP. In order for Bluetooth devices to communicate with one another, they must utilize the same Bluetooth profile. To determine the profiles supported by other Motorola devices, visit www.hellomoto.com/bluetooth. For other devices, contact their respective manufacturer.
Alternatively, you may return unwanted mobile devices and electrical accessories to any Motorola Approved Service Center in your region. Details of Motorola approved national recycling schemes, and further information on Motorola recycling activities can be found at: www.motorola.com/recycling Disposal of your Mobile Device Packaging and User’s Guide...
Symbol Key Your battery, charger, or portable radio may contain symbols, defined as follows: Symbol Definition Important safety information 032374o follows. Do not dispose of your battery 032376o or phone in a fire. Your battery or phone may 032375o require recycling in accordance with local laws.
Service and Repairs If you have questions or need assistance, we’re here to help. Go to www.motorola.com/support, where you can select from a number of customer care options. You can also contact the Motorola Customer Support Center at 1 (800) 453-0920 (United...
Water can get into the phone’s circuits, leading to corrosion. If the phone and/or battery get wet, have them checked by your carrier or contact Motorola, even if they appear to be working properly. • Don’t allow the battery to touch metal objects. If...
Motorola recommends you always use Motorola-branded batteries and chargers. Motorola mobile devices are designed to work with Motorola batteries. If you see a message on your display such as nvalid Battery or Unable to Charge, take the following steps: • Remove the battery and inspect it to confirm that it has a “Motorola Original”...
In this case, the highest tested SAR value is 1.03 W/kg. The tests are carried out in accordance with international guidelines for testing. The SAR information includes the Motorola testing protocol, assessment procedure, and measurement uncertainty range for this product.
• the battery capacity falls below 80% of rated capacity, or • the battery develops leakage. MOTOROLA, at its option, will at no charge either repair the Product (with new or reconditioned parts), replace it (with a new or reconditioned Product), or refund the purchase price of the Product during the warranty period provided it is returned in accordance with the terms of this warranty.
All replaced parts of Product shall become the property of MOTOROLA. This express limited warranty is extended by MOTOROLA to the original end user purchaser only and is not assignable or transferable to any other party. This is the complete warranty for the Product manufactured by MOTOROLA.
MOTOROLA will defend, at its own expense, any suit brought against the end user purchaser to the extent that it is based on a claim that the Product or parts infringe a patent, and Motorola will pay those costs and damages finally awarded against the end user...
Product or parts as established by MOTOROLA. MOTOROLA will have no liability with respect to any claim of patent infringement which is based upon the combination of the Product or parts furnished hereunder with software, apparatus or...
Product registration is an important step toward enjoying your new Motorola product. Registering permits us to contact you for product or software updates and allows you to subscribe to updates on new products or special promotions. Registration is not required for warranty coverage.
If you choose to use your phone while driving, remember the following tips: • Get to know your Motorola mobile device and its features such as speed dial and redial. If available, these features help you to place your call without taking your attention off the road.
Page 103
inconvenient time, if possible, let your voice mail answer it for you. • Let the person you are speaking with know you are driving; if necessary, suspend the call in heavy traffic or hazardous weather conditions. Rain, sleet, snow, ice, and even heavy traffic can be hazardous. •...
index accessories 9 active phone line 37 advanced calling 15 3-way calls 15 call waiting 15 alert set 40, 77 turn off 40, 60 answer a call 14 audio formats 44 auto replies 26 backlight 78 battery charging 13 battery indicator 37 index battery installation 12 Bluetooth 57...
Page 105
display 36 drafts see also text messages, drafts earpiece volume 40 emergency number 63 end a call 14 end key 14 frequently asked questions service and repairs 88 GPS enabled emergency calls 63 GPS, see GPS enabled handsfree speaker 40 hearing aid 41 Hearing Aid Compatibility 95 home screen 36...
Page 106
navigation key 9, 40 one touch PTT 55 optional accessory 9 optional feature 9 packet data 37 phone number 18 power key 2 private calls answer 16 call alerts 16 make 15 receive a call alert 16 PT Manager 56 PTX features 48 index radio frequency 83...
Page 107
text entry 37 alpha method 39 word method 38 text messages 18, 35 creating 19 deleting 29 drafts 23 memory 30 message center 24 receiving 23 resend messages 29 sending 19 sent messages 29 video formats 45 voice names 62 voicemail 64 message indicator 64 receiving 64...
Page 109
NNTN7550A xxxxxxxx xx xx JAN/09 Printed in USA...
