Page 2
1. Features 2. Safety Precautions 3. Images of Module and Circuit Boards 4. Key IC Description& Trouble Shooting Guide 5.Signal Flowing Chart 6. Bus Control Adjustment 7. Circuit Diagram...
Page 3
Features Model Functions HL15WHITE Screen size 15inch Aspect ratio Resolution 1 0 24×7 6 8 Brightness 250cd/m Contrast(Darkroom) 500:1 Response time(ms) Color system ATSC/NTSC NO. of preset channels Picture mode Angel of view H:150 / V:130 ° ° Color display...
Page 4
Model Functions HL15WHITE D-SUB jack DVI socket SCART socket Ear-Phone Out CCD,V-CHIP Semitransparent menu ZOOM 16:9 mode Child Lock Quick View NO. of built-in speakers Audio output power(Built-in)(W) 2*1.5 Total power input W Voltage range V Power frequency Hz Time of sleep timer(MINS)
Page 5
Safety Precautions Warning High voltages are used in the operation of this product. Do not romove the cabinet back from your set. Refer servicing to qualified service personnel. Warning To prevent fire or electrical shock hazard, Do not expose the main unit to rain or moisture. Warning Do not drop or push objects into the television cabinet slots or openings.
Page 6
Caution Never stand on, lean on, push suddenly the product or its stand. You should pay special attention to children to children. Caution Do not place the main unit on an unstable cart stand, shelf or table. Serious injury to an individual, and damage to the television, may result if it should fall.
Images of Module and Circuit Boards 1.images of Main Board 2.images of Power Supply...
Page 8
Key IC Description 1.UOC3 Function:TV signal processor with Teletext and Nicam PIN SYMBOL DESCRIPTION VSSP2 ground VSSC4 ground VDDC4 Digital supply to SDACs(1.8V) VDDA3(3.3V) Supply(3.3V) VREF_POS_LSL Positive reference voltage SDAC(3.3V) VREF_NEG_LSL+HPL Negative reference voltage SDAC(0V) VREF_POS_LSR+HPR Positive reference voltage SDAC(3.3V) VREF_NEG_HPL+HRP Negative reference voltage SDAC(0V) VREF_POS_HPR Positive reference voltage SDAC(3.3V)
Page 9
AUDIOIN5L Audio-5 input(left signal) AUDIOIN5R Audio-5 input(right signal) AUDOUTSL Audio output for SCART/CINCH(left signal) ADUOUTSR Audio output for SCART/CINCH(right signal) DECSDEM Decoupling sound demodulator QSS0/AMOUT/AUDEE inter-carrier output/AM output/deemphasis(front-end audio out) GND2 Ground 2 for TV processor PLLIF IF-PLL loop filter AGC sound IF/internal-external AGC for DVB SIFAGC/DVBAGC applications...
Page 10
YIN(G/YIN2/CVBS-Yx Y-input for YUV interface(2th G input/Y input or CVBS/Yx input) YSYNC Y-input for sync separator YOUT Y-output (for YUV interface) U-output for YUV interface(2 RGB/YPbPr insertion UOUT(INSSW2) input) V-output for YUV interface(general purpose switch VOUT(SWO1) output) INSSW3 RGB/YPbPr insertion input R/PRIN3 R input/Pr input G/YIN3...
Page 11
Supply periphery on-chip voltage 110 VDDP(3.3V) regulator(3.3V) 111 P2.0/TPWM Poet 2.0 or tuning PWM output 112 P2.1/PWM0 Port 2.1 or PWM0 output 113 P2.2/PWM1 Port 2.2 or PWM1 output 114 P2.3/PEM2 Port 2.3 or PWM2 output 115 P3.0/ADC0 Port 3.0 or ADC0 input 116 P3.1/ADC1 Port 3.1 or ADC1 input 117 VDDC1...
Page 12
AHS0 ADC horizontal sync input Adjustable Schmidt trigger 5V tolerance Power from PIN 13 ADC_VDD ADC Power ADC_GND ADC Ground 1st Positive BLUE analog input (Pb+) 1st Negative BLUE analog input (Pb-) SOG0 1st Sync on Green 1st Positive GREEN analog input (Y+) 1st Negative GREEN analog input (Y-) 1st Positive RED analog input (Pr+) 1st Negative RED analog input (Pr-)
Page 13
BBLU7 Display B-port Blue Data 7 BBLU6 Display B-port Blue Data 6 BBLU5 Display B-port Blue Data 5 BBLU4 Display B-port Blue Data 4 BBLU3 Display B-port Blue Data 3 BBLU2 Display B-port Blue Data 2 BBLU1 Display B-port Blue Data 1 BBLU0 Display B-port Blue Data 0 BGRN7...
Page 14
104 ARED4 Display A-port Red Data 4 105 ARED3 Display A-port Red Data 3 106 ARED2 Display A-port Red Data 2 107 Pad 3.3V Ground PGND 108 Pad 3.3V Power PVCC 109 33VPNLOUT Panel on/off switch ot(Max current driving 1A) 110 COUT Crystal out 111 ARED1...
Page 15
P4.3 Bit 3 of port 4 P3.1/TXD Bit 1 of port 3 & Transmit data P3.2/INT0 Bit 2 of port 3 & low true interrupt 0 P3.3/INT1 Bit 3 of port 3 & low true interrupt 1 P3.4/T0 Bit 4 of port 3 & Timer 0 P3.5/T1 Bit 5 of port 3 &...
Page 16
4.TPA1517NE Function: Audio power amplifier IN1 is the audio input for channel 1 SGND SGND is the input signal ground reference SVRR SVRR is the midrail bypass mode enable OUT1 OUT1 is the audio output for channel 1 PGND PGND is the power ground refernce OUT2 OUT2 is the audio output for channel 2 VCC is the supply voltage input.
Trouble shooting 1.Power Supply Trouble Check F1 for 12V Check F1 and CN10 Check E33(470μF/25V)for 5v Check F1 for shortcut Check power output for LDO Turn on or not Check the power Check Pin3 U13 Turn on Change LDO supply net follow F1 For 350Khz Or The load is the set...
Page 34
2.Display Trouble 2.1 Black Black Screen Check 5V for BLON on CN10 Tunn on or not 12V inverter input ? Turn on Check the power supply Check the inverter Check U6/NT68F631ALG 43th pin or self-proofed Check Mcu Check the cirture for 1,power supply 2,Reset 3,Crystal...
Page 35
2.2 White White Screen Check power supply (for panel) Check Q24 0~3.3V(5V or 12V) ,according to the volitage) Check signal output of U5/NT68565FG Check U5 Check voltage of Q24 Check voltage between Check LCD or 1,Power supply U6/NT68F631ALG 7th Q24 Panel Connector 2,Time circuit or check U6 i/o...
Page 36
2.3 Exceptional screen Exceptional screen Check voltage for the panel Select the right panel voltage Change the panel Check the panel connector connector Change LCD Check LCD Check the output net,the Change/mend the part connector circuit Check U5 For Power supply & timer circuit...
Page 37
3.Audio Trouble 3.1 No Audio No Audio Check audio signal input Check the set of volume, mute Check signal from C11 U3/TPA1517NE PIN7 11.2V? Check power U3 8th Check U3 PIN1 and PIN9 for signal input Check U3 PIN4 and PIN6 for Chekc U21PIN60,61for signal output signal output Check the...
Page 38
3.2 TV No Audio TV no audio, having picture Check audio and PC AV Check signal ouput of SAW2/M9370M30 PIN1 Check the net between SAW2 1. check SAW2 Turn to NO AUDIO Pin1and C133/0.01μF 2. check U21 PIN29,30 trouble shooting Check C133 3.
Page 39
3.3 TV Audio abnormal Noise and NICAM can’t be detected Check the audio system Select the right audio Picture is normal? Check C113/0.01UF、D26、 R140/0 or change SAW2 Search again...
Page 40
4.Function Trouble 4.1 TV TV can not search/No picture Check RF signal input Check voltage T1/TDQ-6H3PIN6 for 5V Check voltage T1 PIN3 for 0V Check voltage T1 PIN9 for 33V Check I C signal T1 PIN4,5 Check signal T1 PIN11 Check voltage T1 PIN1 >V Examine Examine...
Page 41
4.2 PC Picture not in center No signal Missing color Picture dithering Check U5 RGB input Check VS,HS signal Reset Check Check OSD setting Check R,G,B Auto adjust Check VS.HS Reset circuit VS.HS...
Page 42
4.3 AV/SV SCART YPbPr/YCbCr 、S- Video、AV No signal No signal Missing color except PC Check RGB signal input for U5 Check RGB circuit Reset Check VS, HS circuit Check the circuit for power supply of U21...
