Washing Machine
This manual is made with 100% recycled paper.
WF1804WP-03025Y-04_EN.indd 1
user manual
imagine
the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
WF1804WP(C/N/Q/S/U/V/W/Y)
WF1802WP(C/N/Q/S/U/V/W/Y)
WF1804YP(C/N/Q/S/U/V/W/Y)
WF1802YP(C/N/Q/S/U/V/W/Y)
WF1754WP(C/N/Q/S/U/V/W/Y)
WF1752WP(C/N/Q/S/U/V/W/Y)
WF1754YP(C/N/Q/S/U/V/W/Y)
WF1752YP(C/N/Q/S/U/V/W/Y)
2013-7-30 11:17:26

Advertisement

Table of Contents
loading

Related Manuals for Samsung WF1804WPC

Summary of Contents for Samsung WF1804WPC

  • Page 1 WF1752WP(C/N/Q/S/U/V/W/Y) WF1754YP(C/N/Q/S/U/V/W/Y) WF1752YP(C/N/Q/S/U/V/W/Y) Washing Machine user manual This manual is made with 100% recycled paper. imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register WF1804WP-03025Y-04_EN.indd 1 2013-7-30 11:17:26...
  • Page 2 (up to 2Kg) in just 15 minutes! • Outdoor Care Using a Samsung washing machine with Bubble allows you to wash waterproof clothing with greater comfort, in the knowledge that your washer provides excellent care for your outdoor clothes. The Foam Cushion created by Bubble protects against impact and abrasion damage to the water proofing layer, minimizing damage to outdoor clothing, and also protecting other...
  • Page 3 This manual contains important information on the installation, use, and care of your new Samsung washing machine. Refer to it for descriptions of the control panel, instructions on how to use the washing machine, and tips for making the most of its state-of-the-art features and functions.
  • Page 4 Congratulations on your new Samsung ActivFresh™ washer. This manual contains important information on the installation, use and care of your appliance. Please take time to read this manual to take full advantage of your washer’s many benefits and features.
  • Page 5 Do not let children (or pets) play on or in your washing machine. The washing machine door does not open easily from the inside, and children may be seriously injured if trapped inside. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction...
  • Page 6 safety information SEVErE WArninG SiGnS fOr inStALLAtiOn WArninG The installation of this appliance must be performed by a qualified technician or service company. - Failure to do so may result in electric shock, fire, an explosion, problems with the product, or injury. The appliance is heavy, take care upon lifting it Plug the power cord into an AC 220V~240V/50Hz/15A wall socket or higher and use the socket for this appliance only.
  • Page 7 Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance. - This may result in electric shock or fire. Do not pull the power cord, when unplugging the power plug.
  • Page 8 safety information Do not wash items contaminated with gasoline, kerosene, benzene, paint thinner, alcohol or other flammable or explosive substances. - This may result in electric shock, fire or an explosion. Do not open the washer door by force while it is operating (high-temperature washing/ drying/spinning).
  • Page 9 The use for business purposes qualifies as product misuse. In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
  • Page 10 safety information Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. - This may result in electric shock, fire, problems with the product, or injury. Do not spray volatile material such as insecticide onto the surface of the appliance.
  • Page 11 Do not use natural hand-washing soap for the washer. - If it hardens and accumulates inside the washer, it may result in problems with the product, discoloration, rust or bad odors. Do not wash large laundry items such as bedding in the washing net. - Place socks and brassieres into the washing net and wash them with the other laundry.

  • Page 12: Table Of Contents

    contents seTTING Up yOUR WAshING Checking the parts mAChINe Meeting installation requirements Electrical supply and grounding Water Supply Drain Flooring Surrounding temperature Alcove or closet installation Installing your washing machine WAshING A lOAd Of lAUNdRy Washing for the first time Basic instructions Using the control panel Child lock...

  • Page 13: Setting Up Your Washing

    Carefully unpack your washing machine, and make sure you’ve received all of the parts shown below. If your washing machine was damaged during shipping, or if you do not have all of the parts, contact Samsung Customer Service or your Samsung dealer. Work top...

  • Page 14: Electrical Supply And Grounding

    setting up your washing machine mEEtinG inStALLAtiOn rEQuirEmEntS Electrical supply and grounding To prevent unnecessary risk of fire, electrical shock, or personal injury, all wiring and grounding must be done in accordance with the National Electrical Code ANSI/FNPA, No. 70 Latest Revision and local codes and ordinances. It is the personal responsibility of the appliance owner to provide adequate electrical service for this appliance.

  • Page 15: Drain

    Drain Samsung recommends a standpipe height of 65 cm. The drain hose must be routed through the drain hose clip to the standpipe. The standpipe must be large enough to accept the outside diameter of the drain hose. The drain hose is attached at the factory.

  • Page 16: Removing The Shipping Bolts

    setting up your washing machine sTep 2 removing the shipping bolts Before installing the washing machine, you must remove the five shipping bolts from the back of the unit. 1. Loosen all the bolts with the supplied wrench. Option 2. Hold the bolt with the spanner and pull it through the wide section of the hole.

  • Page 17: Connecting The Water And Drain

    sTep 3 Adjusting the levelling feet When installing your washing machine, ensure that the power plug, the water supply and the drain are easily accessible. 1. Slide the washing machine into position. 2. Level your washing machine by turning the leveling feet in and out as necessary by hand.
  • Page 18 setting up your washing machine Connecting the water supply hose (selected models) 1. Remove the adaptor from the water supply hose. Adaptor Water supply hose 2. First, using a ‘+’ type screwdriver, loosen the four screws on the adaptor. Next, take the adaptor and turn part (2) following the arrow until there is a 5 mm gap.
  • Page 19 6. Turn on the water supply and ensure that no water leaks from the water valve, tap or adaptor. If there is a water leaks, repeat the previous steps. Do not use your washing machine if there is a water leak. This may cause electric shock or injury.
  • Page 20 setting up your washing machine Connecting the drain hose The end of the drain hose can not be sinked under water and be positioned in three ways: 1. Over the edge of a wash basin: The drain hose must be placed at a height of between 60 and 90 cm.

  • Page 21: Washing A Load Of Laundry 21 Washing For The First Time

    With your new Samsung washing machine, the hardest part of doing laundry will be deciding which load to wash first. WASHinG fOr tHE firSt timE Before washing laundry for the first time, you must run a complete empty cycle (i.e. no laundry).

  • Page 22: Using The Control Panel

    washing a load of laundry uSinG tHE COntrOL pAnEL dIGITAl GRAphIC Displays the remaining wash cycle time, all cycle information, and error dIsplAy messages. Select the tumble pattern and spin speed for the cycle. For detailed information, refer to “Washing clothes using the cycle selector”...
  • Page 23 Wool - Only for machine-washable wool. A load should be less than 2.0 kg. • The wool course washes the laundry using gentle cradling actions. During the wash, the gentle cradling and soaking actions are continued to protect the wool fibers from shrinkage / distortion and for a super gentle clean.
  • Page 24 washing a load of laundry Bubble selection is turned on as a default. Press the Bubble option button once to deselect and the Bubble Generator OFF (shown on the panel), press it again to turn the function back ON. • Some wash cycles must have Bubble option ON (will show on the bUbble seleCTION panel, and the Generator will turn on automatically).

  • Page 25: Child Lock

    Child lock The Child Lock function allows you to lock the buttons so that the wash cycle you’ve chosen can’t be changed. Activating/Deactivating If you want to activate or deactivate the Child Lock function, press the Temp. and Rinse buttons at the same time for 3 seconds.

  • Page 26: Bubble Wash

    washing a load of laundry Bubble Wash The Bubble function is available in all courses except for Drum Clean course and the function availability is as follows. Course bubble function Canceling the bubble function Cotton, Synthetics, Denim, Water Available Saving, Dark Garment, Daily Wash Available Intensive Cold, Outdoor Care, Baby Not available...

  • Page 27: Washing Clothes Using The Cycle Selector

    Washing clothes using the cycle selector Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Control” automatic control system. When you select a wash program, the machine will set the correct temperature, washing time, and washing speed. 1. Turn on your sink’s water tap.

  • Page 28: Washing Clothes Manually

    washing a load of laundry Washing clothes manually You can wash clothes manually without using the Cycle Selector. 1. Turn the water supply on. 2. Press the power button on the washing machine. 3. Open the door. 4. Load the articles loosely into the drum one at a time, without overfilling it. 5.

  • Page 29: Detergent And Additives Information

    Determining the load capacity Do not overload the washing machine or your laundry may not wash properly. Use the chart below to determine the load capacity for the type of laundry you are washing. fabric Type load Capacity model WF1804 / WF1802 WF1754 / WF1752 Cotton - average/lightly soiled 8.0 kg...

  • Page 30: Detergent Drawer

    washing a load of laundry Detergent drawer Your washing machine has separate compartments for dispensing detergent and fabric softener. Add all laundry additives to the correct compartment before starting your washing machine. Do NOT open the detergent drawer when your washing machine is running. 1.

  • Page 31: Cleaning And Maintaining Your

    cleaning and maintaining your washing machine Keeping your washing machine clean improves its performance, wards off unnecessary repairs, and lengthens its life. Drum CLEAn This course is a self-cleaning course that removes mold that may occur inside the washing machine. 1. Press the power button. 2.
  • Page 32 cleaning and maintaining your washing machine • Although generally, the Drum Clean Auto Alarm appears once a month or so, the frequency may differ depending on the number of times the washing machine is used. • In case of the alarm, please also clean the debris fi lter (refer to “Cleaning the debris fi lter” section on page 34).

  • Page 33: Cleaning The Detergent Drawer And Drawer Recess

    CLEAninG tHE DEtErGEnt DrAWEr AnD DrAWEr rECESS 1. Press the release lever on the inside of the release lever detergent drawer and pull the drawer out. 2. Remove the softener divider and the liquid Liquid detergent box(Option) detergent box(option) from the detergent drawer. Softener divider 3. Wash all parts under running water. 4.

  • Page 34: Cleaning The Debris Filter

    cleaning and maintaining your washing machine CLEAninG tHE DEBriS fiLtEr We recommend cleaning the debris filter 5 or 6 times a year, or when the error message of “5E” is displayed. (Refer to “Draining the washing machine in an emergency” in the previous page.) Before cleaning the debris filter, make sure to unplug the power cord.

  • Page 35: Cleaning The Water Hose Mesh Filter

    CLEAninG tHE WAtEr HOSE mESH fiLtEr You should clean the water hose mesh filter at least once a year, or when the error message of “4E” is displayed: 1. Turn off the water supply to the washing machine. 2. Unscrew the hose from the back of the washing machine. To prevent water from gushing out due to the air pressure in the hose, cover the hose with a cloth.

  • Page 36: Troubleshooting And 36 Check These Points If Your Washing Machine

    • Check if the drain pump is blocked by flocks or dirt . Clean the debris filter to abate noise. a strange noise. If the problem persists, contact your local Samsung Customer Service. 36_ troubleshooting and information codes WF1804WP-03025Y-04_EN.indd 36 2013-7-30 11:17:38...

  • Page 37: Information Codes

    • If the correct voltage is supplied, the cycle will resume automatically. For any codes not listed above, or if the suggested solution doesn’t fix the problem, call your Samsung Service Centre or local Samsung dealer.

  • Page 38: Cycle Chart

    cycle chart CyCLE CHArt user option)  max load(kg) detergent spin speed(mAx) rpm max Temp pROGRAm Wf1804 Wf1754 Wf1804 Wf1802 (˚C) pre-wash wash softener Wf1802 Wf1752 Wf1754 Wf1752 Cotton 1400 1200   Synthetics 1200 1200   Denim   Water Saving 1400 1200...

  • Page 39: Appendix 39 Fabric Care Chart

    appendix fABriC CArE CHArt The following symbols provide garment care directions. The care labels include four symbols in this order: washing, bleaching, drying and ironing, and dry cleaning when necessary. The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow the care label directions to maximize garment life and reduce laundering problems.

  • Page 40: Specifications

    appendix SpECifiCAtiOnS Type fRONT lOAdING WAsheR WF1804 / WF1802 DimEnSiOnS W598mm X D670mm X H850mm WAtEr prESSurE 50 kPa ~ 800 kPa WAtEr VOLumE ℓ WF1804 WF1802 nEt WEiGHt 70 kg 68 kg WASH AnD Spin CApACity 8.0 kg MODEL WF1804 / WF1802 220 V 150 W WASHING 240 V 150 W...
  • Page 41 SpECifiCAtiOnS Type fRONT lOAdING WAsheR WF1754 / WF1752 DimEnSiOnS W598mm X D670mm X H850mm WAtEr prESSurE 50 kPa ~ 800 kPa WAtEr VOLumE ℓ WF1754 WF1752 nEt WEiGHt 67 kg 66 kg WASH AnD Spin CApACity 7.5 kg MODEL WF1754 / WF1752 220 V 150 W WASHING 240 V 150 W...
  • Page 42 memo WF1804WP-03025Y-04_EN.indd 42 2013-7-30 11:17:40...
  • Page 43 memo WF1804WP-03025Y-04_EN.indd 43 2013-7-30 11:17:40...
  • Page 44 QUESTIONS OR COMMENTS? Country CAll OR VIsIT Us ONlINe AT AUSTRALIA 1300 362 603 www.samsung.com Code No. DC68-03025Y-04_EN WF1804WP-03025Y-04_EN.indd 44 2013-7-30 11:17:40...
